Handset Z-3040 for Coral FlexAir Systems
User's Guide

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the KIRK Z-3040 and is the answer not in the manual?

Questions and answers

Related Manuals for Kirk KIRK Z-3040

Summary of Contents for Kirk KIRK Z-3040

  • Page 1 Handset Z-3040 for Coral FlexAir Systems User’s Guide...

  • Page 2: Table Of Contents

    Congratulations on your new KIRK Z-3040 handset The handset KIRK Z-3040 will provide you with the greatest possible degree of flexibility and mobility due to high battery capacity, practical weight, size and design. Contents: 1. Construction ................4 8.5.1 Create subscription ..........22 2.

  • Page 3: Construction

    MENU key Display with backlight 1. Construction Left arrow key, Redial menu Key for internal calls from standby text (not used on KIRK dect-z system 1500) Keyboard LOCK (Menu*) Headset Connector (ACS Stratus Ultra) Right arrow key, save number. Telephone book menu from Recall key standby text (MAIL key)

  • Page 4: Charging

    3. Charging It takes approximately 3 1/2 hours to charge the handset from fully discharged to its full capacity. Place the hand- set in the charger. The display shows the charging status in line 3. For correct charging the room temperature has to be between 0°C and 25°C and the handset must therefore not be placed in direct sunshine.

  • Page 5: Turning The Handset On/Off

    “INT” -If residential systems: Internal calls off hook, and internal recall if already offhook. (not used on KIRK dect-z systems 1500 and 500) “R” - If offhook: Recall. If onhook: Read message. “ ” - On hook/off hook and turn ON. ”...

  • Page 6: Making A Call

    6. Making a call For making or receiving calls the handset has to be subscribed to a system ( shown in display) (see chap. 8.5.1) Press the -key, the -icon in the display will flash until connection is established Dial the number Pre-dial: Press the number to dial (long press on »...

  • Page 7: Receiving Calls

    6.1. Receiving calls If the phone rings, the call can be answered by pressing the -key. When ringing the LED flashes fast, and the display shows the CLIP (if presented). If it is an external call (or if no CLIP) the display shows “INCOMING CALL” It is possible to stop the ring signal without answering the call.

  • Page 8: Set Ups

    7. Set ups The handset has two user-defined profiles (set ups), and a mode where all sounds are disabled (SILENT). Pres- sing “MENU” followed by “OK ” will show the chosen profile. A new profile can be selected by using the arrow keys. To select the chosen profile press “OK ”.

  • Page 9: Using The Alphanumeric Keyboard

    8.1 Using the alphanumeric keyboard The normal dialling keys (0-9) are used for writing the name to be placed in the telephone book. By pressing the keys a certain number of times the related letters or digits will appear in the display. Spaces are made by using the 0-key.

  • Page 10: Profile Set Up

    8.3 Profile set-up In the following you will find a description of how to set up one of the 2 profiles. To enter the Profile Setup menu press “MENU”. Then press “OK ” and use > or < to find the profile you wish to change and confirm with “OK”. You are now able to switch between the different settings.

  • Page 11: Profile Functions

    8.4 Profile functions : Can be turned on/off using the > and <. Confirm with (OK ). ACKLIGHT : Scroll through the 9 different ringertones using > and <. Confirm with (OK ). INGERTONE : Turn the volume up and down using > or <. Confirm with (OK ). INGER VOL : Turn the volume up and down using the >...

  • Page 12: Create Subscription

    8.5.1 Create subscription To make subscriptions, the system must allow subscriptions to be made. Some systems also require an Access Code (AC). If more than one system currently permits subscription, you will need to know the ID of the system to which you wish to subscribe.

  • Page 13: Auto Login

    8.5.5 Change startup text The startup text is predefined as i.e. ”KIRK telecom” as factory default. This can be changed by using the following procedure: Press , BOOK, (OK) and give in the new startup text by the keyboard followed by (OK). It is pos- **** sible to give in 24 characters.

  • Page 14: Battery

    8.6 Battery capacity In the battery menu it is possible to see the remaining battery capacity. For reading the correct capacity, the hand- set has to be removed from the charger for at least one hour. Press “Menu” and use the > or < keys to reach the Battery Menu.

  • Page 15: Book

    After storing the telephone will go back to standby mode. If the display shows “MEMORY FULL”, it is necessary to delete one or KIRK TELECOM more numbers from the telephone book. (See menu structure page 30)

  • Page 16: External Services

    (using 1-9)(see chap. 8.2). Call the displayed person by pressing the key. It is also possible to reach the telephone book menu in the main menu. Viewing and editing the telephone book can also be done while in conversation. BOOK KIRK TELECOM > bILL JENSEN CARL NIELSEN PHILIP...

  • Page 17: Msf Functions

    8.10 MSF Functions MSF Functions are special functions, which are based on MSF (Message Service Function). The functions require special software in the main system. 8.11 Mail/Text Messages Available in systems configured with the possibility of sending text messages At the reception of a text message the envelope icon appears in the display.
  • Page 18 Read a mail Press the ”R”- (MAIL) key followed by the OK-key or enter the mail menu (in on hook condition). If the message includes more than 36 letters or digits, the message will run over 2 display screens. Use the > -key to scroll. To see the sender of the mail, press the OK-key. To leave the mail, press the MENU-key. Reply a mail Open the mail by pressing the R-key followed by the OK-key, press the OK-key again and use the <...

  • Page 19: Menu Language

    Menu structure KIRK telecom MAIL N25-01 04.38 L26-01 14.32 N28-01 15.46 WRITE NEW √19-01 09.56 √20-01 10.13 MAIL? htj@kirktelec Temp 45° .. Hello, its me.. FIRE ALARM.. I am working.. Call me.. Meet me at 9 .. Hello it’s me.

  • Page 20: Shortcuts

    9. Shortcuts ”PROFILE 1”: Press: MENU 1. ”PROFILE 2”: Press: MENU 2. (Display shows PROFILE 2) ”SILENT”: Press: MENU #. (No sounds) (Display shows SILENT) ”KEY LOCKED”: Press: MENU . (Display shows KEY LOCKED) “PHONE BOOK”: Press >(BOOK) key in standby. Name search in telephone book: Press the first letter in name and >...

  • Page 21: Error Information

    10.2 Error information Improper function of the handset might be related to the installation of the DECT system or failures related to the main system. Before declaring a handset for repair be sure that the main system is operating properly. 10.3 Warranty The handset is covered by a normal warranty-solution, except the battery.
