Summary of Contents for Ariston PF750AST
- Page 1 User Instruction Book ARISTON GAS HOB Model PF750AST(GH) 00550922...
-
Page 2: Close-Up View
Congratualtions on choosing an Ariston appliance, which you will find is dependable and easy to use. We recommend that you read this manual for best performance and to extend the life of your appliance. Thank you. A. Gas Burners B. Support Grid for Cookware C. -
Page 3: How To Keep Your Hob In Shape
burner. To turn on one of the rings, press the relative knob in all the way and turn it anti-clockwise to the high setting is fitted with an electronic igniter that automatically starts when the knob is pressed in. Since the burner is equipped with a safety device "F", after lighting the burner keep the knob pressed in for about 6 seconds to allow the device which keeps the flame lit automatically to heat up. -
Page 4: Practical Advice
Practical Advise on Using the Burners For best performance, follow these general guidelines: • Use the appropriate cookware for each burner (see table) in order to prevent the flame from reaching the sides of the pot or pan; • Alwasy use cookware with a flat bottom and keep the lid on;... -
Page 5: Is There A Problem
It may occur that the cooktop does not function or does not function properly. Before calling customer service for assistance, lets see what can be done. First of all, check to see that there are no interruptions in the gas and electrical supplies, and, in particular, that the gas valves for the mains are open. -
Page 6: Installation Instructions For Built-In
It is recommended that you follow the guidelines below: Only use the appliance to cook food, avoiding all other uses; Check the condition of the appliance after it has been unpacked; Disconnect the appliance from the power supply in the event of malfunction and always before cleaning or maintenance;... - Page 7 at a height from the top which allows easy use of pots and pans on the cooker. d) Should the cooktop be installed directly under a cupboard, the latter should be at least 700 mm (millimetres) from the top, as shown in Figure. 600mm min.
- Page 8 Gas Connection to Flexible Steel Pipe The gas feed connector to the appliance is a threaded, male 1/ 2" connector for round gas pipe. Only use pipes, tubes and gaskets that comply with current safety codes. The maximum length of the flexible pipes must not exceed 2000 mm. Once the connection has been made, ensure that the flexible metal tube does not touch any moving parts and is not crushed.
-
Page 9: Characteristic Of The Burners And Nozzles
Characteristic of the burners and nozzles Table1 (For Hungary) (only model PF 760...) Burner By-pass 1/100 (mm) Semi-Fishburner (SP) Reduced Fast (RR) Semi Fast (S) Auxiliary (A) Double flame (DCDR internal) Double flame (DCDR external) 2 nozzle Supply pressures At 15°C and 1013 mbar-dry gas P.C.I. - Page 10 PF 740 A / PF 740 AS PF 741 A / PF 741 AS PF 740 A.1 / PF 740 AS.1 PF 741 A.1 / PF 741 AS.1 PF 750 A / PF 750 AS PF 750 AST PF 750 AST R PF 750 ASP PF 760 DR GH PF 760 AS...
