864 TRV GreenSmart™
WARNING:
If the information in these instructions is not followed exactly, a fire or explosion
may result causing property damage, personal injury or loss of life.
•
DO NOT PLACE ARTICLES ON OR AGAINST THIS APPLIANCE.
•
DO NOT USE OR STORE FLAMMABLE MATERIALS NEAR THIS APPLIANCE.
•
DO NOT SPRAY AEROSOLS IN THE VICINITY OF THIS APPLIANCE WHILE IT IS IN OPERATION.
•
DO NOT MODIFY THIS APPLIANCE.
•
Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any
other appliance.
WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
• Do not touch any electrical switch; do not use any phone in your building.
• Immediately call gas supplier from a neighbor's phone. Follow the gas supplier's instructions.
• If you cannot reach your gas supplier, call the fire department.
-
Installation and service must be performed by a qualified installer, service agency or the gas
supplier.
This appliance may be installed in an aftermarket permanently
located, manufactured home (USA only) or mobile home, where
not prohibited by local codes.
This appliance is only for use with the type(s) of gas indicated on
the rating plate. A conversion kit is supplied with the appliance.
Owner's Manual
© Copyright 2009, T.I.
Fireplace
• Operation
• Maintenance
$10.00
100-01227_000
Listed by
AS 4553-2008
GMK10026
IAPMO-R&T OCEANA
Dragon Wholesaling Pty. Ltd.
Unit 2, 16 Lexington Drive
4090227
Bella Vista NSW
Australia 2153
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Travis Industries 864 TRV GS
Summary of Contents for Travis Industries 864 TRV GS
- Page 1 Listed by 864 TRV GreenSmart™ Fireplace • Operation AS 4553-2008 • Maintenance GMK10026 IAPMO-R&T OCEANA WARNING: If the information in these instructions is not followed exactly, a fire or explosion may result causing property damage, personal injury or loss of life. •...
-
Page 2: Introduction
Or, mail your warranty card to: Model: 864 TRV GS Fireplace Travis Industries House of Fire 4800 Harbour Pointe Blvd. SW Mukilteo, WA 98275 Serial Number: Save Your Bill of Sale. -
Page 3: Table Of Contents
– see page 9). In Green Smart mode you will achieve a 3.5 star energy rating. If you choose to run the fireplace in standing pilot mode (used primarily for very cold climates of 0˚ C./32˚ F.) you will only achieve a 1 star energy rating. 4090227 © Travis Industries 100-01227_000... -
Page 4: Safety Precautions
Immediately call a qualified vicinity of this heater. service technician to inspect the appliance and to replace any part of the control system and any gas control that has been under water. 4090227 © Travis Industries 100-01227_000... - Page 5 If the fiber logs become damaged, replace with Travis Industries log set. Children and adults should be Travis Industries, Inc. grants alerted to the hazards of high no warranty, implied or stated, surface temperature and should for the installation or...
-
Page 6: Operation
This switch turns the rear burner on and off. AA Battery Holder This holder contains 4 AA batteries that allow the fireplace to operate during power outages. This switch turns the fireplace burners on and off. Main Burner 4090227 © Travis Industries 100-01227_000... -
Page 7: Starting The Fireplace For The First Time
The rear portion of the burner may be shut off to lower the heat output and flame size from the burner (this is called the comfort control). Use the comfort control switch to adjust this as desired. COMFORT CONTROL 4090227 © Travis Industries 100-01227_000... -
Page 8: Adjusting The Flame Height
Accent Light This fireplace has a built-in accent light that may be turned on and off and dimmed to your preference. Turn the knob to achieve the desired light output. HIGH ACCENT LIGHT HIGH 4090227 © Travis Industries 100-01227_000... -
Page 9: Adjusting The Optional Blower Speed
Frequent On / Off Operation – if you are frequently turning the fireplace on and off, you may wish to leave it in continuous pilot. This allows the burner to turn on more quickly, without pilot ignition delay. CONTINUOUS PILOT GREEN SMART PILOT 4090227 © Travis Industries 100-01227_000... -
Page 10: Normal Operating Sounds
This appliance has several areas that reach high temperatures. Dust or other particles on these areas may burn and create an odor. This is normal during start-up. You may notice the smell is more acute if the appliance was left idle for a long period. 4090227 © Travis Industries 100-01227_000... -
Page 11: Maintenance
Panel Lights Lift up and swing the lower grill down to acces the area below the Swing the concealment cover firebox. up and slide it back to expose AA Battery the controls. Holder AA Battery Tray 4090227 © Travis Industries 100-01227_000... -
Page 12: Accent Light Replacement
If the pilot or main burners do not burn correctly, contact your dealer for service. Monitor blower operation. Remove any debris or vegetation near the vent termination. Contact your dealer if any sooting or deterioration is found near the vent termination. 4090227 © Travis Industries 100-01227_000... -
Page 13: Grill Installation And Removal
(this prevents the it allows the grill to swing bushing. Once in place the grill is grill from accidentally falling off). forward. held in place by gravity. 4090227 © Travis Industries 100-01227_000... -
Page 14: Face Installation And Removal
Some fireplaces have a face that fits over the glass frame. The face can be removed following the directions below. Phillips Screwdriver Four screws hold the face in place. The screws are accessed through the grills on the face. 4090227 © Travis Industries 100-01227_000... -
Page 15: Glass Frame Removal And Installation
Lift the glass frame slightly and attach the lower latches. NOTE: Make sure the glass frame is all the way in place - it should be flush with the front of the fireplace when installed. 4090227 © Travis Industries 100-01227_000... - Page 16 Top of Firebox Glass Frame Anchor Note how the washer on the latch fits behind the flange on the glass frame anchor. Once fully inserted, turn the latch until it is upright. 4090227 © Travis Industries 100-01227_000...
