OWNER'S MANUAL
Installation and Operation
Model:
51I-ACC
•
If the information in these instruc-
tions is not followed exactly, a
fire may result causing property
damage, personal injury, or death.
• Do not store or use gasoline or other flam-
mable vapors and liquids in the vicinity of
this or any other appliance.
• Do not overfire - If heater or chimney con-
nector glows, you are overfiring. Overfiring
will void your warranty.
• Comply with all minimum clearances to
combustibles as specified. Failure to
comply may cause house fire.
WARNING
Fire Risk.
For use with solid wood fuel only.
Other fuels may overfire and generate
poisonous gases (i.e. carbon monoxide).
To obtain a French translation of this manual, please contact your dealer or visit www.quadrafire.com
Pour obtenir une traduction française de ce manuel, s'il vous plaît contacter votre revendeur ou visitez www.
www.quadrafire.com
5100-I ACC WOOD INSERT
Automatic Combustion Control (ACC)
DO NOT DISCARD THIS MANUAL
• Read, understand and
Important operating
a n d m a i n t e n a n c e
instructions included.
WARNING
CAUTION
follow these instructions
for safe installation and
operation.
Hot glass will cause burns.
• Do not touch glass until it is cooled
• NEVER allow children to touch glass
• Keep children away
• CAREFULLY SUPERVISE children in same room as
fireplace.
• Alert children and adults to hazards of high
temperatures.
High temperatures may ignite clothing or other
flammable materials.
• Keep clothing, furniture, draperies and other flammable
materials away.
NOTE
quadrafire.com
7047-148C
R
• Leave this manual with
party responsible for
use and operation.
WARNING
HOT SURFACES!
Glass and other surfaces are
hot during operation AND
cool down.
Installation and service of this appliance should be
performed by qualified personnel. Hearth & Home
Technologies recommends NFI certified profession-
als, or technicians supervised by an NFI certified
professional.
December 20, 2011
Advertisement
Table of Contents
Related Manuals for Quadra-Fire 51I-ACC
Summary of Contents for Quadra-Fire 51I-ACC
-
Page 1: Installation And Operation
5100-I ACC WOOD INSERT Automatic Combustion Control (ACC) OWNER’S MANUAL Installation and Operation Model: 51I-ACC CAUTION DO NOT DISCARD THIS MANUAL • • Read, understand and • Leave this manual with Important operating follow these instructions party responsible for a n d m a i n t e n a n c e for safe installation and use and operation. -
Page 2: Congratulations
51I ACC Wood Insert and Welcome to the Quadra-Fire Family Hearth & Home Technologies welcomes you to our tradition of our stoves, inserts and fireplaces. And yet we are old- of excellence! In choosing a Quadra-Fire appliance, you fashioned when it comes to craftsmanship. Each unit is have our assurance of commitment to quality, durability, and meticulously fabricated and gold and nickel surfaces are performance. -
Page 3: Table Of Contents
51I ACC Wood Insert Safety Alert Key: • DANGER! Indicates a hazardous situation which, if not avoided will result in death or serious injury. • WARNING! Indicates a hazardous situation which, if not avoided may result in death or serious injury. • CAUTION! Indicates a hazardous situation which, if not avoided, may result in minor or moderate injury. • NOTICE: Indicates practices which may cause damage to the appliance or to property. TABLE OF CONTENTS Installer’s Guide Congratulations ...............2 Sample of Safety/Serial Number Label ......2 Warranty Policy ...............4-5 Section 6: Getting Started A. Design, Installation & Location Section 1: Listing and Code Approvals Considerations ..........26 A. Appliance Certifications........6 B. Draft ..............26 B. Mobile Home Approved........6 C. Negative Pressure..........27... -
Page 4: Warranty Policy
51I ACC Wood Insert Hearth & Home Technologies Inc. LIMITED LIFETIME WARRANTY Hearth & Home Technologies Inc., on behalf of its hearth brands (”HHT”), extends the following warranty for HHT gas, wood, pellet, coal and electric hearth appliances that are purchased from an HHT authorized dealer. WARRANTY COVERAGE: HHT warrants to the original owner of the HHT appliance at the site of installation, and to any transferee taking ownership of the appliance at the site of installation within two years following the date of original purchase, that the HHT appliance... - Page 5 51I ACC Wood Insert WARRANTY CONDITIONS: • This warranty only covers HHT appliances that are purchased through an HHT authorized dealer or distributor. A list of HHT authorized dealers is available on the HHT branded websites. • This warranty is only valid while the HHT appliance remains at the site of original installation. •...
