Quadra-Fire 7100FP-BK-B Owner's Manual
Epa certified woodburning fireplace
Hide thumbs
Also See for 7100FP-BK-B:
- Owner's manual (72 pages) ,
- Owner's manual (75 pages) ,
- Installation manual (48 pages)
Table of Contents
Advertisement
Quick Links
INSTALLER: Leave this manual with party responsible for use and operation.
OWNER: Retain this manual for future reference.
NOTICE:
DO NOT discard this manual!
Model(s):
EPA CERTIFIED WOODBURNING
FIREPLACE
Installation and service of this fi replace should be
performed by qualifi ed personnel. Hearth & Home
Technologies recommends NFI certifi ed profes-
sionals, or technicians supervised by an
NFI certifi ed professional.
Owner's Manual
Care and Operation
R
O-T L
Portland
Tested and
Listed by
Oregon USA
C
US
OMNI-Test Laboratories, Inc.
Quadra-Fire • 7100 FP Owner's Manual • 433-3600 • Rev G • 06/25/14
WARNING: If the information in these
instructions is not followed exactly, a fi re
or explosion may result causing property
damage, personal injury, or death.
• DO NOT store or use gasoline or other fl am-
mable vapors and liquids in the vicinity of this
or any other appliance.
• DO NOT overfi re. Overfi ring will void your
warranty.
• Comply with all minimum clearances to com-
bustibles as specifi ed. Failure to comply may
cause house fi re.
WARNING
HOT SURFACES!
Glass and other surfaces are hot during
operation AND cool down.
Hot glass will cause burns.
• DO NOT touch glass until it is cooled
• NEVER allow children to touch glass
• Keep children away
• CAREFULLY SUPERVISE children in same room as
fi replace.
• Alert children and adults to hazards of high temperatures.
High temperatures may ignite clothing or other fl ammable
materials.
• Keep clothing, furniture, draperies and other fl ammable
materials away.
WARNING
Fire Risk.
For use with solid wood fuel only.
Other fuels may overfi re and generate
poisonous gases (i.e. carbon monoxide).
Pour demander un exemplaire en
français de ce Manuel
du propriétaire, visitez www.
heatnglo.com/translations.
1
Advertisement
Table of Contents
Troubleshooting
Subscribe to Our Youtube Channel
Related Manuals for Quadra-Fire 7100FP-BK-B
Summary of Contents for Quadra-Fire 7100FP-BK-B
-
Page 1: Care And Operation
High temperatures may ignite clothing or other fl ammable EPA CERTIFIED WOODBURNING materials. • Keep clothing, furniture, draperies and other fl ammable FIREPLACE materials away. Installation and service of this fi replace should be WARNING performed by qualifi ed personnel. Hearth & Home Technologies recommends NFI certifi ed profes- Fire Risk. sionals, or technicians supervised by an NFI certifi ed professional. For use with solid wood fuel only. Other fuels may overfi re and generate poisonous gases (i.e. carbon monoxide). Quadra-Fire • 7100 FP Owner’s Manual • 433-3600 • Rev G • 06/25/14... -
Page 2: Table Of Contents
6 Reference Materials 1. Hardwood vs. Softwood ► 2. Moisture content A. Service Parts 3. Seasoning B. Contact Information 4. Storing Wood 5. Burning Process 6. Dirty Glass 7. Creosote Formation 8. Opacity D. First Fire E. Lighting Instructions F. Heat Management Quadra-Fire • 7100 FP Owner’s Manual • 433-3600 • Rev G • 06/25/14... -
Page 3: Welcome
2013 2014 2015 Jan Feb Mar Apr May June July Aug Sept Oct. Nov. Dec. DO NOT REMOVE THIS LABEL Made in U.S.A. of US and imported parts 433-1400 Quadra-Fire • 7100 FP Owner’s Manual • 433-3600 • Rev G • 06/25/14... -
Page 4: Limited Lifetime Warranty