-
Page 17: Log Set Installation
When installed, the ten (10) logs should appear as shown below. The directions on the following pages detail installation of this log set. Back Log Center Log Right Twig Left Log Center Left Twig Left Twig Center Twig Front Left Log Right Log Front Ember Chunk 4090227 © Travis Industries 100-01227_000... - Page 18 The log straddles the burner and does not cover any burner holes. Right Log The right log has a channel on the bottom that fits over the grate. Place the log in place and slide it to the rear. 4090227 © Travis Industries 100-01227_000...
- Page 19 Left Log The left log has a channel on the bottom. Place this channel over the grate. When in place, make sure the log is positioned so it does not block any burner holes. 4090227 © Travis Industries 100-01227_000...
- Page 20 (make sure it is not over any burner holes). Front Ember Chunk The front ember chunk has a groove on the bottom that fits over the grate. Place it as shown below. 4090227 © Travis Industries 100-01227_000...
- Page 21 Make sure the twig is positioned so it does not cover any burner holes. 4090227 © Travis Industries 100-01227_000...
- Page 22 Make sure the fork on the front of the log fits over the grate as shown below. Right Twig The right twig has a hole on the bottom that fits over the pin on the right log. Position the twig so it rests on the back log as shown below. 4090227 © Travis Industries 100-01227_000...
- Page 23 A bag of embers is provided to further enhance the firebox. Place the embers on the firebox floor and on the burner. Do not place embers over any of the burner holes or air channels. 4090227 © Travis Industries 100-01227_000...
-
Page 24: Glass Cleaning
With the outer glass Inner glass frame frame and screen removed, the outer surface of the glass The optional screen is may be cleaned. sandwiched between the inner and outer glass frame. Outer glass frame 4090227 © Travis Industries 100-01227_000... -
Page 25: Troubleshooting Table
Replace the AA batteries (see page 11) Comfort Control Does not Work The logs or coals are placed incorrectly See "Log Set Installation" Thin Layer of Soot Improper air shutter adjustment Adjust Air Shutter - contact your dealer Covers the Glass 4090227 © Travis Industries 100-01227_000... -
Page 26: Wiring Diagram
TRAY INTERMITTENT CONTROL PILOT Accent 240v Power In Thermodisk Rheostat 240v Power In Light Optional Blower(s) Rheostat Caution: Label all wires prior to disconnection when servicing controls. Wiring errors can cause improper and dangerous operation. 4090227 © Travis Industries 100-01227_000... -
Page 27: Replacement Parts List
Maintenance Replacement Parts List Caution: Use only Travis Industries replacement parts. Do not use substitute materials. Warning: Do not operate appliance with the glass front removed, cracked, or broken. Replacement of the glass should be done by a licensed or qualified service person. -
Page 28: Warranty
2. Travis Industries has the option of either repairing or replacing the defective component. 3. If your dealer is unable to repair your appliance’s defect, he may process a warranty claim through TRAVIS INDUSTRIES, INC., including the name of the dealership where you purchased the appliance, a copy of your receipt showing the date of the appliance’s purchase, and the serial number on your appliance. -
Page 29: Optional Equipment
Blower The optional blowers help transfer heat to your home. Firebacks There are several styles of decorative firebacks that fit inside the firebox and enhance the area behind the flames. 4090227 © Travis Industries 100-01227_000... -
Page 30: Index Index
Safety Precautions .............. 4 Starting the Fireplace for the First Time ......7 Troubleshooting Table ............25 Turning the Fireplace On and Off ........7 Warranty ................27 Wiring Diagram ..............26 Yearly Service Procedure ........... 12 4090227 © Travis Industries 100-01227_000...
