- Page 1 Model T3260 Wall Mount Television Wall Mount with Tilt Option...
-
Page 2: Getting Started
GettING StARted Introduction Congratulations on the purchase of your new Audio Solutions™ T3260 Television Wall Mount. For maximum benefit, please read the entire manual before beginning installation. NOTE: This model has been designed to work with most 32 to 60 inch Plasma, LCD and LED televisions with a maximum weight of 110lbs (50kg). -
Page 3: Opening The Package
GettING StARted Opening the Package The T3260 Wall Mount and accompanying hardware have been carefully packed in a carton designed to protect it from transportation damage. After opening the carton, check that the components are in good condition and that all listed contents are included. - Page 4 GettING StARted Wall Plate Mounting Hardware Part Image Description M8/M6 Part Image Description Spacer Square Head Screw M4/M5 Concrete Washer Anchor M6/M8 Washer M8 Washer M4 Washer Screw-In Handle M5 Washer 16 x 6.5 x M6 Washer 1mm Washer M8 Washer TV Bracket Assembly Hardware Part Image Description M4 x 12 Bolt...
- Page 5 INStAllAtION SteP 1 Read and understand all of the enclosed instructions and verify that all parts are present and appear in good working order before you begin. SteP 2 Attach the Wall Plate to the wall. Wood Stud Mounting The Wall Plate must be mounted, at the top and bottom, to at least 2 wooden studs, spaced a minimum of 16”...
- Page 6 INStAllAtION SteP 3 In the hardware bag provided, locate the 4 pan head bolts that fit the thread pattern for your television. With the two vertical brackets centered on the back of the TV, gently thread the screws into the holes by hand.
- Page 7 INStAllAtION NOTE: You will need at least 2 people to finish this mounting procedure. To avoid possible injury, do not attempt to mount the TV alone. YES! Figure 4 - two Person Install WARNING! SteP 4 Screw the two handles (A) with washers (B) to the side of each bracket (Figure 5). Figure 5 - Install Handles...
- Page 8 INStAllAtION SteP 5 Hang the pre-assembled TV unit on the Wall Plate. Tighten the screws (A) at the bottom of each bracket to secure the brackets to the Wall Plate (Figure 6). Figure 6 - Attach tV Assembly to Wall Plate...
- Page 9 INStAllAtION SteP 6 Adjust angle by loosening the side two handles to allow the TV to tilt forward up to 15 degrees or backward 5 degrees (Figure 7). Once the desired tilt angle is achieved, tighten the handle to secure the television in the new position.
-
Page 10: Limited Warranty
Metra Electronics Corporation will repair or replace, at its option, any defective unit. This warranty is applicable only to the original purchaser and is not assignable or transferable. Metra hereby... - Page 11 ©2011 Metra Electronics Corporation, 460 Walker Street, Holly Hill, FL 32117-2699 Specifications are subject to change without notice. All trademarks are the property of their respective owners. www.audiosolutions.com...
