Windsor TITAN 98165 Owner's Manual

Windsor titan wet/dry vacuum 98165 2/14/01d
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
TITAN
WET/DRY VACUUM
Record the model and serial number
located on the blue data label.
Use these numbers when calling upon the
Windsor dealer for parts and service.
MODEL : ______________________
SERIAL NO. : __________________
PURCHASE DATE : ____________
Contents:
1. Product Information
2. Warnings (English)
3. Warnings (French)
4. Warnings (Spanish)
D
WARNING
Unplug this machine before making
repairs or adjustments. Be sure all
electrical connections are correct and
that the wiring matches APPROPRIATE
diagram before plugging this machine
into an electrical outlet.

1. Maintenance and repairs

must only be done by
qualified personnel.
Using non-Windsor parts to
2.
repair this machine will
void the warranty.
10. Tank Squeegee Assemblies
12. Duct-Cord-Cover Assemblies
14. Lower/UpperHead Assemblies
TITAN 98165 2/14/01
Owner's Guide

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TITAN 98165 and is the answer not in the manual?

Questions and answers

Related Manuals for Windsor TITAN 98165

Summary of Contents for Windsor TITAN 98165

  • Page 1: Table Of Contents

    TITAN WET/DRY VACUUM Record the model and serial number located on the blue data label. Use these numbers when calling upon the Windsor dealer for parts and service. MODEL : ______________________ SERIAL NO. : __________________ PURCHASE DATE : ____________ Contents: 1.

  • Page 2: Important Safety Instructions

    IMPORTANT SAFETY INSTRUCTIONS When using an electrical appliance, basic precaution must READ ALL INSTRUCTIONS BEFORE USING THIS MACHINE. WARNING To reduce the risk of fire, electric shock, or injury: • Do not operate without filters (dry or wet) in place. •...
  • Page 3 IMPORTANTES MESURES DE SÉCURITÉ L’utilisation d’un appareil électrique demande certaines précautions: LIRE TOUTES LES INSTRUCTIONS AVANT DE FAIRE FONCTIONNER (CET APPAREIL) AVERTISSEMENT Pour réduire les risques d’incendie, de choc électrique ou de blessure: Cet appareil ne doit être connecter qu a des prises ayant une sortie de terre. Se •...
  • Page 4 INSTRUCCIONES IMPORTANTES PARA Durante la utilzación de un dispositivo eléctrico hay que tener en cuenta una serie de medidas básicas de precaución, que incluyen las siguientes ADVERTENCIA o lesiones: Conecte la aspiradora solamente a tomas de corriente con puesta a tierra. Tenga en •...

  • Page 5: Grounding Instructions

    THIS PRODUCT IS FOR COMMERCIAL USE ONLY. ELECTRICAL: In the USA this vacumm operates on a standard 15 amp 115 volt A.C. power circuit (120V nominal). Special voltage models are available for international applications. The amp, hertz, and voltage are listed on the data label found on each machine.
  • Page 6 T/SG 98165 7/1/97...

  • Page 7: Maintenance

    Caution: Strippers and some detergents produce foam which will damage the vac motors. The vac shut-off may not be sensitive to all foams. Be sure to check that the tank is not filling with foam. Use a defoaming agent to avoid pulling foam through vac motor.

  • Page 8: Servicing Vac Motor

    Servicing the Vac Motor To access the vac motor (s) remove the (6) screws which attach the main cover to the head assembly and set the cover to one side. The carbon motor brushes can now be serviced, to replace the motor assembly or service the vac motor gasket it will be necessary to open the vac exhaust chamber, remove the (9) screws around the edge of the exhaust chamber plate and remove the two screws from each vac motor connecting it to the vac chamber plate.

  • Page 9: Wiring Diagrams

    WIRING DIAGRAMS T10J, T16J 100V Twin T16/2-J T/SG 98165 7/1/97...

  • Page 10: Tank Assembly

    TANK ASSEMBLY SQUEEGEE ASSEMBLY (SUPER GULP MODELS ONLY) T/SG 98165 10/18/99...
  • Page 11 PART NO. DESCRIPTION 75166 Tank, 16 Gallon 75169 Tank, 10 Gallon 18011 Caster, 3” Swivel 87025 Washer, ¼ Star 70011 Scr, ¼-20 x 5/8 HHMS 78258 Tube, Squeegee Pivot 87008 Washer, ¼-20 x 1.25 Flat 70019 Scr, ¼-20 x 1.25 HHMS 62357 Plate, Squeegee Lock 67104...
  • Page 12 VAC COOLING DUCT T/SG 98165 2/14/01...
  • Page 13 PART NO. DESCRIPTION 34216 Foam, Duct Bottom OPEN 29168 Duct, 120V TT Vac Cooling 29167 Duct, 120V T Vac Cooling 29169 Duct, w/ Foam, 120V 29166 Duct w/ Foam, 120V 70430 Scr, #8-18 x 3/8 PHP 87017 Washer, #8 Flat 71112 Support, 115V Vac Duct PART NO.
  • Page 14 UPPER HEAD ASSEMBLY LOWER HEAD ASSEMBLY T/SG 98165 10/18/99...
  • Page 15 PART NO. DESCRIPTION 35107 Gasket, Support Plate 62798 Plate, Vac Shut-Off Disc 62370 Plate, Twin Motor Support 62371 Plate, Single Motor Support 87017 Washer, #8 Flat 70429 Scr, #8-18 x 3/4PHP H-L 53742 Motor Asm, 115V 53751 Motor Asm, 115V 53756 Motor Asm, 100V 27539...

  • Page 16: Troubleshooting Chart

    Faulty vac housing seals NOTE: Maintenance and repairs must be done by qualified personnel. Using non-Windsor parts to repair this machine will void the warranty. A complete service manual is available upon request which includes wiring diagrams, parts lists, part diagrams and basic repair instructions for the entire machine.

  • Page 17: Notes

    NOTES: T/SG 98165 7/1/97...

  • Page 18: Limited Warranty

    If proof of purchase cannot be identified, the warranty start date is 90 days after date of sale to an authorized Windsor distributor. Parts replaced or repaired under warranty are guaranteed for the remainder of the original warranty period.
