KOBE RANGE HOODS authorized agents will automatically void the warranty. KOBE RANGE HOODS will not be held responsible for any damages to personal property or real estate or any bodily injuries whether caused directly or indirectly by the range hood.
Page 4
What to Do In The Event Of a Range Top Grease Fire • SMOTHER FLAMES with a tight fitting lid, cookie sheet, or metal tray, and then turn off the burner. KEEP FLAMMABLE OR COMBUSTIBLE MATERIAL AWAY FROM FLAMES. If the flames do not go out immediately, EVACUATE THE AREA AND CALL THE FIRE DEPARTMENT or 911.
{H} One Piece Duct Cover – 1 {I} Mounting Bracket – 1 {J} Mounting Template All screws attached to units OPTIONAL RECIRCULATING KIT AVAILABLE. FOR MORE INFORMATION, PLEASE VISIT OUR WEBSITE :::.2%(5DQJH+RRGV&20 OR CONTACT KOBE RANGE HOODS AT (626) 775-8880.
INSTALLATION PLEASE READ ENTIRE INSTRUCTIONS BEFORE PROCEEDING Calculation before Installation To calculate installation, please refer to TABLE 1. (All calculation in inches.) TABLE 1 A = Height of Floor to Ceiling B = Height of Floor to Counter Top (Standard: 36") C = Preferred Height of Counter Top to Hood Bottom (Recommended 30"...
Page 7
Preparation before Installation NOTE: TO AVOID DAMAGE TO YOUR HOOD, PREVENT DEBRIS FROM ENTERING Figure 1 THE VENT OPENING. Decide the location of the venting pipe from the hood to the outside. (Figure 1) A straight, short vent run will allow the hood to perform more efficiently.
Wiring to Power Supply SAFETY WARNING Figure 4 RISK OF ELECTRICAL SHOCK. THIS RANGE HOOD MUST PROPERLY GROUNDED. MAKE SURE THIS IS DONE QUALIFIED ELECTRICIAN ACCORDANCE WITH APPLICABLE NATIONAL LOCAL ELECTRICAL CODES. BEFORE CONNECTING WIRES, SWITCH POWER OFF AT SERVICE PANEL AND LOCK SERVICE PANEL TO PREVENT POWER FROM...
Page 9
Figure 7 Duct Cover Installation 10. Slide glass canopy onto the blower system. Secure glass on the top of range hood with 4 (M5 x 20) screws and 4 washers (provided). (Figure 5) 11. Slide duct cover onto the blower unit, secure underneath the blower unit with 4 (M8) nuts and 4 washers (provided).
OPERATION INSTRUCTIONS This KOBE hood is equipped with five touch buttons, double horizontal squirrel cages with stainless steel filter, and four bright 12-volt /20-watt halogen lights. The five touch buttons are Power Control (On/Off), Speed Control (High, Medium, & Low), and Light Control.
MAINTENANCE SAFETY WARNING NEVER PUT YOUR HAND INTO AREA HOUSING THE FAN WHILE THE FAN IS OPERATING. CAUTION NEVER USE ABRASIVE CLEANERS, PADS, OR CLOTHS. DO NOT USE PAPER TOWEL ON STAINLESS STEEL. For optimal operation, clean range hood and all baffle/spacer/filter/oil tunnel/oil container regularly. *** Regular care will help preserve the appearance of the hood.
Page 12
To Replace Halogen Light Bulbs CAUTION: HALOGEN LIGHT UNIT MAY BE HOT! WAIT UNTIL UNIT IS COOL. NOTE: DO NOT TOUCH HALOGEN LIGHT WITH BARE HANDS, WHICH MIGHT CAUSE OVER HEAT AND SHORTEN THE LIFT OF LIGHT BULBS. 1. Make sure all controls are OFF, and range hood is unplugged. 2.
MEASUREMENTS & DIAGRAMS All ( ) measurements are in millimeter. All inch measurements are converted from millimeter. Inch measurements are estimated. ***Mounting Template...
Trouble Shooting Issue Possible Cause Solution After Installation, The power is not on. Make sure the circuit breaker and the unit’s power is both motors and ON. Use a voltage meter to check the power supply. lights are not The wire connection is not secure. Check and tighten wire connection.
