Kirk Z-3040 User Manual

Hide thumbs Also See for Z-3040:
Table of Contents

Advertisement

Quick Links

Download this manual
Kirk Z-3040 håndsæt 14021600
26/03/03
9:35
Page 1
(Black/Process Black plate)
Handset Z-3040 for KIRK dect-z System 1500 and 500
User's Guide

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Z-3040 and is the answer not in the manual?

Questions and answers

Related Manuals for Kirk Z-3040

Summary of Contents for Kirk Z-3040

  • Page 1 Kirk Z-3040 håndsæt 14021600 26/03/03 9:35 Page 1 (Black/Process Black plate) Handset Z-3040 for KIRK dect-z System 1500 and 500 User’s Guide...

  • Page 2: Table Of Contents

    Page 2 (Black/Process Black plate) Congratulations on your new KIRK Z-3040 handset The handset KIRK Z-3040 will provide you with the greatest possible degree of flexibility and mobility due to high battery capacity, practical weight, size and design. Contents: 8.5.1 Create subscription ..........22 1.

  • Page 3: Construction

    Kirk Z-3040 håndsæt 14021600 26/03/03 9:35 Page 3 (Black/Process Black plate) MENU key Display with backlight 1. Construction Left arrow key, Redial menu Key for internal calls from standby text (not used on KIRK dect-z system 1500) Keyboard LOCK (Menu*)

  • Page 4: Charging

    Kirk Z-3040 håndsæt 14021600 26/03/03 9:35 Page 4 (Black/Process Black plate) 3. Charging It takes approximately 3 1/2 hours to charge the handset from fully discharged to its full capacity. Place the hand- set in the charger. The display shows the charging status in line 3. For correct charging the room temperature has to be between 0°C and 25°C and the handset must therefore not be placed in direct sunshine.

  • Page 5: Turning The Handset On/Off

    Kirk Z-3040 håndsæt 14021600 26/03/03 9:35 Page 5 (Black/Process Black plate) “INT” -If residential systems: Internal calls off hook, and internal recall if already offhook. (not used on KIRK dect-z systems 1500 and 500) “R” - If offhook: Recall. If onhook: Read message.

  • Page 6: Making A Call

    Kirk Z-3040 håndsæt 14021600 26/03/03 9:35 Page 6 (Black/Process Black plate) 6. Making a call For making or receiving calls the handset has to be subscribed to a system ( shown in display) (see chap. 8.5.1) Press the -key, the...

  • Page 7: Receiving Calls

    Kirk Z-3040 håndsæt 14021600 26/03/03 9:35 Page 7 (Black/Process Black plate) 6.1. Receiving calls If the phone rings, the call can be answered by pressing the -key. When ringing the LED flashes fast, and the display shows the CLIP (if presented). If it is an external call (or if no CLIP) the display shows “INCOMING CALL”...

  • Page 8: Set Ups

    Kirk Z-3040 håndsæt 14021600 26/03/03 9:35 Page 8 (Black/Process Black plate) 7. Set ups The handset has two user-defined profiles (set ups), and a mode where all sounds are disabled (SILENT). Pres- sing “MENU” followed by “ ” will show the chosen profile. A new profile can be selected by using the arrow keys.

  • Page 9: Using The Alphanumeric Keyboard

    Kirk Z-3040 håndsæt 14021600 26/03/03 9:35 Page 9 (Black/Process Black plate) 8.1 Using the alphanumeric keyboard The normal dialling keys (0-9) are used for writing the name to be placed in the telephone book. By pressing the keys a certain number of times the related letters or digits will appear in the display. Spaces are made by using the 0-key.

  • Page 10: Profile Set Up

    Kirk Z-3040 håndsæt 14021600 26/03/03 9:35 Page 10 (Black/Process Black plate) 8.3 Profile set-up In the following you will find a description of how to set up one of the 2 profiles. To enter the Profile Setup menu press “MENU”. Then press “ ” and use > or < to find the profile you wish to change and confirm with “ ”. You are now able to switch between the different settings.