2 years Factory-installed blowers Molded refractory panels 3 years Firepots and burnpots 5 years 1 year Castings and baffles Manifold tubes, 7 years 3 years HHT chimney and termination 1 year Burners, logs and refractory years Limited 3 years Firebox and heat exchanger Lifetime All replacement parts 90 Days beyond warranty period See conditions, exclusions, and limitations on next page. 4021-645F 02-18-13 Page 1 of 2 Quadra-Fire • 7100 FP Owner’s Manual • 433-3600 • Rev G • 06/25/14... - Page 5 This warranty is void if: • The appliance has been over-fired or operated in atmospheres contaminated by chlorine, fluorine, or other damaging chemicals. Over-firing can be identified by, but not limited to, warped plates or tubes, rust colored cast iron, bubbling, cracking and discoloration of steel or enamel finishes. • The appliance is subjected to prolonged periods of dampness or condensation. • There is any damage to the appliance or other components due to water or weather damage which is the result of, but not limited to, improper chimney or venting installation. LIMITATIONS OF LIABILITY: • The owner’s exclusive remedy and HHT’s sole obligation under this warranty, under any other warranty, express or implied, or in contract, tort or otherwise, shall be limited to replacement, repair, or refund, as specified above. In no event will HHT be liable for any incidental or consequential damages caused by defects in the appliance. Some states do not allow exclusions or limitation of incidental or consequential damages, so these limitations may not apply to you. This warranty gives you specific rights; you may also have other rights, which vary from state to state. EXCEPT TO THE EXTENT PROVIDED BY LAW, HHT MAKES NO EXPRESS WARRANTIES OTHER THAN THE WARRANTY SPECIFIED HEREIN. THE DURATION OF ANY IMPLIED WARRANTY IS LIMITED TO DURATION OF THE EXPRESSED WARRANTY SPECIFIED ABOVE. 4021-645F 02-18-13 Page 2 of 2 Quadra-Fire • 7100 FP Owner’s Manual • 433-3600 • Rev G • 06/25/14...
-
Page 6: Product Specific Information
Heating Capacity: up to 3,500 sq ft Chimney Size: 8 inches SL300 Series DuraVent DuraPlus Max Wood Length: 24 inches Fuel: Cord Wood Shipping Weight: 670 lbs Firebox Size 3.4 cubic feet C. Glass Specifications This fireplace is equipped with 5mm ceramic glass. Re- place glass only with 5mm ceramic glass. Please contact your dealer for replacement glass. Quadra-Fire • 7100 FP Owner’s Manual • 433-3600 • Rev G • 06/25/14... -
Page 7: Important Safety And Operating Information
60 in. (1524 mm) Clear Space Bottom of Fireplace to Lower Edge of Mantel or Trim 48 in. (1219 mm) Clear Space Front of Fireplace 12 in. (305 mm) Clear Space Sides of Fireplace (from the FP opening) Figure 3.1 Clear Space Quadra-Fire • 7100 FP Owner’s Manual • 433-3600 • Rev G • 06/25/14... -
Page 8: Firebrick
• Ensure all joints are properly engaged and the chimney is properly secured. WARNING! Risk of Fire! A chimney fire can perma- nently damage your chimney system. Failure to re- place damaged components and make proper repairs can cause a structure fire. Quadra-Fire • 7100 FP Owner’s Manual • 433-3600 • Rev G • 06/25/14... -
Page 9: General Operating Parts
B. General Operating Parts WARNING! DO NOT operate fi replace before reading and understanding operating instructions. Failure to operate fi re- place according to operating instructions could cause fi re or injury. Automatic Combustion Air Control Handle Auxiliary Convection ACC Override Outside Air Control Handle Air Lever Lever (Must be open during use) Figure 3.3 General Operating Parts Quadra-Fire • 7100 FP Owner’s Manual • 433-3600 • Rev G • 06/25/14... -
Page 10: Automatic Combustion Control (Acc)
ACC Override Control Left - Close Figure 3.5 ACC Override Control Automatic Combustion Control (ACC) Left - Close (low) Right-Open (high) Figure 3.4 Automatic Combustion Control (ACC) Quadra-Fire • 7100 FP Owner’s Manual • 433-3600 • Rev G • 06/25/14... -
Page 11: Auxiliary Convection Air System
