- Page 1 USER GUIDE 3 Channel Datalogging Thermometer Model SD200...
- Page 2 Introduction Congratulations on your purchase of the Extech SD200 3-Channel Temperature Datalogger. This meter displays and stores temperature readings from one to three type k thermocouple temperature probes. Data is stored on a SD card for transfer to a PC. This meter is shipped fully tested and calibrated and, with proper use, will provide years of reliable service.
-
Page 3: Product Description
10. Reset button 11. RS-232 output 12. SD memory card socket 13. T1 thermocouple input 14. T2 Thermocouple input 15. T3 thermocouple input Note: Battery Compartment and Tilt Stand are located on the back of the meter. SD200-EU-EN V1.8 07/13... - Page 4 Press the LOGGER button for >2 seconds to begin logging. “DATALOGGER” will appear in the display (between T2 and T3 displays) and the meter will beep each time the data is recorded (if the beeper is enabled). SD200-EU-EN V1.8 07/13...
- Page 5 Remove the memory card from the datalogger and plug it into the SD card slot on the PC. Launch Excel and open the data file on the memory card. The file will appear similar to the figure below. SD200-EU-EN V1.8 07/13...
- Page 6 RESET button on the side of the datalogger (use a paper clip or similar pointed object) to return the meter to a working state. RS232 Interface A serial output is provided to link the meter to a PC’s serial port. Call Technical Assistance for more information on this interface. SD200-EU-EN V1.8 07/13...
-
Page 7: Specifications
Never mix battery types. Always install new batteries of the same type. Copyright © 2013 FLIR Systems, Inc. All rights reserved including the right of reproduction in whole or in part in any form ISO-9001 Certified www.extech.com SD200-EU-EN V1.8 07/13...