-
Page 6: Section 1: Listing And Code Approvals
3 cubic feet Approved. Max Wood Length: 20 inches Fuel: Cord Wood NOTE: This installation must conform with local codes. In the Shipping Weight: absence of local codes you must comply with the UL1482, (UM) 480 lbs 84-HUD and NPFA211 in the U.S.A. and the ULC S628-93 and CAN/CSA-B365 Installation Codes in Canada. WARNING The Quadra-Fire 5100 Wood Insert (ACC) meets the U.S. Environmental Protection Agency’s 1990 particulate emis- sion standards. Fire Risk. Hearth & Home Technologies disclaims any B. Mobile Home Approved responsibility for, and the warranty will be voided by, the following actions: • This appliance is approved for mobile home installa- • Installation and use of any damaged appliance. tions when not installed in a sleeping room and when • Modification of the appliance. an outside combustion air inlet is provided. • Installation other than as instructed by Hearth & Home • The structural integrity of the mobile home floor, ceil-... -
Page 7: Section 2: Operating Instructions
51I ACC Wood Insert User Guide Operating Instructions WARNING HOT SURFACES! Glass and other surfaces are hot during operation AND cool down. Hot glass will cause burns. • DO NOT touch glass until it is cooled • NEVER allow children to touch glass • Keep children away • CAREFULLY SUPERVISE children in same room as appliance. • Alert children and adults to hazards of high temperatures. High temperatures may ignite clothing or other flammable materials. • Keep clothing, furniture, draperies and other flammable materials away. If you expect that children may come into contact with this appli- ance, we recommend a barrier such as a decorative screen. -
Page 8: Fire Safety
51I ACC Wood Insert B. Fire Safety Hearth & Home Technologies WILL NOT warranty stoves To provide reasonable fire safety, the following should be that exhibit evidence of over-firing. Evidence of over-firing given serious consideration: includes, but is not limited to: 1. Install at least one smoke detector on each floor of • Warped air tube your home to ensure your safety. They should be located away from the heating appliance and close • Deteriorated refractory brick retainers to the sleeping areas. Follow the smoke detector... -
Page 9: Burning Process
2. Second Stage F. Burning Process In the secondary stage wood gives off flammable gases which burn above the fuel with bright flames. In recent years there has been an increasing concern about air quality. Much of the blame for poor air quality has been During this stage of burning: placed on the burning of wood for home heating. • The flames must be maintained and not allowed to go out In order to improve the situation, we at Quadra-Fire have to ensure the cleanest possible fire. developed cleaner-burning wood appliances that surpass • If the flames tend to go out, it is set too low for your burn- the requirements for emissions established by our governing ing conditions. agencies. The air control located at the upper right hand corner is used to These wood appliances must be properly operated in order adjust for burn rates. This is called the Burn Rate Air Control. to ensure that they perform the way they are designed to Figure 10.1 on page 10. -
Page 10: Automatic Combustion Control (Acc)
51I ACC Wood Insert G. Automatic Combustion Control (ACC) Typically, when you build a fire, you open the air controls fully and monitor the fire to prevent it from going into an overfire Burn Rate Air Control situation and/or burning your wood up too quickly before you shut down the air controls to the desired burn rate. When using the Automatic Combustion Control (ACC) system, you do not have to continually monitor the fire. Once you set the ACC system it will control the fire for you. Follow the instructions below to learn how to operate your stove with ease. H. Air Controls 1. Start-Up Air Control The Start-Up Air Control has two primary functions. The first function is to activate the Automatic Combustion Control system (ACC). -
Page 11: Burn Rates And Operating Efficiency