2. PLEASE INSPECT CONTENTS OF PACKAGE(S) CAREFULLY UPON RECEIVING! We must be notified in writing of any damages and/or missing parts within the allocated days upon your receipt of package(s). Contact your local KOBE dealer or distributor or call KOBE for the time limit.
Any covered failure occurring within one years of original purchase arising from defective workmanship or material in manufacture will be, at our discretion, replaced free of charge by KOBE Range Hoods as applicable. Keep proof of purchase (or original invoice) handy for inspection.
Page 21
Some states do not allow limitations on the duration of implied warranties. This warranty gives you specific legal rights, and may also have rights, which vary from state to state. SERVICE For service contact: KOBE Range Hoods 11775 Clark Street Arcadia, CA 91006 U.S.A.
Any covered failure occurring within one years of original purchase arising from defective workmanship or material in manufacture will be, at our discretion, replaced free of charge by KOBE Range Hoods as applicable. Keep proof of purchase (original invoice) handy for inspection.
Page 23
Arcadia, CA 91006 http://www.KOBERangeHoods.com This KOBE hood is made for use in the USA and CANADA only. We do not recommend using this hood overseas as the power supply may not be compatible and may violate the electrical code of that country. Using a KOBE hood overseas is at your own risk and will void your warranty.
Page 24
Hotte de cuisine de marque KOBE Modèles No. IS2036GS IS2042GS SÉRIES IS-20 «ISLAND GLASS CANOPY» INSTRUCTIONS D’INSTALLATION ET MANUEL D’OPÉRATION...
Page 25
- LIRE ET CONSERVER CES INSTRUCTIONS - CONTENU DIRECTIVES DE SÉCURITÉ IMPORTANTES............. 25 COMPOSANTS DE L’EMBALLAGE ................27 INSTALLATION......................28 MODE D’EMPLOI......................32 ENTRETIEN........................33 SPÉCIFICATIONS......................35 DIMENSIONS ET SCHÉMAS ..................36 LISTE DE PIÈCES ......................37 SCHÉMA DE CIRCUITS ....................39 TROUBLE SHOOTING ....................
KOBE RANGE HOODS annulera automatiquement la garantie. KOBE RANGE HOODS ne sera pas tenu responsable de tous dommages à la propriété personnelle ou aux biens immeubles ou de toutes blessures corporelles causées directement ou indirectement par la hotte de cuisine.
Page 27
Que faire en cas d’incendie de graisse sur la cuisinière ÉTOUFFEZ LES FLAMMES avec un couvercle de bonne grandeur, une tôle à biscuits, ou un plateau en métal, puis fermez le brûleur. GARDEZ LES MATÉRIAUX INFLAMMABLES OU COMBUSTIBLES LOIN DES FLAMMES. Si les flammes ne s’éteignent pas immédiatement, ÉVACUEZ L’ENDROIT ET APPELEZ LE SERVICE D’INCENDIE ou le 911.
COMPOSANTS DE L’EMBALLAGE (Garder tous les matériaux pour retours ou remboursements) Boîte 1 de 3 Boîte 2 de 3 {A} Hotte de cuisine KOBE {B} Carte d’enregistrement de garantie {F} Garniture en verre – 1 {C} Manuel d’instruction {D} Filtre en acier inoxydable – 1 {E} Collerette en acier inoxydable–...
INSTALLATION VEUILLEZ LIRE LES INSTRUCTIONS AU COMPLET AVANT DE DÉBUTER Calculs avant l’installation Pour faire les calculs avant l’installation, veuillez vous référer au TABLEAU 1. (Tous les calculs sont en pouces.) TABLEAU 1 A = Hauteur du plancher au plafond B = Hauteur du plancher au dessus du comptoir (Standard : 36") C = Hauteur préférée du dessus du comptoir au...
Page 30
Figure 1 Préparation avant l’installation REMARQUE : AFIN D’ÉVITER TOUS DOMMAGES À VOTRE HOTTE, EMPÊCHEZ LES DÉBRIS D’ENTRER DANS L’ORIFICE DE VENTILATION Choisissez l’endroit de la canalisation de ventilation à partir de la hotte jusqu’à l’extérieur. (Figure 1) Une longueur courte et droite permettra à...
