Summary of Contents for Stelpro ASIL Series
- Page 1 User’s guide ‘‘ASIL’’ series Electronic convector Replacement components list included This unit complies with the CSA and UL standards For further information or to consult this guide online, please visit our Web site. INS_ASIL_1111...
- Page 2 If needed, refer to a specialist who will be able to calculate these heat losses and optimize the required capacity, or consult the “Online heating calculation” section of the Stelpro Design Web site (residential buildings). To heat a large room and to increase your comfort, it is recommended to install several units instead of one.
-
Page 3: Selection Table
Important: Light Activation of the thermal protection is indicated by a light located at the right end, visible trough the louvers. It warns you that the heater has been subjected to abnormal conditions. If this occurs, it is highly recommended that the unit be disconnected and inspected by a qualified electrician in order to make sure it is not damaged. -
Page 4: Installation
INSTALLATION • Installation of the wall rack 1. Remove the unit from the wall rack’s hooks. 2. With a pencil, mark the wall at the four anchoring points of the rack. 3. Fasten the rack to the wall, making sure it is level. When drilling into a wall or ceiling, do not damage electrical wiring and other hidden utilities. -
Page 5: Unlocking Procedure
Night light mode Normally, the backlight is activated when you press down a button and stays on for fifteen (15) seconds afterwards. To keep the backlight on, simultane- ously press down both buttons for 3 seconds (until the backlight blinks), then release. Repeat this procedure to deactivate the night light mode. Selection of the temperature scale To change the temperature scale (°C or °F), simultaneously press down both buttons for eight (8) seconds, the °C or °F symbol will blink. -
Page 6: Maintenance
• SUMMARY – BUTTONS FUNCTIONS Buttons DAY mode NIGHT mode One (1) button To set the desired temperature To set the desired temperature To switch to NIGHT mode for a Two (2) buttons, simultaneously To switch back to DAY mode pre-determined time Two (2) buttons, To select the duration of the... -
Page 7: Troubleshooting
TROUBLESHOOTING PROBLEM DEFECTIVE PART OR PART TO CHECK - Defective thermostat or wrong thermostat setting - Open circuit breaker or fuse The unit does not work - Thermal protection activated - Faulty connections The unit runs continuously - Defective thermostat or wrong thermostat setting - Defective thermal protection The enclosure is extremely hot - Blocked air vents... -
Page 8: Limited Warranty
The warranty is limited to the repair or the replacement of the unit or the refund of its purchase price, at the discretion of Stelpro. Any parts replaced or repaired within the warranty period with the written authorization of Stelpro will be warranted for the remainder of the original war- ranty period.
