IrDA Infrared Interface Port (CN6)

The built-in IrDA port supports Serial Infrared (SIR) or Amplitude Shift Keyed IR
(ASKIR) interface. To use the IrDA port, configure the SIR or ASKIR model in the
BIOS's Peripheral Setup's COM2. Then, the normal RS-232 COM2 will be disabled.
For the location of this connector, refer to figure 2.
Pin Number
1
2
3
4
5
6

VGA Connector (J1)

The built-in 15-pin VGA connector can be connected directly to your monochrome
CRT monitor as well as a high resolution color CRT monitor. For the location of
this connector, refer to figure 2.
Pin Number
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
Description
VCC
FIR-RX
IR-RX
GND
IR-TX
CIR-RX
Description
RED
GREEN
BLUE
NC
GND
GND
GND
GND
VCC
GND
NC
DDC DATA
HSYNC
VSYNC
DDC CLK
Board Configuration 22
