KIRK 4020 and KIRK 4040 1.9 GHz
User s Guide

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 4020 and is the answer not in the manual?

Questions and answers

Related Manuals for Kirk 4020

Summary of Contents for Kirk 4020

  • Page 1 KIRK 4020 and KIRK 4040 1.9 GHz User s Guide...

  • Page 2: Table Of Contents

    Congratulations on your new KIRK handset Your new handset from KIRK telecom will provide you with the greatest possible degree of flexibility and mobility due to high battery capa c i t y, low weight, practical size and design. Contents : 7.5.3 Auto login .

  • Page 3: Construction

    (only KIRK 4040) MENU key L e ft arrow key, Redial Menu Key for internal calls from standby text (not used on KIRK Wireless Server) Loud speaking (only KIRK 4040) Alarm key Keyboard LOCK (Menu*) Right arrow key, save number.

  • Page 4: Charging

    LED flashes at a low frequency while charging and lights constantly when the charging is finished. The display goes back to normal mode when fully charged. KIRK telecom zzzzzzzzz ..When the handset is placed in the charger it will not vibrate, and B-answer is inactive. If the battery is fully dischar- ged, up to 10 min.

  • Page 5: Turning The Handset On/Off

    - I f o ff hook: Recall. If on hook: Read or write message - On hook/off hook and turn ON - * (Change from pulse to DTMF on KIRK Wireless Server), Long = pause (-), extra long: change from pulse to DTMF (a T appears in the display, GAP s tandard)

  • Page 6: Making A Call

    - i c o n w i l l f l a s h u n t i l t h e c o n n e c t i o n i s e s tablished. Using the handset in residential systems: (not on KIRK Wireless Server)

  • Page 7: Receiving Calls

    Please note: If the Date and Time function is supported, then date and time of the incoming or outgoing call is shown in the CLIP/Redial stack on the 4th line of the display. See Chap. 8 for more information. Speed dial: See Chap.

  • Page 8: Menu Structure

    Pressing the 3-key, jumps to a lower level in the menu. When the lowest menu level is reached, it will store the set- ting and jump to a higher level. It has to be used if a YES is wanted. KIRK telecom M E N U...

  • Page 9: The Key Functions

    7.2 The key functions Capita l l e t t e r Small letter ? ! 1 - + * / = & ( ) % ¿ ¡ ? ! 1 - + * / = & ( ) % ¿ ¡ A B C 2 ˜...

  • Page 10: Profile Set Up

    :Can be turned on/off using < and >. Confirm with 3. When turned on, the telephone automatically goes off A N S W E R hook when ringing. If subscribed to a KIRK solution it automatically goes on hook when calls are terminated. B-answ- er is inactive when handset is placed in the charger.

  • Page 11: Menu Subscription And Login

    :The out of range indication can be turned on/off using < and >. Confirm with 3. Wi t h t h e o u t o f U T O F R A N G E range indicator turned on, a beep will appear when the telephone is moving out of range of the base station, and OUT OF RANGE will appear in the display.

  • Page 12: Create Subscription

    7.5.1 Create subscription To make subscriptions, the system must allow subscriptions to be made. Some systems also require an Access Code (AC). If more than one system currently permits subscription, you will need to know the ID of the system to which you wish to subscribe.

  • Page 13: Auto Login

    7 . 5 . 3 Auto login The handset can be subscribed to 10 different systems. If a handset is subscribed to two or more systems, you can use Auto Login A to change between the systems auto- matically. The selected system is marked with an A . Please note: Auto login A should only be used in separate systems without overlaps.

  • Page 14: Remove Subscription

    7.5.5 Change startup text The startup text is predefined as e.g. KIRK telecom as factory default. This can be changed by using the following * * * * procedure: Press , BOOK, 3 and enter the new startup text using the keyboard followed by 3.

  • Page 15: Redial

    It is possible to edit the CLIP or REDIAL numbers. Find the number you wish to edit and press the digits you want to add to the number, e . g . p r e f i x = O . The Redial and CLIP s tack Menu (fig) KIRK telecom < BILL G ATES...

  • Page 16: Book

    A fter storing the telephone will go back to standby mode. If the display shows M E M O RY FULL , it is necessary to delete one or KIRK telecom more numbers from the telephone book.

