Parallel Port (CN4)

This port is usually connected to a printer. The SBC-370 includes an onboard par-
allel port accessed through a 26-pin flat-cable connector. For the location of this
connector, refer to CN4 in figure 2.
Pin Number
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
Description
STROBE#
DATA 0
DATA 1
DATA 2
DATA 3
DATA 4
DATA 5
DATA 6
DATA 7
ACKNOWLEDGE
BUSY
PAPER EMPTY
PRINTER SELECT
AUTO FORM FEED #
ERROR#
INITIALIZE
PRINTER SELECT LN#
GND
GND
GND
GND
GND
GND
GND
GND
NC
Board Configuration 18
