Keyboard/Mouse Connector (CN8/CN17/CN18)

The SBC-370 provides one external keyboard, one external mouse, and one PS/2
keyboard and mouse connector.
CN8: 5-pin Header External Keyboard Connector (see note below)
•
Pin Number
1
2
3
4
5
CN17: PS/2 Mouse 5-pin Header Connector
•
Pin Number
1
2
3
4
5
CN18: 6-pin Mini-DIN PS/2 Keyboard and Mouse Connector (see note below)
•
Pin Number
1
2
3
4
5
6
For the location of these connectors, refer to figure 2.
Note:
A keyboard cannot be connected to CN8 and CN18 simultaneously. A mouse can-
not be connected to CN17 and CN18 simultaneously. One of each device can be con-
nected to CN18 via a Y adapter cable) or CN8 and CN17.
Description
KB CLK
KB DATA
NC
GND
+5V
Description
MS DATA
NC
GND
+5V
MS CLK
Description
KB DATA
NC
GND
+5V
KB CLK
NC