Outside Air Control Handle Clockwise Counterclockwise Open Close Figure 3.7 Outside Air Control Handle Auxillary Convection Air Lever Control Left - Close Right-Open Figure 3.6 Auxillary Convection Air Lever Quadra-Fire • 7100 FP Owner’s Manual • 433-3600 • Rev G • 06/25/14... -
Page 12: Glass Doors
Their seeds are usually found within a protective pod or enclosure. Some ex- amples of deciduous trees are oak, maple, apple, and birch. However, it should be noted that there are some Figure 3.8 Override Switch and Fan Speed Control Quadra-Fire • 7100 FP Owner’s Manual • 433-3600 • Rev G • 06/25/14... -
Page 13: Moisture Content
When combined with tar and other organic vapors from burning wood it will form creosote which condenses in the relatively cool firebox and chimney. Even dry wood contains at least 15% moisture by weight, and should be burned hot enough to keep the chimney hot for as long as it takes to dry the wood out - about one hour. To tell if wood is dry enough to burn, check the ends of the logs. If there are cracks radiating in all directions from the center, it is dry. If your wood sizzles in the fire, even though the surface is dry, it may not be fully cured. Quadra-Fire • 7100 FP Owner’s Manual • 433-3600 • Rev G • 06/25/14... -
Page 14: Burning Process
You may the way open for 15-20 minutes should remove the built notice an industrial odor the first few fires. This is considered up coating. normal. Quadra-Fire • 7100 FP Owner’s Manual • 433-3600 • Rev G • 06/25/14... -
Page 15: Lighting Instructions
Burn Rate BTU / Hr *Combustion Air Control to liven the coalbed. The door should be opened slowly to Below 10,000 Slide LEFT to Stop prevent ash and smoke spillage into the room. Break up Medium 10,000 - 15,000 Stop to 1/8 in. -1/2 in. open any large chunks and distribute the coals so new wood Medium High 15,000 - 30,000 Stop to 1/2 in. - 1-1/2 in. open is laid evenly on hot coals. Add desired amount of fuel, High Maximum Heat All the way to RIGHT close the door. *These are approximate settings, and will vary with type of wood or chimney draft. Quadra-Fire • 7100 FP Owner’s Manual • 433-3600 • Rev G • 06/25/14... -
Page 16: Maintenance And Service
• Inspect for creosote and remove as needed, at least every two months during the heating season. • Inspect the system at the fireplace connection and at the chimney top. In the event of a chimney fire, Hearth & Home Technologies recommends replacement of the chimney and inspection of the adjacent structure to the provisions of NFPA Level III inspection criteria. WARNING! Risk of Asphyxiation and Fire! Annual inspection by qualified technician recommended. Check: • condition of doors, surrounds and fronts • condition of glass and glass assembly • obstructions of combustion and ventilation air • obstructions of termination cap Clean: • glass • air passageways, grilles Quadra-Fire • 7100 FP Owner’s Manual • 433-3600 • Rev G • 06/25/14... -
Page 17: Creosote (Chimney) Cleaning
Termination Caps Remove 2 screws from the front and back and lift the top off. TCT375 Terra Cotta Termination Cap Figure 4.1 Chimney & Termina- tion Cap Cleaning Quadra-Fire • 7100 FP Owner’s Manual • 433-3600 • Rev G • 06/25/14... -
Page 18: Care And Cleaning Of Plated Surfaces
1/4 in. • Open door, place half a dollar bill inside and close (6 mm). the door. • Attempt to pull the bill out. • If the bill gives good resistance or is not removable, the gasket is adjusted correctly. If the bill is easily removed, the gasket needs adjustment or replacement to create an even seal all around door. It may be necessary to adjust or tighten the door latch. Quadra-Fire • 7100 FP Owner’s Manual • 433-3600 • Rev G • 06/25/14... -
Page 19: Replacement Maintenance
