- Page 1 User’s guide ‘‘ASHC’’ series Convector Replacement components list included This unit complies with the CSA and UL standards For further information or to consult this guide on line, please visit our Web site. INSASHC0812...
- Page 2 If needed, refer to a specialist who will be able to calculate these heat losses and optimize the required capacity or consult the “Online heating calculation” section of the Stelpro Design Web site (residential buildings). To heat a large room and to increase your comfort, it is recommended to install several units instead of one.
- Page 3 SELECTION TABLE bUIlt-IN WItHOUt pOWER vOltAGE HEIGHt lENGtH WEIGHt tHERMOStAt tHERMOStAt code code watts volts ASHC0501 ASHC0501WC 500 17 9/16 17 5/16 11,2 ASHC0508 ASHC0508WC 500 17 9/16 17 5/16 11,2 ASHC0502 ASHC0502WC 500/375 240/208 17 9/16 17 5/16 11,2...
- Page 4 N.B. The wall where you install the device must be straight so that the bracket is perfectly level, without any pressure. It is very important to follow this directive to prevent damaging the bracket during the installation. This could cause malfunction of the interlock system.
- Page 5 Night Light Mode Normally, the backlight is activated when you press down a button and stays on for fifteen (15) seconds afterwards. To keep the backlight on, simultane- ously press down both buttons for 3 seconds (until the backlight blinks), then release. Repeat this procedure to deactivate the night light mode. Selection of the Temperature Scale To change the temperature scale (°C or °F), simultaneously press down both buttons for eight (8) seconds, the °C or °F symbol will blink.
-
Page 6: Troubleshooting
• SUMMARY – BUTTONS FUNCTIONS buttons DAY mode NIGHt mode One (1) button To set the desired temperature To set the desired temperature To switch to NIGHT mode for a Two (2) buttons, simultaneously To switch back to DAY mode pre-determined time Two (2) buttons, To select the duration of the... - Page 7 REPLACEMENT COMPONENT LIST # REF. # PART DESCRIPTION M-SHC0504Z* FRONT COVER SHC 500 W M-SHC1004Z* FRONT COVER SHC 1000 W M-SHC1504Z* FRONT COVER SHC 1500 W M-SHC2004Z* FRONT COVER SHC 2000 W PROT-006 THERMAL PROTECTION 500 W PROT-100 LINEAR THERMAL PROTECTION 1000 W PROT-005 THERMAL PROTECTION 1500 W PROT-007...
-
Page 8: Limited Warranty
Stelpro reserves the right to examine or to ask one of its representatives to examine the product itself or any part of it before honoring the warranty. Stelpro reserves the right to replace the entire unit, refund its purchase price or repair a defective part.