51I ACC Wood Insert 3. Burn Rate Air Control • The air supply enters at the upper front of the firebox, 5. Low Burn Rate - Below 10,000 BTU/hr* near the top of the glass door. • Leave the Burn Rate Air Control at the bottom marker. • This preheated air supplies the necessary fresh oxygen • Push the Start-Up Air Control all the way back until it to mix with the unburned gases, helping to create the stops and then pull forward until it stops. -
Page 12: Correct Baffle & Blanket Placement
51I ACC Wood Insert J. Correct Baffle & Blanket Placement INCORRECT POSITIONS WARNING Fire Risk Improper baffle placement may cause: • Overheating of firebox • Overheating the chimney Baffle must be placed properly (see instructions) Replace baffle if damaged or missing. NOTE: A missing, damaged or improperly positioned baffle Ceramic Blanket and Baffle Board are NOT is dangerous and may cause damage and poor efficiency. in contact with the back of the firebox. It will also void your warranty. Note: This are generic drawings and may not represent your specific model. CORRECT POSITION Back of Firebox Ceramic Blanket Ceramic Blanket is NOT in contact with the back of the firebox and NOT even with the Baffle Board in the front. -
Page 13: Building A Fire
51I ACC Wood Insert K. Building A Fire • Open door slowly so that ash or smoke does not exit ap- pliance through opening. WARNING • Large logs burn slowly, holding a fire longer. • Small logs burn fast and hot, giving quick heat. 9. As long as there are hot coals, repeating steps 6 through Fire Risk. 8 will maintain a continuous fire. Keep combustible materials, gasoline and other flammable vapors and liquids clear of appliance. • Do NOT store flammable materials in the appliance’s vicinity. NOTE: • DO NOT USE GASOLINE, LANTERN FUEL, • Build fire on brick firebox floor. KEROSENE, CHARCOAL LIGHTER FLUID OR SIMILAR LIQUIDS TO START OR “FRESHEN UP” A • Do NOT use grates, andirons or other methods to support FIRE IN THIS HEATER. fuel. It will adversely affect emissions. • Keep all such liquids well away from the heater while it is in use. -
Page 14: Wood Fuel
51I ACC Wood Insert L. Wood Fuel Moisture WARNING WARNING Fire Risk. • Do NOT burn wet or green wood. Fire Risk. • Store wood in dry location. • DO NOT BURN GARBAGE OR FLAMMABLE • Stack wood so both ends are exposed to air. FLUIDS SUCH AS GASOLINE, NAPTHA OR Wet, unseasoned wood can cause accumulation of ENGINE OIL. creosote. • DO NOT USE CHEMICALS OR FLUIDS TO START A The majority of the problems appliance owners experience FIRE. are caused by trying to burn wet, unseasoned wood. • Do NOT burn treated wood or wood with salt (driftwood). • Wet, unseasoned wood requires energy to evaporate the • May generate carbon monooxide if burn material other water instead of heating your home, and than wood. May result in illness or possible death. • Causes evaporating moisture which cools your chimney, accelerating formation of creosote. -
Page 15: Blower Control Box Snap Disc Operations
51I ACC Wood Insert M. Operating the Blower Control Box with Snap Disc 1. The blower will turn on/off automatically when set to AUTO. Figure 15.1. 2. When set to MANUAL, the fan will turn on/ off only when you turn it on or off. This setting over-rides the internal snap disc. 3. Adjust the speed of the fan by turning the HIGH/LOW knob to the desired setting. MANUAL: Over-rides the internal Snap Disc AUTO: Fan will tun ON/OFF automatically and is controlled... -
Page 16: Clear Space
51I ACC Wood Insert Q. Opacity (Smoke) O. Clear Space Opacity is the measure of how cleanly your appliance is • Do NOT place combustible objects within 4 ft (1.2 m) of burning. the front of appliance. Figure 16.1. Opacity is measured in percent: • 100% opacity is when an object is totally obscured by WARNING the smoke column from a chimney, and Fire Risk. • 0% opacity means that no smoke column can be seen. • Do NOT place combustible objects within 48 As you become familiar with your appliance, you should inches in front of the appliance. -
Page 17: Quick Start Guide
51I ACC Wood Insert Note: These are generic drawings and may not represent R. Quick Start Guide your specific model. 10 Pieces of Newspaper, 10-20 Pieces of Dry Kindling ITEMS NEEDED FOR FIRST FIRE: and a Few Pieces of Dry Split Wood. OPEN AIR CONTROLS ADD NEWSPAPER LOAD WOOD BURN HIGH RATE Upper right corner START-UP Lower right corner Push In and then Pull Out ADD KINDLING WARNING! Risk of Fire Close and securely latch the door after... -