DO NOT OVERTIGHTEN OR CROSS THREAD SCREWS. Figure 4.2 Door Handle Assembly • Replace the door on the fireplace. • After the first burn, recheck the tightness of the screws. NOTICE: Remove all labels from glass before lighting the first fire in your fireplace. Quadra-Fire • 7100 FP Owner’s Manual • 433-3600 • Rev G • 06/25/14... -
Page 20: Firebrick Replacement
1 9” x 3-1/4” x 1-1/4” Angled (see drawing) 2 6-1/4” x 4-1/2” x 1-1/4” 3-1/4" 1-1/4" 3 9” x 2” x 1-1/4” 4 6-1/4” x 3-1/2” x 1-1/4” 5 9” x 4.5” x 1-1/4” Quadra-Fire • 7100 FP Owner’s Manual • 433-3600 • Rev G • 06/25/14... -
Page 21: Baffle Removal And Installation
Screws the air channel and out of hole at the other end. It is Screwdriver Slot only necessary to remove the first tube in order to remove the baffle. Figure 4.8 Accessing Fan Motor • Slide fiber board baffle forward to front of fireplace and straight out through door. See Figure 4.7. • To install the fiber board baffle, repeat the 2nd through 4th steps in reverse. Be sure the fiber board baffle and ceramic blanket are pushed back fully and the blanket is down and flat. Quadra-Fire • 7100 FP Owner’s Manual • 433-3600 • Rev G • 06/25/14... -
Page 22: Timer Assembly Replacement
Air Chamber Cover is attached to Timer Assembly Figure 4.13 Timer Assembly with Air Chamber Cover Figure 4.10 Installing Fans (Linkage arm is not included in the kit) Quadra-Fire • 7100 FP Owner’s Manual • 433-3600 • Rev G • 06/25/14... - Page 23 Figure the assembly. See Figure 4.18. 4.18. Timer Plate Air Chamber Cover Attach with 1/4-20 bolts Figure 4.16 Remove Screws from Timer Mounting Plate Figure 4.19 Install Control Box Quadra-Fire • 7100 FP Owner’s Manual • 433-3600 • Rev G • 06/25/14...
-
Page 24: Timer Removal & Replacement
Figure 4.23 Linkage Control Arm Installed Figure 4.21 Timer • Rotate linkage control arm into final position and re-attach to mounting plate. Note that the D cut is now facing the linkage timer arm. Re-attach the linkage timer arm, Figure 4.23. • Retun to Timer Assembly Replacement, Section 4.B.6. Quadra-Fire • 7100 FP Owner’s Manual • 433-3600 • Rev G • 06/25/14... - Page 25 Figure 4.24 Exploded View of Entire Assembly for Point of Refer- ence only Item Description Door Linkage Linkage Control Arm Bushing Washer SAE #10 Screw 8-32 x 1/2 PH PHL TC Linkage Timer Arm Attachment Nut & Set Screw Screw 6-32 x 1/4 PH PHL TC Mounting Bracket Timer, Mechanical, 12 hours Quadra-Fire • 7100 FP Owner’s Manual • 433-3600 • Rev G • 06/25/14...
-
Page 26: Troubleshooting
He can usually make suggestions or discover These three factors work together as a system to create problems that can be easily corrected allowing your the flue draft. Increasing or decreasing any one of them fireplace to operate correctly as it has been designed, will affect the other two and thus change the amount of providing safe and economical heat for your home. draft in the entire system. If the fire is hard to start and smoke spills out of the fire- place, or you find it difficult to establish and maintain a moderately high burn rate, then the flue draft is too low and corrective measures must be taken. Be sure you have air available for combustion and that your firewood is dry and well seasoned. Build your fires properly and according to the instructions given in op- Quadra-Fire • 7100 FP Owner’s Manual • 433-3600 • Rev G • 06/25/14... - Page 27 (furnace, fan, Unsealed dryer, etc.)? can lights? Overhead fan operating? Creosote buildup in flue? Air register from furnace near fireplace? Doors opening and closing? Outside air Window closed Combustion closed? for start-up? air control Figure 5.1 Factory-built Fireplaces: Troubleshooting Quadra-Fire • 7100 FP Owner’s Manual • 433-3600 • Rev G • 06/25/14...