Page 31
Figure 4 5. Alignez le gabarit d’assemblage avec les marques au plafond et fixez en place avec du ruban adhésif. Coupez une ouverture de 6-1/4” pour le conduit et un trou d’environ 1” pour faire passer le câblage. Percez des trous pour les 6 vis de montage tel qu’indiqué...
Page 32
Figure 7 REMARQUE : Placez le conduit de canalisation rond de 6” sur le clapet. Scellez avec du ruban à conduits afin de que les joints soient isolés de façon sécuritaire. REMARQUE : ASSUREZ-VOUS QUE LES ABATTANTS SUR LE CLAPET PUISSENT OUVRIR ET FERMER LIBREMENT.
MODE D’EMPLOI Cette hotte KOBE est munie de cinq touches, de doubles cages écureuil horizontales avec filtre en acier inoxydable, et de 4 lampes halogènes claires 12V/20W. Les cinq touches sont Commande d’alimentation (Marche/Arrêt), Commande de vitesse (Élevée, Moyenne, et Basse) et Commande des lumières.
ENTRETIEN AVERTISSEMENT DE SÉCURITÉ NE JAMAIS METTRE LA MAIN DANS L’EMPLACEMENT QUI CONTIENT LE VENTILATEUR LORSQUE LE VENTILATEUR EST EN MARCHE. Nettoyage de la surface de la hotte MISE EN GARDE : NE JAMAIS UTILISER DE NETTOYANTS, DE TAMPONS OU DE LINGES ABRASIFS. Pour une opération optimale, nettoyez régulièrement la hotte de cuisine et tous les déflecteurs/espacements/filtres/tunnels d’huile/contenants d’huile.
Page 35
Pour remplacer les ampoules de lampe halogène MISE EN GARDE : LA LAMPE HALOGÈNE PEUT ÊTRE TRÈS CHAUDE ! ATTENDEZ QU’ELLE REFROIDISSE. REMARQUE : NE TOUCHEZ PAS À LA LAMPE HALOGÈNE AVEC LES MAINS NUES, CECI POURRAIT CAUSER UNE SURCHAUFFE ET RACCOURCIR LA DURÉE DE VIE DES AMPOULES.
DIMENSIONS ET SCHÉMAS Toutes ( ) les dimensions sont en millimètres. Toutes les dimensions en pouces sont converties à partir de millimètres. Les dimensions en pouces sont estimatives. ***Gabarit d’assemblage...
Trouble Shooting Solution Problème Cause probable Après Pas d’alimentation électrique. Assurez- Utilisez un voltmètre pour vérifier l’alimentation l’installation, vous que le disjoncteur et que en électricité. les deux l’alimentation électrique moteurs et soient en marche. les lumières ne Le câblage n’est pas bien installé. Vérifiez et serrez les connexions de fils.
Page 42
La canalisation est plus petite que la Changez la canalisation en accord avec les canalisation suggérée. suggestions du fabricant. De l’air froid La connexion du conduit n’est pas Vérifiez l’installation du conduit. entre dans la scellée correctement. maison. Le clapet n’est pas bien installé ou Vérifiez l’installation du clapet.
Nous devons être avertis par écrit de tous dommages et/ou pièces manquantes en dedans du nombre de jours alloué à partir de la date de réception de votre (vos) emballage(s). Communiquez avec votre fournisseur ou distributeur KOBE ou appelez KOBE pour la limite de temps.
; iii) installé, entretenu ou opéré avec un non-respect des instructions fournies par KOBE Range Hoods y compris l’utilisation de détergents, de javellisant ou de nettoyants non appropriés.
Page 45
KOBE Range Hoods selon le cas, pour tous frais de déplacement et coûts de transport pour la hotte de cuisine ou les pièces vers et à partir du détaillant ou de l’agent de service.
(à notre propre discrétion) sans frais par un agent autorisé de INFORMATION KOBE Range Hoods ou KOBE Range Hoods selon le cas. Gardez une preuve d’achat (ou la facture originale) sous la main pour inspection. Si la hotte de cuisine est vendue par l’acheteur original durant la période de garantie, le nouveau propriétaire est protégé...