Page 18: Section 3: Maintenance And Service
51I ACC Wood Insert Maintenance and Service Creosote - Formation and Need for Removal A. Disposal of Ashes • When wood is burned slowly, it produces tar and other • Frequency: When ash is within 1-3/4 inch (44mm) of organic vapors, which combine with expelled moisture firebox lip. Leave 1/4 to 1/2 inch (6-13mm) of ash in the to form creosote. bottom of the firebox. • The creosote vapors condense in the relatively cool •... -
Page 19: Glass Cleaning
51I ACC Wood Insert E. Glass Cleaning F. Inspect Firebrick • Frequency: After each ash removal • Frequency: As desired • By: Homeowner • By: Homeowner Replace the firebrick if they become crumbly and/or if • Clean glass with a non-abrasive glass cleaner. Abrasive there is a 1/4 inch (6.35mm) gap between the bricks. cleaners may scratch and cause glass to crack. The firebox is lined with firebrick, which has exceptional • If the deposits on the glass are not very heavy, normal insulating properties. Do not use a grate; simply build glass cleaners work well. Heavier deposits may be a fire on the firebox floor. Do not operate appliance removed by using a damp cloth dipped in wood ashes or without firebrick. -
Page 20: Quick Reference Maintenance Guide
51I ACC Wood Insert G. Quick Reference Maintenance Guide Start the first inspection after the first 2 months of use, or if performance changes, and adjust your schedule CAUTION! accordingly. Maintenance is required for safe operation Allow the appliance to completely cool and must be performed to maintain your warranty. down before performing any cleaning or maintenance. Frequency Task Baffle & Blanket Baffle and blanket placement is critical to MONTHLY heat output, efficiency and overall life of the Blanket unit. Make sure the baffle is pushed all of the After Every... -
Page 21: Section 4: Troubleshooting Guide
51I ACC Wood Insert Troubleshooting Guide With proper installation, operation, and maintenance your woodstove will provide years of trouble-free service. If you do experience a problem, this troubleshooting guide will assist you or a qualified service person in the diagnosis of a problem and the corrective action to be taken. Start Fire Problems Possible Cause Solution Can not get fire started Not enough kindling/paper or no Use dry kindling, more paper. Arrange kindling & Excessive smoke or spillage kindling/paper wood for air movement. Burns too slowly Not enough heat output Check for restricted termination cap Check for blockage of outside air kit (if installed). Check for flue blockage. Pre-warm flue before starting fire (refer to Building a Fire Section). Not enough air for fire to ignite Check for adequate vent height (refer to Chimney Height Section). Open window below the appliance towards the wind. Wood condition is too wet, too Use dry, seasoned wood (refer to Seasoned Wood large Section). Bed of coals not established Start with paper & kindling to establish bed of before adding wood coals (refer to Building a Fire Section). -
Page 22: Section 5: Service Parts Replacement
Handle glass with care. • Inspect the gasket to ensure it is undamaged. Assemblée • Do NOT strike, slam or scratch glass. Bouclier ventilateur • Do NOT operate appliance with glass & door assembly removed. • Do NOT operate with glass cracked, broken or scratched. Figure 22.2 Quadra-Fire appliances are equipped with ceramic super heat-resistant glass, which can only be broken by impact or Blower Mounting Bracket misuse. CAUTION Shock Risk. • Do NOT remove grounding prong from plug. Remove 4 screws • Plug directly into properly grounded 3 prong receptacle. • Route cord away from appliance. -
Page 23: Glass Replacement - Side Window
51I ACC Wood Insert E. Snap Disc Replacement C. Glass Replacement - Side Window (Replace with 5mm ceramic glass only) 1. The snap disc bracket assembly is located on top of the blower housing in the center. Figure 23.2. 1. Open door and remove vertical brick in the bay window 2. Remove the 4 hex head bolts using a 5/32 Allen wrench area. from the blower housing and pull the housing towards you. 2. Reach inside firebox and loosen 4 hex nuts using a 7/16 3. Pull the snap disc and spade connectors up and out of inch socket wrench holding the cast in place. -
