ELECTRICAL
The Model PV5 Wet/Dry Vacuum
Cleaner operates on standard 15 amp,
option available. Voltages below 105
volts, or above 125 volts, will cause
potentially serious damage to the vac
motors.
Thirty-five feet of 16/3 STJO cable with
a 3-prong plug is the power connection
to the machine.
This system has 3 main units:
1. Cabinet assembly with vacuum
motors, and attached electrical
cable.
2. Dome and perk/filter chamber
and cage.
3. Waste bucket.
Carefully unpack and inspect all com-
ponents for shipping damage. If you
discover any damage, notify the deliver-
ing carrier immediately. Your machine
was tested and inspected thoroughly
before shipment, and damage is the re-
sponsibility of the carrier.
OPERATION
Attach vacuum hose between the wand
and floor tool and the machine.
FOR DRY PICKUP
The waste bucket MUST have at least
5" of water in it before dry pickup is
started, and the perk/filter chamber
and cage must be in place.
FOR WET PICKUP
Wet pickup should be done with the
Insert electrical plug into 115 volt, 15
amp outlet. Make sure the dome is in
place and sealed. You may be working
on wet cerpet or wet floors, so make
sure the machine is properly grounded.
To prevent an overloaded circuit, do not
operate on the same circuit with other
appliances.
Turn power switch ON.
WARNING: When using for wet pickup
an overflow of water or dirt into the
vacuum motors can cause them to fail!!
Constantly monitor the level of waste
water in the recovery bucket. When
about 2/3rds full, shut off the machine,
remove the dome, take out bucket and
empty. Keep the exterior of the bucket
dry so no moisture gets into the vacuum
chamber. Replace the bucket, center
and seal the dome and continue
cleaning.
Do not use to pick up volatile materials
or dry chemicals. Do not expose the unit
to rain. Always store it indoors.
Do not tip over the machine. Always
operate with vac hose clipped by rope
leash to the machine.
AFTER CLEANING
Empty the waste water bucket and rinse
it thoroughly. Wipe out tank. Wipe off
machine and wand with a damp cloth.
Clean lint from the two air screens
inside the vacuum chamber before each
use.
MAINTENANCE
Periodically inspect the surfaces, hoses,
cable, filters and connections on your
machine. All surfaces should be clean to
minimize abrasion damage. Use only
soap and water for cleaning your
machine. Do not walk on hoses. Keep
them clean and unkinked. Frayed spots
on hoses should be covered and end
connectors kept snug. Because the
electrical cable will lie on carpet or
floors at times, the cable must be well
insulated and cable connector screws
should be tight. Do not walk on the
cable or run machinery over it. If the
cable insulation is broken or frayed,
repair or replace it immediately. Don't
take chances with an electrical fire or
shock.
If necessary, the plastic perk/filter
chamber can be removed for cleaning
by releasing the rod that holds it in
place. When replacing the chamber be
sure rubber gasket in dome elbow is in
place.
POSSIBLE CAUSE
PROBLEM
No power to machine Dead electrical circuit
Power switch failure.
Faulty electrical cable.
Equipment not grounded.
Electrical shock
Motor speed varies Motor brushes worn.
or doesn't run Motor worn out.
Loss of vacuum Loose vacuum dome.
Clogged water chamber.
Crack in dome or defective
glue joint.
Lint or dirt clogging vacuum
screen.
Loose cuffs on vacuum hose.
Vacuum motor seals leaking.
Floor tool vacuum chamber
plugged.
Broken vac hose.
Damaged dome gasket.
Worn out vac motor.
I

LIMITED WARRANTY

this product is free from defects in workmanship and
materials under normal use and service for a period of
one year from date of purchase WINDSOR will. at its
option. repair or replace without charge, except lor
transportation costs. parts that fail under normal use
and service when operated and maintained i n
accordance with the appl!cable operation and InStrUC-
wear, or to items whose life dependent on their use
and care, such as cords. switches. hoses. rubber parts.
electric motor parts. etc
IN ADDITION to the above warranty. for a period
5 YEARS WINDSOR will. without charge. either re-
place or return to working order. at its option. any solu-
tion tank that fails as a result 01 defects in materials or
WINDSOR INDUSTRIES, INC.
2635 So Santa
SOLUTION
Check building circuit breaker or
fuse box.
Replace.
Replace.
Ground prong on plug broken
off. Never operate machine
with grounding prong removed.
Replace.
Replace.
Center and seal dome over tank.
Rinse out with water.
Replace or reseal using acrylic
plastic cement only.
With power off, clean screen.
Tighten cuffs turning counter-
clockwise.
Replace.
Wash out with hose. Pick lint
out with wire
Replace.
Replace.
Replace.
workmanship during normal service and usage except
for transportation costs
This limited warranty is in lieu of all other warranties
expressed or implied and releases WINDSOR from all
other obligations and liabilities It is applicable only in
the A and Canada and is extended only to the
original userlpurchaser of this'product WINDSOR is
not responsible lor costs for repairs performed by
persons other than those specifically authorized by
WINDSOR This warranty does not apply to damage
from transportation alterations by unauthorized
persons misuse or abuse of the equipment use of non
compatible chemicals or damage to property or loss of
income due to malfunctioning of the product
If a difficulty develops with this machine you should
contact the dealer from whom it was purchased
Fe Drive Denver CO 80223