  • Page 11: Profile Functions

    Kirk Z-3040 håndsæt 14021600 26/03/03 9:35 Page 11 (Black/Process Black plate) 8.4 Profile functions : Can be turned on/off using the > and <. Confirm with ( ). ACKLIGHT : Scroll through the 9 different ringertones using > and <. Confirm with ( ).

  • Page 12: Create Subscription

    Kirk Z-3040 håndsæt 14021600 26/03/03 9:35 Page 12 (Black/Process Black plate) 8.5.1 Create subscription To make subscriptions, the system must allow subscriptions to be made. Some systems also require an Access Code (AC). If more than one system currently permits subscription, you will need to know the ID of the system to which you wish to subscribe.

  • Page 13: Auto Login

    Kirk Z-3040 håndsæt 14021600 26/03/03 9:35 Page 13 (Black/Process Black plate) 8.5.3 Auto login The handset can be subscribed to 10 different systems. If Auto login is chosen from the menu, the handset auto- matically selects a system. The selected system is marked with an “A”.

  • Page 14: Battery

    Kirk Z-3040 håndsæt 14021600 26/03/03 9:35 Page 14 (Black/Process Black plate) 8.6 Battery capacity In the battery menu it is possible to see the remaining battery capacity. For reading the correct capacity, the hand- set has to be removed from the charger for at least one hour. Press “Menu” and use the > or < keys to reach the Battery Menu.

  • Page 15: Book

    Kirk Z-3040 håndsæt 14021600 26/03/03 9:35 Page 15 (Black/Process Black plate) The Redial and CLIP stack Menu (fig) KIRK < BILL GATES REDIAL CLIP 75602850 DELETE? STORE NO.? DELETE ALL? NAME: 8.8 Book Storing a number (max. 24 digits) in the telephone book is done by pressing the number to be stored (in on hook), then press the “>”- key followed by the “...

  • Page 16: External Services

    Kirk Z-3040 håndsæt 14021600 26/03/03 9:35 Page 16 (Black/Process Black plate) Read BOOK numbers: The telephone book is entered by pressing ”>”(book). For quick-search: press the first letter of the name (using 1-9)(see chap. 8.2). Call the displayed person by pressing the key.

  • Page 17: Msf Functions

    Kirk Z-3040 håndsæt 14021600 26/03/03 9:35 Page 17 (Black/Process Black plate) 8.10 MSF Functions MSF Functions are special functions, which are based on MSF (Message Service Function). The functions require special software in the main system. 8.11 Mail/Text Messages Available in systems configured with the possibility of sending text messages At the reception of a text message the envelope icon appears in the display.
  • Page 18 Kirk Z-3040 håndsæt 14021600 26/03/03 9:35 Page 18 (Black/Process Black plate) Read a mail Press the ”R”- (MAIL) key followed by the -key or enter the mail menu (in on hook condition). If the message includes more than 36 letters or digits, the message will run over 2 display screens.

  • Page 19: Menu Language

    Kirk Z-3040 håndsæt 14021600 26/03/03 9:35 Page 19 (Black/Process Black plate) Menu structure KIRK telecom MAIL N25-01 04.38 L26-01 14.32 N28-01 15.46 WRITE NEW √19-01 09.56 √20-01 10.13 MAIL? htj@kirktelec Temp 45° .. Hello, its me.. FIRE ALARM.. I am working..

  • Page 20: Shortcuts

    Kirk Z-3040 håndsæt 14021600 26/03/03 9:35 Page 20 (Black/Process Black plate) 9. Shortcuts ”PROFILE 1”: Press: MENU 1. ”PROFILE 2”: Press: MENU 2. (Display shows PROFILE 2) ”SILENT”: Press: MENU #. (No sounds) (Display shows SILENT) ”KEY LOCKED”: Press: MENU .

  • Page 21: Error Information

    Kirk Z-3040 håndsæt 14021600 26/03/03 9:35 Page 21 (Black/Process Black plate) 10.2 Error information Improper function of the handset might be related to the installation of the DECT system or failures related to the main system. Before declaring a handset for repair be sure that the main system is operating properly.
