- Page 1 Kirk Z-3020 håndsæt 14046900 25/10/00 14:56 Side 1 Handset Z-3020 for KIRK dect-z Systems 1500 and 500 User’s Guide...
-
Page 2: Table Of Contents
14:56 Side 2 Congratulations on your new KIRK Z-3020 handset The handset KIRK Z-3020 will provide you with the greatest possible degree of flexibility and mobility due to high battery capacity, practical weight, size and design. Contents: 8.1Profile set up............18 8.2 Profile functions ...........20... -
Page 3: Construction
Long key press turns OFF. 1.1 The display The KIRK Z-3020 handset is delivered with a 7-segment display architecture, making the telephone significantly more competitive when emphasising on device functionality and not on presentation texts. In a 7-segment display a few characters can be difficult to recognise, but in this User’s Guide all displays are depicted exactly as they are in the telephone display, enabling the user to get quickly accustomed to the use of the telephone. -
Page 4: Battery Installation
Kirk Z-3020 håndsæt 14046900 25/10/00 14:57 Side 4 2. Battery installation Before using the telephone you must connect the battery to the connector in the battery box. 1. Push the back cover 5 mm towards the bottom of the handset using your thumbs. -
Page 5: Key Functions
Kirk Z-3020 håndsæt 14046900 25/10/00 14:57 Side 5 It is necessary to recharge the battery when the battery icon is flashing, or if the handset can not be turned on. The LED flashes at a low frequency while charging and lights constantly when the charging is finished and the display goes back to normal mode. -
Page 6: Turning The Handset On/Off
- On hook/off hook and turn ON. “ ” - * (Change from pulse to DTMF on KIRK CCFP), Long = pause (-), extra long: change from pulse to DTMF (a “t” appears in the display, GAP standard). “0-9” - Digits. In book: finds incoded numbers. -
Page 7: Making A Call
Press the < -key (REDIAL-key) to see the redial number. Press the -key, for calling the redial number. Using the handset in residential systems: (not in a KIRK dect-z System 1500 or 500). Internal call post-dial: Press the INT-key, the -icon in the display will be shown. -
Page 8: Receiving A Call
Kirk Z-3020 håndsæt 14046900 25/10/00 14:57 Side 8 6.1. Receiving calls When receiving a call, it is answered by pressing the -key. During ringing the LED flashes fast, and the display shows the number that is calling. If there is no caller ID the display shows “ringing”. -
Page 9: Settings
Kirk Z-3020 håndsæt 14046900 25/10/00 14:57 Side 9 7. Settings The handset has two profiles (setups). A user-defined mode, and a mode where all sounds are disabled (key click and ringer tone). Pressing “MENU” followed by # will place the handset in the silent mode (display will show Press MENU and # again for disabling the silent mode. -
Page 10: Profile Setup
Kirk Z-3020 håndsæt 14046900 25/10/00 14:58 Side 10 8.1 Profile Setup In the following you will find a description on how to set up your profile. To enter the profile setup menu press “MENU” followed by “”. Press “” when you find the setting you wish to change or check upon. -
Page 11: Profile Functions
Kirk Z-3020 håndsæt 14046900 25/10/00 14:58 Side 11 8.2 Profile Functions Ringertone: Scroll through the 9 different ringer tones using < and >. Confirm with (). Ringer Vol: Turn the volume up and down using < or >. Confirm with (). -
Page 12: Create Subscription
Kirk Z-3020 håndsæt 14046900 25/10/00 14:58 Side 12 8.3.1 Create subscription To create subscriptions, the system must allow subscriptions to be created. Some systems requires an Access Code (AC). If more than one system currently permits subscription, you will need to know the ID of the sys- tem to which you wish to subscribe. -
Page 13: Battery Capacity
Kirk Z-3020 håndsæt 14046900 25/10/00 14:58 Side 13 8.4 Battery capacity In the battery menu it is possible to see the remaining battery capacity. For reading the correct capacity, the hand- set has to be removed from the charger for at least one hour. Press “MENU” and use the < or > keys to reach the Battery Menu. -
Page 14: Book
Kirk Z-3020 håndsæt 14046900 25/10/00 14:59 Side 14 8.6 Book Storing a number (max 24 digits) in the telephone book is done by pressing the number to be stored (in on hook), then press the “>”-key followed by the “”-key. The book can store up to 10 numbers. The position (0-9) is dis- played in the right side of the display if the number has less than 11 digits. -
Page 15: Shortcuts
Kirk Z-3020 håndsæt 14046900 25/10/00 14:59 Side 15 9. Shortcuts “SILENT”: Press: MENU and #. (No sounds) (Display shows “KEY LOCKED”: Press: MENU and . (Display shows MUTE temporarily the ringer: Press “” (MUTE) when the telephone is ringing. MUTE the microphone: Press “”... -
Page 16: Error Information
Kirk Z-3020 håndsæt 14046900 25/10/00 14:59 Side 16 10.2 Error information Improper function of the handset might be related to the installation of the DECT system or failures related to the main system. Before declaring a handset for repair be sure that the main system is operating properly.