Page 47
Nous ne recommandons pas l’utilisation de cette hotte outremer puisque l’alimentation électrique peut ne pas être compatible et peut enfreindre le code d’électricité de ce pays. Utiliser une hotte KOBE outremer est à vos propres risques et annulera la garantie.
Page 48
Campana de Extracción KOBE Modelo No. IS2036GS IS2042GS SERIE IS-20 “CAMPANA DE VIDRIO DE ISLA” INSTRUCCIONES DE INSTALACIÓN Y MANUAL DE OPERACIÓN...
Page 49
- LEA Y CONSERVE ESTAS INSTRUCCIONES - CONTENIDO INSTRUCCIONES IMPORTANTES DE SEGURIDAD ..........50 COMPONENTES DEL PAQUETE................. 52 INSTALACIÓN....................... 53 INSTRUCCIONES DE OPERACIÓN ................57 MANTENIMIENTO ......................58 ESPECIFICACIONES ....................60 MEDIDAS Y DIAGRAMAS .................... 61 LISTADO DE PIEZAS ....................62 DIAGRAMA DE CIRCUITO ...................
KOBE RANGE HOODS anulará la garantía automáticamente. KOBE RANGE HOODS no se hará responsable por cualquier daño a la propiedad personal o inmobiliario ni por las lesiones físicas que se hayan causado ya sea directa o indirectamente por la campana de extracción.
Page 51
Qué Hacer en Caso de un Incendio Causado por la Grasa Acumulada en las Hornillas de la Estufa • SOFOQUE LAS LLAMAS con una tapadera, una bandeja para hornear galletas o una bandeja de metal que quede bien ajustada y luego apague la hornilla. MANTENGA TODO EL MATERIAL INFLAMABLE O COMBUSTIBLE LEJOS DE LAS LLAMAS.
(Debe conservar todo el material en caso de devolverlo o solicitar un reembolso) Caja 1 de 3 Caja 2 de 3 {A} Campana de Extracción KOBE {F} Campana de Vidrio - 1 {B} Tarjeta de Registro para Garantía {C} Manual de Instrucciones...
INSTALACIÓN POR FAVOR, LEA LAS INSTRUCCIONES COMPLETAMENTE ANTES DE CONTINUAR Cálculo antes de la Instalación Para realizar el cálculo para la instalación, por favor consulte la TABLA 1. (Todos los cálculos están hechos en pulgadas). TABLA 1 A = Altura del Piso al Techo B = Altura del Piso a la Superficie del Mostrador (Estándar: 36") C = Altura Preferida de la Superficie del...
Page 54
Preparación antes de la Instalación Figura 1 NOTA: PARA EVITAR CAUSAR DAÑOS A SU CAMPANA, EVITE QUE DESECHOS Tubo Redondo de 6” PENETREN RENDIJA VENTILACIÓN Decida la ubicación para colocar el conducto de ventilación de la campana Campana Codo Redondo Cubierta de Conductos hacia el exterior.
Page 55
tornillos de montaje, según lo indica la Figura 4 plantilla. 6. Alinee el soporte de montaje con los agujeros perforados en el techo y fije las vigas y entramado utilizando 6 tornillos (no proporcionados). Asegúrese que los tornillos penetren en el centro de las vigas y entramado para brindar un soporte máximo.
Page 56
ABRIRSE CERRARSE Figura 7 PROBLEMAS. (Figura 6) Instalación de la Cubierta de Conductos 10. Deslice la campana de vidrio en el sistema del ventilador. Fije el vidrio en la parte superior de la campana de extracción utilizando 4 tornillos (M5 x 20) y 4 arandelas (proporcionados) (Figura 5) 11.
INSTRUCCIONES DE OPERACIÓN Esta campana de extracción KOBE está equipada con cinco botones táctiles, jaulas de ardilla horizontales dobles con filtro de acero inoxidable y cuatro focos brillantes de halógeno de 12- voltios/20vatios. Los cinco botones táctiles son: Control Encendido/Apagado, Control de Velocidad (Alto, Medio y Bajo) y Control de Luz.
