- Page 1 NFORMATION RACKING YSTEM GL300A USER MANUAL Version 1 ● 20 March 2019 Software Company Ltd. Address: 11 Magnaurska Shkola str., 3 floor, office 316,1754 Sofia, Bulgaria, Email: nikolay_palov@novotika.com, Website: www.novotika.com...
-
Page 2: Table Of Contents
Information Tracking System GL300A User Manual.docx Table of Contents Introduction ........................5 1.1. Purpose and Scope ....................5 1.2. Document Overview ....................5 1.3. Definitions, Acronyms and Abbreviations .............. 5 1.4. Contacts: ........................6 Product Overview ......................6 2.1. Appearance ....................... 7 2.2. - Page 3 Information Tracking System GL300A User Manual.docx 4.11. From the section Position Related Report/Fixed Report Information choose Fixed Timing Report and the corresponding time interval in seconds (600)....17 4.12. Exit and Apply settings to device – ‘Send Command’: ........17 4.13.
- Page 4 Information Tracking System GL300A User Manual.docx Document History Paper copies are valid only on the day they are printed. Contact the author if you are in any doubt about the accuracy of this document. Revision History This document has been revised by:...
-
Page 5: Introduction
Specifications document given with “Project MC5.01/15B – Support to Southern African States in Nuclear Safety and Safeguards. INSC/2016/379-139.”. The GPS locator GL300A is perfectly fit for monitoring a multitude of temporarily- dispatched, outsourced vehicles and containers in logistics industry. Its main advantages are ultra-long standby time with large-capacity internal battery and low power consumption. -
Page 6: Contacts
Information Tracking System GL300A User Manual.docx 1.4. Contacts: Manager: Mr. Nikolay Palov – Software Company Ltd. Head Office: 11 Magnaurska Shkola str., 3 floor, office 316, 1754 Sofia, Bulgaria Mobile: (+359) 88 866 7888 Email: nikolay_palov@novotika.com System administrator: Mr. Emil Stoyanov – Software Company Ltd. -
Page 7: Product Overview
Information Tracking System GL300A User Manual.docx 2. Product Overview 2.1. Appearance Figure 1: GL300A Main views 2.2. Parts List Item Description GL300A Locator 151*74*34.5 mm Micro USB 5Pin Cable 1.2M (Optional) GL300A Adapter © Software Company Ltd. P a g e... -
Page 8: Button, Usb And Gps Interface
Information Tracking System GL300A User Manual.docx External GPS Active Antenna (Optional) GL300A Magnet Set (Optional) Table 1: Parts 2.3. Button, USB and GPS Interface Figure 3: Micro USB and GPS Figure 2: Power ON Button © Software Company Ltd. P a g e... -
Page 9: Led
Information Tracking System GL300A User Manual.docx 2.4. LED There are seven LED lights. The two in the first row are Cell and GPS lights, which indicate GSM and GPS signals. In the second row, there are five power lights indicating the power Figure 4: Display LED 2.5. -
Page 10: Getting Started
Information Tracking System GL300A User Manual.docx 3. Getting Started 3.1. Open the External SIM Card Holder Figure 6: External SIM Card holder Remove the screws with a screwdriver first and then remove the SIM card cover to open the SIM card holder. -
Page 11: Install A Sim Card
Information Tracking System GL300A User Manual.docx 3.2. Install a SIM Card Insert the SIM card and move the toggle switch to the ON position. Figure 7: Add SIM Card 3.3. Power on the Device Put the case back in place and fix it with screws. Press the power-on button to turn the device on. -
Page 12: Device's Led Status
Information Tracking System GL300A User Manual.docx 3.4. Device’s LED Status Device Status Led Status The device is searching network. Fast flashing Slow flashing The device has been registered to Cell (Green) network. SIM card needs pin code to unlock. GPS chip is powered off. -
Page 13: Tracker Connection Steps
Information Tracking System GL300A User Manual.docx 4. Tracker Connection Steps Follow the steps to connect GPS Device to existing mobile network using genuine device drivers. 4.1. Remove the PIN from the SIM card. 4.2. Install the SIM card. 4.3. Turn the switch next to the SIM card slot to ON position. - Page 14 Information Tracking System GL300A User Manual.docx © Software Company Ltd. 14 | P a g e...
-
Page 15: Fill Appropriated Values For Apn Settings, Username And Password For Selected Mobile Network
Information Tracking System GL300A User Manual.docx 4.9. Fill in appropriate values for APN settings, Username and Password for selected mobile network: See Appendix B. © Software Company Ltd. 15 | P a g e... -
Page 16: Tracker Settings
Information Tracking System GL300A User Manual.docx 4.10. Tracker settings: Server: istc.novotika.com; Port 5004; Mode: TCP Short preferred. © Software Company Ltd. 16 | P a g e... -
Page 17: From The Section Position Related Report/Fixed Report Information Choose Fixed Timing Report And The Corresponding Time Interval In Seconds (600)
Information Tracking System GL300A User Manual.docx 4.11. From the section Position Related Report/Fixed Report Information choose Fixed Timing Report and the corresponding time interval in seconds (600). 4.12. Apply and Exit settings to device – ‘Send Command’: 4.13. Register GPS devices: ... -
Page 18: Troubleshooting And Safety Information
The SIM card is not inserted. Please insert the SIM card into GL300A. After GL300A is The signal is too weak; Please move GL300A to a place with good turned on, the GSM LED always GL300A cannot be registered cell coverage. -
Page 19: Safety Information
Information Tracking System GL300A User Manual.docx 5.2. Safety Information: Please do not disassemble the device by yourself’ Please do not put the device in overheated or too humid place, and avoid exposure to direct sunlight. Too high temperature will damage the device or even cause battery explosion. -
Page 20: Appendices
Information Tracking System GL300A User Manual.docx 6. Appendices 6.1. Appendix A: Definitions, Acronyms, and Abbreviations Term Meaning Global Positioning System Access Point Name Information Tracking System Software Company Ltd. 6.2. Appendix B: Mobile Operators, APN, Usernames, and Passwords by countries... - Page 21 Information Tracking System GL300A User Manual.docx Lacell APN: internet; username: not set; password: not set; G-Expresso APN: internet; username: not set; password: not set; Vodacom Tanzania APN: internet; username: not set; password: not set; Tigo Tanzania APN: tigoweb; username: not set;...