-
Page 28: Troubleshooting Table
• Insufficient fuel for fire/heat required Fan doesn’t come on • No power • Fireplace is not hot enough to activate snap disc • Snap disc may be faulty Quadra-Fire • 7100 FP Owner’s Manual • 433-3600 • Rev G • 06/25/14... -
Page 29: Reference Materials
7100FP-BK-B, 7100FP-GD-B, and 7100FP-NL-B (Aug 2006 - Active) 7100FP-BK, 7100FP-GD and 7100FP-NL (Mar 2005 -- July 2006) MISSION HILL FASCIA VALLEY FORGE FASCIA Part number list on following page. 01/14 Quadra-Fire • 7100 FP Owner’s Manual • 433-3600 • Rev G • 06/25/14... -
Page 30: Service Parts
Post 0071580458 Screw, BH SH 1/4-20 x 1.25 BLK Pkg of 24 225-0630/24 Screw, 1/4-20 x .5 Button Head 32328/20 Pkg of 20 Nut, Tinnerman Cage 1/4-20 Pkg of 4 812-2980 Component Pack 433-5990 Knob, Chad, Mission Hill Front 2005-193 Pre 0071580458 DF-7100VF Fascia, Valley Forge DF-7100VF-B Post 0071580458 Post 0071580458 DF-7100RM Fascia, Rolling Meadows Post 0071580458 DF-7100RM-NL Component Pack 433-5990 Additional service part numbers appear on following page. Quadra-Fire • 7100 FP Owner’s Manual • 433-3600 • Rev G • 06/25/14... -
Page 31: Door Handle Assembly
13.10 Cam Latch 32084 Gold Trim 433-7160 Door Trim, Left (Only use for damaged as a replacement for damaged parts) Nickel Trim 433-7340 Gold Trim 433-7150 Door Trim, Right (Only use for damaged as a replacement for damaged parts) Nickel Trim 433-7330 Gasket, Door, Left & Right Door SRV433DRGASKET Gasket, Lytherm, 1/2 x 1/8, 4. 4.17 Ft 834-2590 Screw, Flat Head Philips 8-32 x 1/2 Pkg of 10 832-0860 Washer, Sae, 3/8 Pkg of 3 832-0990 Additional service part numbers appear on following page. Quadra-Fire • 7100 FP Owner’s Manual • 433-3600 • Rev G • 06/25/14... -
Page 32: Side View
Warranty Card) Control Arm Assembly 433-5880 Face Board Assembly, Non-combustible board 433-5720 Fan Speed Control SRV7000-143 Flange, Outer Can Lower 433-0970 Hearth Strip 18320 Knob, ACC Knob Pkg of 2 32284/2 Light Switch 480-1260 Light Switch Cover Plate 480-1270 Outside Air Hood 6” 4059-051 Paint Touch-Up 812-0910 Outside Air Termination Cap, 6 In. 480-1160 Unit Collar 659-125 Additional service part numbers appear on following page. Quadra-Fire • 7100 FP Owner’s Manual • 433-3600 • Rev G • 06/25/14... - Page 33 Nut, Keps Lock, 8-32 Pkg of 40 226-0060/40 Nut, Ser Flange Small 1/4-20 Pkg of 24 226-0130/24 Pkg of 25 220-0030/25 Screw, PH 8-32 x 1/2 Screw, Machine Screw 1/4-20 X 5/8 Pkg of 24 220-0440/24 Screw, Pan Head Philips 8-32 X 3/4 Pkg of 24 229-1100/24 Screw, Pan Head Philips 8-32 X 3/8 Pkg of 40 225-0500/40 Screw, Sheet Metal #8 X 1/2 S-Grip Pkg of 40 12460/40 Pkg of 24 226-0160/24 Wing Nut WF .8-32, Refractory Retainer Wing Nut WF .1/4-20, for use with fan kits Pkg of 12 226-0110/12 Quadra-Fire • 7100 FP Owner’s Manual • 433-3600 • Rev G • 06/25/14...
- Page 34 This page intentionally left blank. Quadra-Fire • 7100 FP Owner’s Manual • 433-3600 • Rev G • 06/25/14...
- Page 35 This page intentionally left blank. Quadra-Fire • 7100 FP Owner’s Manual • 433-3600 • Rev G • 06/25/14...
-
Page 36: Contact Information
6769426, 6774802, 6796302, 6840261, 6848441, 6863064, 6866205, 6869278, 6875012, 6880275, 6908039, 6919884,7047962, 7216645, D320652, D445174, D462436; (Canada) 1297749, 2195264, 2225408, 2313972; (Australia) 780250, 780403, 1418504 or other U.S. and foreign patents pending. Printed in U.S.A. - Copyright 2012 Quadra-Fire • 7100 FP Owner’s Manual • 433-3600 • Rev G • 06/25/14...
