- Page 1 Instructions for use, installation, and connection Electric built-in cooking hob...
-
Page 2: Table Of Contents
Electric built-in cooking hob Dear customer! Electric built-in hob is intended for use in households. Our products are packed in environment-friendly materials which can be recycled, disposed of, or destroyed without imposing any burden on the environment. Instructions for use Instructions for use Instructions for use are intended for the user. -
Page 3: Important Warnings
Important warnings • Installation of the appliance into a kitchen worktop and its connection to the power mains may only be performed by an adequately qualifi ed technician. • Do not leave small children unattended when the appliance is in operation. Risk of burning and scalding! •... -
Page 4: Appliance Description
Appliance description The following fi gure shows the surface of the hob with electric hotplates. Type EVK4... Type EVK6... 1. Cooking zone rear left 2. Cooking zone front left 3. Control knobs 4. Cooking zone front right 5. Cooking zone rear right... -
Page 5: Cooking Zones
Cooking zones Before using the Before using the Turn on the cooking zones for 3 to 5 minutes and select the appliance for the fi rst appliance for the fi rst maximum power level; some fumes may be discharged from the time time hob. -
Page 6: Operating The Cooking Zones
Energy saving Energy saving • Pan bottom diameters should match the diameter of the cooking zone. If the pan is too small, some heat is wasted; furthermore, using a too small pan can damage the cooking zone. • Whenever possible given the cooking process, use a lid. •... -
Page 7: Cleaning And Maintenance
Cleaning and maintenance • Clean the appliance using warm water, liquid detergent, and a soft cloth. • Do not use any abrasive or sharp utensils or other objects. Burnt or dried food residues should be moistened using a damp cloth and softened with appropriate detergent. •... -
Page 8: Special Warnings And Fault Reporting
Special warnings and fault reporting During the warranty period, only a service center authorized by the manufacturer may carry out any repairs. Before making any repairs, make sure the appliance is disconnected from the power mains either by removing the fuse or by disconnecting the power plug from the wall outlet. Unauthorized tampering with and repairs of the kitchen range (cooking hob) can result in electric shock or short circuit;... -
Page 9: Installation
• Minimum distance between the built-in cooking hob and the rear wall is indicated on the installation drawing. • Cooking hobs can be installed into worktops that are 30 to 50 mm thick. Kitchen worktop cutoff Type EVK4.. dimensions... -
Page 10: Installation Procedure
Type EVK6.. • Only type EVP4, EVP2... ovens fi tted with a cooling fan may be installed underneath this cooking hob. • Before installing an oven, the rear wall of the kitchen furniture element should be removed in the area of the cooking hob cutout. -
Page 11: Connecting The Appliance To The Power Mains
Connecting the appliance to the power mains Important warnings • The appliance may only be connected by an authorized skilled technician. • Electric system protection should comply with all relevant regulations. • The connection clips can be accessed when the connection clip covers are opened / removed. •... - Page 12 NOTE: Connection bridges are already installed on their respective places on the clip. Screws of the connection terminals are open, which means they do not have to be unfastened or unscrewed any further. When fastening the screws, you may hear a slight ‘click’, which means that the screws should be fastened / screwed in completely.
-
Page 13: Technical Characteristics
Technical characteristics Rating plate A Serial number B Code C Model D Type E Trademark F Technical information G Compliance indications / symbols WE RESERVE THE RIGHT TO MAKE ANY CHANGES THAT DO NOT AFFECT THE FUNCTIONALITY OF THE APPLIANCE. - Page 16 EVK6,4K 252584/en (04-10)
