Watchdog Timeout Period (JP12)

Period
1 sec.
2 sec.
10 sec.
20 sec.
110 sec.
220 sec.
Refer to figure 2 for the location of JP12.
DiskOnChip™ Memory Address Setting (JP11)
The DiskOnChip™ (DOC) Flash Disk Chip is produced by M-Systems. No extra soft-
ware utility is needed because the DOC is 100% compatible to hard disk. It is
"plug and play", easy, and reliable. The DOC is available from 2 MB to 144 MB.
Pin Number
1-2
3-4
5-6
Refer to figure 2 for the location of JP11.

Clear CMOS Setup (JP4)

If you forget the CMOS password, you can clear or reset it by closing JP4. After
JP4 is closed, turn on the power for about three seconds, then turn it off and
open JP4. Now, the password has been cleared from your CMOS.
Pin Number
2-3
3-4
Note:
1-4 is for connection with external battery (4=GND)
Refer to figure 2 for the location of JP4.
1-2
3-4
OFF
OFF
OFF
OFF
OFF
ON
OFF
ON
ON
OFF
ON
OFF
Address
CE00-CFFF
D600-D7FF
DE00-DFFF
Description
Normal Operation
Clear CMOS Setup
Board Configuration
5-6
7-8
ON
OFF
ON
ON
OFF
OFF
OFF
ON
OFF
OFF
OFF
ON
14
