Summary of Contents for Windsor Titan T1
- Page 1 WET/DRY VACUUM Operating Instructions (ENG) MODEL: T1 QUEST… for Continuous Improvement Windsor’s Quality Management System is Certified ISO 9001. Read these instructions before operating the machine. T1 98648 03/27/00...
-
Page 2: Table Of Contents
Operations .........5 Troubleshooting .........6 INSPECTION Carefully unpack and inspect your machine for shipping damage. Each unit is operated and thoroughly inspected before shipping, and any damage is the responsibility of the carrier, who should be notified immediately. T1 98648 03/28/00... -
Page 3: Safety Instructions
Do not pull or carry by cord, use cord as a handle, close a door on cord, or pull cord around sharp edges or corners. Do not pull/run machine over cord. Keep cord away from heated surfaces. Connect to a properly grounded outlet. See Grounding Instructions. SAVE THESE INSTRUCTIONS T1 98648 03/27/00... -
Page 4: Hazard Intensity Level
Unless Operation Guide is Read and understood. In Flammable or Explosive areas. In areas with possible falling objects. WHEN SERVICING MACHINE: Avoid moving parts. Do not wear loose clothing; jackets, shirts, or sleeves when working on the machine. Use Windsor approved replacement parts. T1 98648 03/27/00... -
Page 5: Grounding Instructions
Do not modify the plug provided with the appliance - if it will not fit the outlet, have a proper outlet installed by a qualified electrician. T1 98648 03/27/00... -
Page 6: Operations
For wet or dry use. Your machine is equipped with a 1.5” diameter hose. Hose Adaptor enables machine to use 1.25” tools. Dusting tool included with machine must be used with Hose Adapter, Dusting Tool For dusting dry surfaces. Twist onto Hose Adaptor or Extension Wand(s). T1 98648 03/27/00... -
Page 7: Troubleshooting
Float in raised position. Obstruction inside head or on motor. Float Shuts Off Without Water in Tank Filter bag pushed into float cage, holding too loose to motor. Parts damaged, missing or incorrectly assembled, holding float too close to motor. T1 98648 03/27/00... -
Page 8: Wiring Diagram
WIRING DIAGRAM T1 98648 03/27/00... -
Page 9: Machine Assembly
MACHINE ASSEMBLY T1 98648 03/27/00... -
Page 10: Parts Lists
Gasket, Tank Cover 9527014 Float 9558023 Cage, Float 9527002 Tank 9560017 Gasket, Hose Coupler 9560043 Coupler, Hose 9560021 Caster 95PL061 Latch 9560041 Power Cord, Complete 9595018 Filter, Sponge 95R003 Carbon Brushes for 9527003 Not shown 500015 Label, Main T1 98648 03/27/00... -
Page 11: Limited Warranty
VERSAMATIC motors, pump motors, pc boards and electronics, vac motors (other than ® SENSOR FLEXSOL™ RADIUS™ TITAN™ pumps, and diaphragms, all Wet/Dry Vacs carry a 1 year parts and service labor warranty. Propane equipment has a 2 year ® Onan manufactured parts warranty.
