Operating Your Ceiling Fan - Hunter Ceiling fan Installation And Operation Manual

10
installing the switch housing cap and plug button
Install the switch housing cap and plug button to the lower switch
housing as shown in Figure 31.
Figure 31 - Installing the
switch housing cap and plug button
installing the lower switch housing
1. Connect the upper plug connector from the motor to the lower
plug connector in the lower switch housing assembly. See Fig-
ure 28.
NOTE: Both plug connectors are polarized and will only fit to-
gether one way. Make sure that both connectors are properly
aligned before connecting them together. Incorrect connec-
tion could cause improper operation and damage to the prod-
uct.
2. Place the lower switch housing assembly over the upper switch
housing. Align the side screw holes in the upper and lower
switch housings. Attach the lower switch housing to the up-
per switch housing with three #6-32 x 3/8" housing assembly
screws. See Figure 28.
41886-01 02/08/2005
41886-01_Rev 02.08.05.pmd 10
Lower Switch
Housing
Cap
Plug Button

operating your ceiling fan

1. Turn on electrical power to the fan.
2. The fan pull chain controls power to the fan. The pull chain
has five settings in sequence: High, Medium, Low, Ultra Low
and Off.
• Pull the chain slowly to change settings.
• Release slowly to prevent the chain from recoiling into the
blades.
• The chain uses a breakaway connector that separates if
the chain is jerked. If this happens, simply reinsert the chain
into the connector.
3. The light pull chain controls power to the light. The pull chain
has two settings: On and Off.
4. Ceiling fans work best by blowing air downward (counterclock-
wise blade rotation) in warm weather to cool the room with a
direct breeze. In winter, having the fan draw air upward (clock-
wise blade rotation) will distribute the warmer air trapped at
the ceiling around the room without causing a draft. Refer to
Figure 32.
Figure 32 - Air flow patterns
To change the direction of air flow, turn the fan off and let it
come to a complete stop. Slide the reversing switch on the fan
to the opposite position as shown in Figure 33. Restart fan.
Fan Pull
Chain
Figure 33 - Pull chain and reversing switch
2/8/05, 5:14 PM
Reversing
Switch
© 2005 Hunter Fan Company