Page 24: Baffle Removal
51I ACC Wood Insert F. Baffle Removal G. Door Handle Assembly 1. Install washer on door handle shaft. 1. Remove all ash from the firebox, and extinguish all hot embers before disposal into a metal container. 2. Slide door handle through door. 2. The baffle board has 2 pieces. With the ceramic blanket 3. Install second washer(s) as shown in Figure 24.3. still in place, slide one baffle piece over the top of other one 4. Install key in groove. but still keep it all components inside the firebox. Figure 5. Align groove in latch cam with key; slide latch cam over 24.1. shaft 3. It is easier to remove both baffle boards and ceramic 6. Install locknut but do not overtighten, the handle needs blanket after the tube channel assembly has been partially to move smoothly. -
Page 25: Tube Channel Assembly Replacement
51I ACC Wood Insert G. Tube Channel Assembly Replacement it is off the threads. Drop the right side down, then slide the assembly back to right. Removing Tube Channel Assembly 5. The ceramic blanket and both baffle boards can be removed at the same time you remove the tube channel 1. Remove the right side bricks (3 pieces). assembly. 2. Remove the baffle protection channel by rolling forward 6. When the tube channel assembly is free of the left side and out of the firebox. support, rotate clockwise and pull assembly, blanket and 3. Locate the 2 channel nuts and 2 channel bolts inside of baffles out through the front opening. chamber and remove. 7. Re-install in reverse order. NOTE: S oak the bolts with penetrating oil for at least 15 min- utes before trying to remove them. 4. Slide the tube channel assembly all the way to left until 2 Tube Channel Nuts 2 Tube Channel bolts Rotate and remove from... -
Page 26: Installer's Guide
51I ACC Wood Insert Installer’s Guide Getting Started B. Draft A. Design and Installation Considerations Draft is the pressure difference needed to vent appliances CAUTION successfully. When a appliance is drafting successfully, all combustion byproducts are exiting the home through the Check building codes prior to installation. chimney. • Installation MUST comply with local, regional, state and Considerations for successful draft include: national codes and regulations. -
Page 27: Negative Pressure
51I ACC Wood Insert C. Negative Pressure WARNING Asphyxiation Risk. • Negative pressure can cause spillage of com- bustion fumes, soot and carbon monoxide. • Appliance needs to draft properly for safety. Negative pressure results from the imbalance of air available for the appliance to operate properly. It can be strongest in lower levels of the house. Causes include: • Exhaust fans (kitchen, bath, etc.) • Range hoods • Combustion air requirements for furnaces, water heaters and other combustion appliances • Clothes dryers • Location of return-air vents to furnace or air conditioning • Imbalances of the HVAC air handling system • Upper level air leaks such as: - Recessed lighting - Attic hatch - Duct leaks To minimize the effects of negative air pressure: • Install the outside air kit with the intake facing prevailing winds during the heating season... -
Page 28: Locating Your Appliance And Chimney
51I ACC Wood Insert D. Locating Your Stove & Chimney • Consider the appliance location in order to avoid floor and ceiling attic joists and rafters. Location of the appliance and chimney will affect perfor- mance. As shown in Figure 28.1 the chimney should: • Locate termination cap away from trees, adjacent structures, uneven roof lines and other obstruc- • Install through the warm space enclosed by the build- tions. -
Page 29: 2-10-3 Rule
51I ACC Wood Insert F. 2-10-3 Rule These are safety requirements and are not meant to assure proper flue draft. This appliance is made with a 6 inch (152mm) diameter chimney connector as the flue collar on the unit. • Changing the diameter of the chimney can affect draft and cause poor performance. • It is not recommended to use offsets and elbows at altitudes above 4000 feet above sea level and or when there are other factors that affect flue draft. Less than 10 ft. (305cm) 2 ft. (61cm) 3 ft. (91cm) 2 ft. (61cm) Minimum 10 ft. -
