2

Physical Description

Inner View

Vari-focal Lens
Micro SD/SDHC/SDXC
Reset Button
Jumpers
Microphone Video Output
NTSC
Internal
60Hz
PAL
External
50Hz
1
2
1. There is no internal microphone. Connect an external microphone if you need
audio inputs.
2. Use the included AV cable to connect to a camera tester or LCD monitor to begin
initial setup.
LCD Monitor/
Camera tester
Card Slot
Audio/Video
Out (green)
Microphone In
(pink)
Ethernet 10/100
RJ45 Socket
AV Out
EN - 2
Remove the foam pad
IR LEDs (8 units, effective up
to 15m)
Black Cover
Tilt Adjustment Screw
Auto Focus Button
General I/O Terminal
Block
