FD8365EHV/8355EHV
Quick Installation Guide
繁中
簡中
日本語
English
Indonesia
Dansk
2/1.3MP • 20M IR • Smart Focus System •
IP66
Français
Español
Deutsch
Português
Fixed Dome
Network Camera
Русский
Türkçe
Italiano
Polski
Česky
Svenska
Nederlands

Advertisement

loading
Need help?

Need help?

Do you have a question about the FD8365EHV and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Vivotek FD8365EHV

  • Page 1 FD8365EHV/8355EHV Fixed Dome Network Camera Quick Installation Guide Русский Česky Svenska Nederlands 繁中 簡中 日本語 Türkçe English Français Español Deutsch Português Italiano Polski Indonesia Dansk 2/1.3MP • 20M IR • Smart Focus System • IP66...
  • Page 2 Warning Before Installation / Warnung vor der Installation / Waarschuwing voor installatie Power off the Network Camera as soon as Keep the Network Camera away from smoke or unusual odors are detected. water. If the Network Camera becomes wet, power off immediately. Netzwerkkamera bei Rauchentwicklung oder ungewöhnlichem Geruch sofort Halten Sie die Netzwerkkamera von...
  • Page 3 Physical Description / Beschreibung der Teile / Afmetingen IR LEDs (4 units, effective up to 20m) IR-LEDs (4 Einheiten mit einer Inner View Reichweite von bis zu 20 m) IR-leds (4 eenheden, effectief Vari-focal Lens tot 20m) Gleitsichtobjektiv Varifocusknop Tilt Adjustment Screw Kippanpassungsschraube Bevestigingschroef Focus &...
  • Page 4 Use the included AV cable to connect to a camera tester or LCD monitor to begin initial setup. Verwenden Sie das beiliegende AV-Kabel, um den Kameratester oder LCD-Monitor für die grundlegende Einrichtung anzuschließen. Gebruik de bijgesloten AV-kabel om een cameratester of lcd-scherm aan te sluiten om de camera voor het eerst in te stellen.
  • Page 5 Cabling Assembly / Kabelverbindung / De kabels leggen Connect power lines and if you have external devices such as sensors and alarms, make the connection from the general I/O terminal block. Schließen Sie die Stromkabel an und stellen Sie den Anschluss vom allgemeinen I/O Anschlussblock her, wenn Sie über externe Geräte wie z.B.
  • Page 6 Waterproof Connector / Vandtæt konnektor / Waterdichte aansluiting Sealing Nut (A) Dichtungsmutter Verzegelingsmoer Housing (B) Gehäuse Behuizing Seals (C) Dichtungen Verzegelingen Seal (D) Dichtung Verzegeling Screw Nut (E) Schraubenmutter Schroefmoer Hex Nut (F) Sechstkantmutter Netmoer Assembling Steps / Wasserdichter Anschluss / Montagestappen 4.
  • Page 7 Connecting RJ45 Ethernet Cable / Anschluss des RJ45 Ethernetkabels / RJ45 Ehternet-kabel aansluiten RJ45 Cable Dimension / RJ45 Kabelabmessung / Afmetingen van de RJ45-kabel Recommended cable diameter: 5 to 8mm Empfohlene Kabeldicke: 5 bis 8 mm Aanbevolen kabeldikte: 5 tot 8 mm Assembling Steps / Zusammenbau / Montagestappen Rubber Seal Plug 1.
  • Page 8 Mounting the Camera / Montieren der Kamera / De Camera monteren 1. Attach the supplied alignment sticker to the wall. Bringen Sie den Aufkleber an der Wand an. Bevestig de bijgesloten uitlijnsticker op het plafond. 2. Using the circle marks on the sticker, drill at least 2 pilot holes symmetrically on each side into the wall.
  • Page 9 Installieren Sie den “Installationsassistenten 2”. Installeer de “Installatiewizard 2.” vanaf de map Software Utility op de software-cd. 2. The program will search for VIVOTEK Video Receivers, Video Servers or Network Cameras on the same LAN. Das Programm sucht nach VIVOTEK Videoempfängern, Videoservern oder Netzwerkkameras in demselben LAN.
  • Page 10 To adjust the zoom factor and focus range Zur Einstellung des Zoomfaktors und des Fokusbereichs De zoomfactor en focusbereik aanpassen 1. The camera comes with a motorized vari-focal lens module. With a web console, you can enter the Configuration > Media > Image > Focus page to tune the image zoom and focus.
  • Page 11 Completion / Abschluss / Voltooien 1. Attach the dome cover to the camera by combining it to the retainer and aligning with the mounting holes. Bringen Sie die Kugelabdeckung an der Kamera an, indem Sie sie mit der Halterung zusammenführen und an den Montageöffnungen ausrichten.
  • Page 13 P/N:625023100G Rev. 1.0 All specifications are subject to change without notice. Copyright 2013 VIVOTEK INC. All rights reserved.