Page 30: Tools And Supplies Needed
51I ACC Wood Insert Pre-Burn Check List G. Tools And Supplies Needed Before beginning the installation be sure the following tools Place the appliance in a location near the final and building supplies are available: installation area and follow the procedures below: Open the appliance and remove all the parts and Reciprocating saw Framing material articles packed inside the Component Pack. Inspect Pliers High temp caulking material all the parts and glass for shipping damage. Contact your dealer if any irregularities are noticed. Hammer Gloves All safety warnings have been read and followed. Phillips screwdriver Framing square This Owner’s Manual has been read. Flat blade screwdriver Electric drill and bits Floor protection requirements have been met. Plumb line Safety glasses Venting is properly installed per vent manufacturing instructions. Level Tape measure The proper clearances from the appliance and chim- 1/2-3/4 in. length, #6 or #8 self-drilling screws ney to combustible materials have been met. -
Page 31: Section 7: Dimensions And Clearances
51I ACC Wood Insert Dimensions and Clearances NOTE: Flue Collar size is 6 inch (152mm) diameter (ID) A. Appliance Dimensions 29-1/16 in. (738mm) 25-1/2 in. (648mm) 37-7/16 in. (951mm) 17-9/16 in. (446mm) 12-3/8 in. (314mm) 13-1/16 in. (332mm) Figure 31.1 Top View Figure 31.2 Front View Surround Sizes Standard... -
Page 32: Clearances To Combustibles (Ul And Ulc)
51I ACC Wood Insert B. Clearances to Combustibles, United States and Canada (UL and ULC) TOP TRIM 32-1/4 27-1/4 819mm 692mm 40-11/16 1033mm USA 16-3/4 HEARTH CANADA EXTENSION 24-3/4 (629mm) 12in max MANTEL USA 23-1/2 CANADA 25-1/2 (648mm) 43-11/16 1110mm HEARTH EXTENSION No thermal protection required ember protection only... -
Page 33: Section 8: Chimney Systems
51I ACC Wood Insert Chimney Systems D. Masonry Chimney A. Venting Systems • Must meet minimum standards of NFPA 211. Chimney Connector: • Must have at least 5/8 inch (16mm) fireclay lining joined It is also known as flue pipe or stove pipe. It must be with refractory cement. (Installations into a clay flue 6 inches (152mm) minimum diameter stainless steel without a stainless steel liner may reduce draw which affects connector pipe. -
Page 34: Masonry Chimney
51I ACC Wood Insert Masonry Chimney (Cont’d) NOTE: In Canada, this fireplace insert must be installed with a continuous chimney liner of a 6 inch (152mm) diam- This insert conforms with the UL 1482 and ULC S628 eter extending from the fireplace insert to the the top of the (Canada) in all respects, and is approved to UL & ULC chimney. The chimney liner must conform to the Class 3 safety standards for installation and use within a fireplace requirements of CAN/ULC-S635, Standard for Lining Sys- with a masonry chimney in accordance with NFPA 211 and tems for Existing Masonry or Factory-Built Chimneys and... -
Page 35: Metal Heat Circulating Chimney
51I ACC Wood Insert E. Metal Heat Circulating Masonry •The original factory-built clearance fireplace chimney cap must be re-installed after installing the approved This insert conforms with the safety standard UL-1482 and chimney liner meeting type UL 103 HT requirements ULC S628 (Canada) in all respects and is approved to UL & (2100°F) per UL 1777. ULC safety standards for installation and use within a fire- •If the chimney is not listed as meeting HT requirements, place with masonry chimney, in accordance with NFPA 211, or if the factory built fireplace was tested prior to 1998, a with a direct flue collar connection. full height listed chimney liner must be installed from the appliance flue collar to the chimney top. -
Page 36: Securing Chimney Components
51I ACC Wood Insert Prefabricated Metal Chimney (Cont’d) H. Altering the Fireplace Inches Millimeters The following modifications of factory-built fireplaces are Minimum Width of Cavity Opening - Front 29-1/16 permissible: Minimum Width of Cavity Opening - Rear 25-1/2 The following parts may be removed: Minimum Height 20-3/4 Minimum Depth from Front to Rear 17-9/16 Damper Smoke Shelf or Baffle Ember Catches Fire Grate NOTE: Refer to chimney liner manufacturer for recom- Viewing Screen/Curtain Doors mendations on supporting the liner. -