  • Page 17: External Services

    External services are features placed in the main system, and only available if the handset is subscribed to a KIRK solution. Under External services can be found; View Clip St ack , Delete Clip St ack and Local Phone Book . The Local Phone Book is a common phone book for all handsets subscribed to the actual system, and all handsets subscribed to the system are listed in the phone book.

  • Page 18: Mail/Textmessages

    7 . 11 Mail/Text Messages Available in systems configured with the possibility of sending text messages At the reception of a text message the envelope icon appears in the display. The envelope icon is indicating one or more unread messages. The text message is shown in the display, and when the message is read the envelope icon will disappear.
  • Page 19 Press the 3-key, type the number of the receiver and confirm with the 3-key. The message is sent. Note In case a sent message is not received, the sender will get a message in the display. The Mail Menu (fig) KIRK telecom MAIL N25-01 04.38 L26-01 14.32 N28-01 15.46 WRITE NEW ›19-01 09.56...

  • Page 20: Speed Dial

    8. Date and Time Function The Date and Time function requires the use of a KIRK Wireless Server and special software in the main system. If the Date and Time function is supported, a clock is shown in the 2nd line of the display. The clock shows the time with an accuracy of +/- 1 minute.

  • Page 21: Language

    O N G K E Y MSF an MSF is sent to the KIRK Wireless Server when pressing 0,1,2...9 with a long key press or when pressing the alarm key with a long key press. When choosing SPEED DIAL a call is made to the assigned number when pressing 0,1,2...9 with a long key press or when pressing the alarm key with a long key press.
  • Page 22 When turned on and B-ANSWER ON (hands-free) is selected, the handset also turns on the loudspeaker automatically (see Chap. 7.4). (Loudspeaker only works on KIRK 4040). :Can be turned on/off using < and >. Confirm with 3. When turned off the display shows a local stand- TA N D B Y TEXT b y t e x t .

  • Page 23: Shortcuts

    11. Shortcuts KEY LOCKED : Press: MENU . (Display shows SILENT : Press: MENU #. (No sounds) (Display shows PHONE BOOK : Press > (BOOK) in standby Name search in telephone book: Press the first letter in name and > (BOOK) afterwards Store a number: Press >...

  • Page 24: Error Information

    12.2 Error information Improper function of the handset might be related to the installation of the KIRK solution or failures related to the main system. Before declaring a handset for repair be sure that the main system is operating properly.

  • Page 25: Important Safety Instructions And Product Information

    12.5 Important safety instructions and product information Before using your telephone equipment, you should always follow basic safety instruction to reduce the risk of fire, electrical shock and injury to persons, and damage to property. Read and understand all instructions Follow all warnings and instructions including those marked on the product Unplug this product before cleaning.
  • Page 26 13 Do not place the unit near microwave ovens, radio equipment, or non-ground connected televisions. These appliances may cause electrical interference to the base or handset 14 The unit must be installed on a hard, plane surface and connected to a functional 120 volt AC power netadapter and plug the adapter into the power outlet 15 The system will not operate in the event of a blackout.
  • Page 27 Users should ensure for their own protection that the electrical ground connections of the power utility, elephone lines and inter- nal metallic water pipe system, if present, are connected together. This precaution may be pa r t i c u l a r l y i m p o r ta n t i n r u r a l a r e a s . CAUTIONS: Users should not attempt to make such connections themselves, but should contact the appropriate electric inspe- ction authority, or electrician, as appropriate.
  • Page 28 Information to user: The users manual or instruction manual for an intentional or unintentional radiator shall caution the user that changes or modifications not expressly approved by the party responsible for compliance could void the user s a u t h o r i t y t o operate the equipment.
  • Page 29 THIS LIMITED WARRANTY IS IN LIEU OF ALL OTHER WARRANTIES EXPRESS OR IMPLIED. A N Y IMPLIED WARRANTIES INCLUDING BUT N O T LIMITED TO THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PA RTICU- LAR PURPOSE, SHALL BE LIMITED TO THE DURATION OF THIS WRITTEN LIMITED WARRANTY. WE DISCLAIM A N Y LIA- BILITY FOR DAMAGES FOR LOSS OF USE OF THE PRODUCTS, LOSS OF TIME, INCONVENIENCE, INJURY TO A N Y PERSON, OR DAMAGE TO PROPERTY CAUSED BY THE PRODUCT, LOSS OF REVENUE OR PROFIT OR DAMAGES FOR A N Y FAILURE TO PERFORM.

This manual is also suitable for:

4040
