- Page 1 44202 07/08/2010...
-
Page 2: Site Selection
Site Selection and Preparation Refer to the included booklet "Guide to Choosing and Preparing a Ceiling Fan Site" to determine the best location for your fan. The booklet also includes information to ensure your fan support and outlet box meet applicable safety codes for ceiling fans. -
Page 3: How To Use This Manual
How To Use This Manual Screwdriver, Phillips- Wrench How to Use This Manual: head Be sure to read the entire manual before beginning installation and save any extra parts for future use. This manual will help you install, operate, and maintain your new fan. These instructions are designed to make Screwdriver, Flat-head Hammer installation and assembly as simple and efficient as possible. - Page 4 Fan Mounting Options Standard Mounting is the most common way to mount a There are three different ways to mount your ceiling fan, depending ceiling fan. Standard mounting is recommended for ceilings on your needs and the style of your ceiling.
- Page 5 If angle mounting, Be sure to orient the ceiling plate so that the Drill one hole on each side of the supply mains for the expansion arrows printed on the ceiling plate are pointing toward the ceiling anchors. Measure this distance using the oval slots in the ceiling peak.
- Page 6 Secure the secondary support cable [a] to the support hook [b] Pull the supply mains [a] through the center hole of the ceiling located in the ceiling. Align the Anchor bolts [c] with the oval slots plate [b] and align the two oval slots in the ceiling plate [b] with in the ceiling plate [d].
- Page 7 For standard or angle mounting: Loosen the setscrew [a] on the adapter [b]. With the fan motor [a] resting in the packaging, slide the canopy trim ring [b] and canopy [c] onto the wires [d]. Pull the wires [a] through one side of the pin [b] in the pipe Screw the pipe assembly [a] into the adapter until tight.
- Page 8 Securely tighten the pipe setscrew [a]. Proceed to step 18. For flush mounting: Slide the canopy trim ring [a], canopy [b] and low profile washer [c] onto the wires [d] from the fan motor [e]. Align the holes in the assembly washer [a] with the holes in the top Raise the fan and place the hook [a] on the ceiling plate through the of the fan and secure with three assembly screws [b].
- Page 9 WARNING! To avoid possible electric shock, before wiring the fan, disconnect Connect the end of the earth wire [a] (green) from the ceiling plate power to the fan by turning off the circuit breakers to both the outlet box and its [b] and the earth wire [c] from the ceiling to the green wire [d] associated wall switch location.
- Page 10 If you have a separate switch for the light, connect that wire [a] to WARNING! Be sure no bare wire or wire strands are visible after making the black and white wire [b] from the fan motor [c] by twisting the connections.
- Page 11 Raise the canopy over the ceiling plate. Rotate the canopy clockwise Partially install the three canopy screws [a] into the canopy one at a until the tabs on the ceiling plate totally engage with the slots in the time. Once all three screws are in, tighten them. canopy Using both hands, push the canopy trim ring [b] up to the top of the canopy.
- Page 12 Loosely insert blade mounting screws [a] through the blade iron Partially thread two small assembly screws [a] into two of the three [b] into the fan until all fan blades [c] are spaced and attached. outermost holes on the switch housing mounting plate [b]. Securely tighten all screws.
- Page 13 Install the remaining small assembly screw [a] into the third hole Attach the plug connector [a] from the motor housing [b] to the and tighten all three securely. plug connector [c] on the lower switch housing [d]. Place the lower switch housing assembly [a] over the upper switch housing [b] then align the holes of both housings and secure with three side screws [c].
-
Page 14: Cleaning And Maintenance
Wood finish blades should be cleaned with a furniture polish cloth. Occasionally, a light coat of furniture polish may be applied for added protection and beauty. Painted and high-gloss blades may be cleaned in the same manner as the fan finish. If you need parts or service assistance contact your Hunter Fan retailer or visit out website at http://www.hunterfanglobal.com. Troubleshooting Troubleshooting Problem: Excessive wobbling. - Page 15 44202 07/08/2010...