Page 37: Zero-Clearance Factory-Built Fireplaces
Inspect the existing fireplace and chimney for any damage K. Chimney Height / Rise and Run or flaws such as burnouts, metal or refectory warping. To be sure that your Quadra-Fire insert burns properly, the chimney draft (static pressure) should be approximately -0.10 Inspection to a minimum of NFPA 211 Level II is recom- inches water column (W.C.) during a high burn and -0.04 mended. All repairs must be made prior to installing an inches W.C. during a low burn, measured 6 inches (152mm) -
Page 38: Section 9: Appliance Set-Up
51I ACC Wood Insert Appliance Set-up A. Outside Air Kit Installation WARNING A source of air (oxygen) is necessary in order for combustion to Fire Risk. take place. Whatever combustion air is consumed by the fire must be replaced. Air is replaced via air leakage around win- Asphyxiation Risk. dows and under doors. In homes that have tightly sealed doors Do not draw outside combustion air from: and windows, an outside air source is needed. An optional Out- • Wall, floor or ceiling cavity side Air Kit is available. • Enclosed space such as an attic or garage Items Needed for Installation (not supplied) • Close proximity to exhaust vents or chimneys • 4 inch flex aluminum pipe, or if using alternate material, Fumes or odor may result then it shall be made from durable, non-combustible, heat resistant material up to 350... -
Page 39: Securing Stove Pipe/Liner To Flue Collar
51I ACC Wood Insert B. Securing Stove Pipe/Liner to Flue Collar Cast Iron Flue Located on Appliance 1. There are 4 pre-drilled holes in the flue collar 90 degrees apart. Attach the flue collar to the stove pipe/liner. If the seal is questionable use high temperature sealant such as stove mastic Figure 39.1. 2. Attach gasket to bottom side of flue collar with a thin coat of silicone. Drill through all 8 countersunk locations Figure 39.2 Gasket Flue Collar Stove Pipe/Liner Figure 39.1... -
Page 40: Leveling Legs
51I ACC Wood Insert E. Securing Appliance to Stove Pipe/Liner D. Leveling Legs 1. Once you have the appliance in place and secured, reach 1. Remove the 2 screws already installed on each leg. up through the flue opening and grab the attachment bar 2. Move legs to the desired height. and pull down inside flue opening. Figure 40.2. 3. Re-install the screws to secure in place. 2. Insert the 5/16 bolts inside the cast flue and through the chimney mounting bar. Securely tighten the nuts. Fas- teners are provided. 3. Re-install the tube channel assembly, baffle board, ceramic blanket and baffle protection channel. Attachment Bar Chimney Mounting Bar Remove 2 screws from both sides. -
Page 41: Surround & Trim Installation
51I ACC Wood Insert F. Surround & Trim Kit Installation 1. Lay surround face down on a protected surface to pre- vent scratching. 2. Using a Phillips head screw driver attach the side sur- rounds to the top surround using 2 #8 sheet metal screws provided with the kit. Figure 41.1 SURROUND 3. Lay the trim face down and place the corner brackets into ATTACH POINTS position. 4. Using a standard flat screw driver tighten the corner brackets. Figure 41.2. -
Page 42: Blower Cord Installation - Left Side
51I ACC Wood Insert G. Blower Cord Installation on Left Side 10. See Figure 43.1 as a reference to connect the remain- ing wires as shown. The blower cord is shipped to be installed on the right side of the appliance. You may relocate the cord so it is on the 11 Reconnect the wire harness to the snap disc that is left side. You will need to remove the wires, flip them over located on the heat shield. Rotate the heat shield into and remove and reverse the male and female terminals position and reinstall the flat head screws and the sheet- and re-install the wires. The wire harness and components... - Page 43 51I ACC Wood Insert Remove Control Plate Disconnect Wires to theSnap Disc Figure 43.1 Figure 43.4 Place Harness Under Tabs Remove Screw from Bottom of Housing Figure 43.2 Figure 43.5 Figure 43.3 Figure 43.6 Page 43 7047-148C December 20, 2011...