MANTENIMIENTO ADVERTENCIA DE SEGURIDAD NUNCA COLOQUE SUS MANOS DENTRO DE LA CAJA DEL VENTILADOR MIENTRAS ESTE SE ENCUENTRE FUNCIONADO. PRECAUCIÓN: NUNCA UTILICE LIMPIADORES, ALMOHADILLAS PAÑOS ABRASIVOS. NO UTILICE TOALLAS DE PAPEL SOBRE EL ACERO INOXIDABLE. Para funcionamiento óptimo, limpie campana extracción todos deflectores/separadores/filtros/conductos de aceite/recipientes para aceite con regularidad.
Page 59
Para Reemplazar los Focos de la Lámpara de Halógeno PRECAUCIÓN: ¡LA UNIDAD DE LA LÁMPARA DE HALÓGENO PODRÍA ESTAR CALIENTE! ESPERE HASTA QUE SE ENFRÍE NOTA: NO TOQUE LA LÁMPARA DE HALÓGENO CON LAS MANOS DESPROTEGIDAS, PUES PODRÍA CAUSAR SOBRECALENTAMIENTO Y REDUCIR EL TIEMPO DE VIDA DE LOS FOCOS. Halogen Light Glass Cover = Cubierta de Vidrio de la Lámpara de Halógeno Halogen Light Housing = Carcasa de la Lámpara de Halógeno Flat-headed screwdriver = Destornillador de Cabeza Plana...
MEDIDAS Y DIAGRAMAS Todas las medidas ( ) están en milímetros. Todas las medidas en pulgadas han sido convertidas de milímetros. Las medidas en pulgadas son medidas aproximadas. *** Plantilla de Montaje Parte Frontal de la Campana...
Filtro de Acero Inoxidable ISL120-20 Lámpara de Halógeno ISL120-21 Unidad de Control ISL120-22 Cubierta de la Unidad de Control ISL120-23 Caja 2 de 3 MODELO NO. IS2036GS / IS2042GS (Vidrio) DESCRIPCIÓN MODELO PIEZA NO. Campana de Vidrio IS2036GS ISL120-18 IS2042GS ISL120-18-1 (Caja 3 de 3) ARTICULO NO.
Page 63
MODELO IS2036GS NO.: IS2042GS KIT DE RECIRCULACIÓN Artículo No. RD-0020 (Vendidos por Separado)
DIAGRAMA DE CIRCUITO MODELO IS2036GS NO.: IS2042GS Transformador Panel de Panel de Potencia Interruptor Blue = Azul Brown = Café Red = Rojo Black = Negro Green = Verde Yellow = Amarillo Orange = Naranja White = Blanco...
Guía para la Solución de Problemas Problema Posible Causa Solución Después de la No está encendido. Asegúrese que el interruptor de circuitos y la Instalación, unidad se encuentren encendidos. Utilice un ninguno de los medidor de voltaje para verificar la energía de motores ni las entrada.
Se nos deberá notificar por escrito sobre cualquier daño y/o piezas faltantes dentro del periodo de días establecidos luego de haber recibido su paquete(s). Contacte a su distribuidor o concesionario KOBE o llame a KOBE para obtener información sobre el límite de tiempo. RECLAMOS SERÁN...
KOBE Range Hoods incluyendo el uso inadecuado de detergentes, blanqueadores o limpiadores. por daños causados a la campana de extracción durante su transporte, entrega, instalación o al quitarla;...
Page 68
Agente autorizado de KOBE Range Hoods más cercano según corresponda, así como de cualquier gasto de viaje y cualquier costo de transporte de la campana de extracción y piezas desde y hacia el concesionario y Agente de Servicio.
Consulte la sección de la garantía para obtener la información completa sobre la cobertura de la garantía. Este aparato ha sido fabricado, sometido a pruebas e inspeccionado según los estándares requeridos por KOBE Range Hoods. POR FAVOR, ENVÍE POR CORREO SU TARJETA DE REGISTRO DE GARANTÍA Y EL COMPROBANTE DE COMPRA A:...
Page 70
Utilizar una campana KOBE en el extranjero será a su propio riesgo y anulará la garantía.
