- Page 1 Model FM2642 Wall Mount Full Motion Television Wall Mount...
-
Page 2: Getting Started
Never use defective parts, as improper installation may cause damage or serious injury. Do not use this product for any purpose not explicitly specified by Audio Solutions™. Audio Solutions™ cannot be liable for damage or injury caused by incorrect mounting, incorrect assembly, or incorrect use. -
Page 3: Opening The Package
GettING StARted Opening the Package The FM2642 Wall Mount and accompanying hardware have been carefully packed in a carton designed to protect it from transportation damage. After opening the carton, check that the components are in good condition and that all listed contents are included. - Page 4 GettING StARted Wall Plate Mounting Hardware Part Image Description M4/M5 Part Image Description Spacer Square Head Screw M8/M6 Spacer Concrete Anchor M4/M5 M8 Washer Washer M6/M8 M6 x 10 Bolt Washer M4 Washer M8 x 12 Bolt M5 Washer Allen Wrench M6 Washer M8 Washer TV Bracket Assembly Hardware Part Image...
- Page 5 INStAllAtION SteP 1 Read and understand all of the enclosed instructions and verify that all parts are present and appear in good working order before you begin. SteP 2 Attach the Wall Plate to the wall. Wood Stud Mounting The Wall Plate must be mounted, at the top and bottom, to a solid wooden stud. Locate the stud and mark the center and edge locations.
- Page 6 INStAllAtION SteP 3 In the hardware bag provided, locate the 4 pan head bolts that fit the thread pattern for your television. Depending on the spacing of holes on the back of your television, choose from the various mounting options listed below to attach the mounting bracket to your television. If necessary, use the M6 x 10 bolts (A) to connect the included extension arms vertically, horizontally or diagonally to reach the television mounting holes.
- Page 7 INStAllAtION Figure 4 - Attach Bracket/diagonal Arms Figure 5 - Attach Bracket/Vertical Arms...
- Page 8 INStAllAtION Figure 6 - Attach Bracket/Horizontal Arms NOTE: You will need at least 2 people to finish this mounting procedure. To avoid possible injury, do not attempt to mount the TV alone. YES! Figure 7 - two Person Install WARNING!
- Page 9 INStAllAtION SteP 4 Next, hang the pre-assembled TV unit on the Wall Plate. Slide the protruding M8 x 12 head hex bolt (A) on the bracket attached to your TV into the groove on the mounted Wall Plate, illustrated in Figure 8. Use a second M8 x 12 bolt (B) to secure the TV assembly to the wall plate, and then tighten the top bolt (A) on the TV assembly.
- Page 10 INStAllAtION SteP 5 NOTE: Angle adjustment should be done by at least two people. • (A) With assistance, adjust the bracket arm at the joint nearest the wall up to 170 degrees or at the middle joint up to 360 degrees. Pay attention to wiring to ensure wires are not damaged during angle adjustment.
-
Page 11: Limited Warranty
lIMIted WARRANty Audio Solutions™ – Audio Mount™ – Limited Warranty – Valid in the United States and Canada This 60 month limited warranty is provided by Metra Electronics Corporation for the Metra product identified by the purchaser’s registration as indicated below, and there are no other warranties, expressed or implied, except as required by law, including warranties of merchantability and fitness for a specific purpose, that are provided for herein, however all such implied warranties, if any, are limited to the duration of this specific limited product warranty. - Page 12 ©2011 Metra Electronics Corporation, 460 Walker Street, Holly Hill, FL 32117-2699 Specifications are subject to change without notice. All trademarks are the property of their respective owners. www.audiosolutions.com...