-
Page 44: Zero-Clearance Adjustable Trim Support
51I ACC Wood Insert H. Zero Clearance Adjustable Trim Support, EXPLODED VIEW OF SCISSORS 2” to 10” Part No. 841-0990, size 9” x 45” and Part No. ADJSPT-12, size 12” x 50” SCREWS ARE CIRCLED Included in Kit: ( 1) Trim Top, (1) Trim Front, (2) Trim Sides, Double-Sided Tape (already installed) DOUBLE-SIDED TAPE DOUBLE-SIDED TAPE... -
Page 45: Section 10: Moble Home Installation
51I ACC Wood Insert Mobile Home Installation 1. An outside air inlet must be provided for combustion and 8. Burn wood only. Other types of fuels may generate must remain clear of leaves, debris, ice and/or snow. It poisonous gases (e.g., carbon monoxide). must be unrestricted while unit is in use to prevent room 9. If unit burns poorly while an exhaust blower is on in air starvation which can cause smoke spillage and an home, (i.e., range hood), increase combustion air. inability to maintain a fire. Smoke spillage can also set off smoke alarms. 10. Installation shall be in accordance with the Manufacturers Home & Safety Standard (HUD) CFR 3280, Part 24. -
Page 46: Section 11: Reference Materials
51I ACC Wood Insert Reference Materials 51i- ACC-BK Service Parts 51i- ACC-BK Service Parts Beginning Manufacturing Date: July 2011 Wood Insert Stove Ending Manufacturing Date: Active Beginning Manufacturing Date: July 2011 Wood Insert Stove Ending Manufacturing Date: Active A. Exploded Drawings 7025-040 6-18-09 Part number list on following page. -
Page 47: Service Parts & Accessories
51I ACC Wood Insert 51i- ACC-BK Service Parts Beginning Manufacturing Date: July 2011 Ending Manufacturing Date: Active B. Service Parts & Accessories IMPORTANT: THIS IS DATED INFORMATION. When requesting service or replacement Stocked parts for your appliance please provide model number and serial number. All parts listed in this manual may be ordered from an authorized dealer. -
Page 48: Service Parts
51I ACC Wood Insert 51i- ACC-BK Service Parts Beginning Manufacturing Date: July 2011 Ending Manufacturing Date: Active IMPORTANT: THIS IS DATED INFORMATION. When requesting service or replacement Stocked parts for your appliance please provide model number and serial number. All parts listed in this manual may be ordered from an authorized dealer. - Page 49 51I ACC Wood Insert 51i- ACC-BK Service Parts Beginning Manufacturing Date: July 2011 Ending Manufacturing Date: Active IMPORTANT: THIS IS DATED INFORMATION. When requesting service or replacement Stocked parts for your appliance please provide model number and serial number. All parts listed in this manual may be ordered from an authorized dealer.
- Page 50 51I ACC Wood Insert 51i- ACC-BK Service Parts Beginning Manufacturing Date: July 2011 Ending Manufacturing Date: Active IMPORTANT: THIS IS DATED INFORMATION. When requesting service or replacement Stocked parts for your appliance please provide model number and serial number. All parts listed in this manual may be ordered from an authorized dealer.
-
Page 51: Service And Maintenance Log
51I ACC Wood Insert C. Service And Maintenance Log Date of Service Performed By Description of Service Page 51 7047-148C December 20, 2011... -
Page 52: Contact Information
Hearth & Home Technologies 1445 North Highway Colville, WA 99114 Division of HNI INDUSTRIES Please contact your Quadra-Fire dealer with any questions or concerns. For the number of your nearest Quadra-Fire dealer, log onto www.quadrafire.com CAUTION DO NOT DISCARD THIS MANUAL •...
