Summary of Contents for Audio Solutions Helios T3260
- Page 1 Model T3260 Wall Mount Television Wall Mount with Tilt Option CAUTION: Please read this instruction carefully before assembly. Fits 32-60" plasma and LCD TV. Weight Capacity: 50kg (110lbs).
- Page 2 GettING StARted CAUTION : SAFETY WARNING: Never let children climb on product or play with product. Do not sit or stand on product. Do not fasten a TV that is heavier than the recommended load rating to the mount. Using suitable concrete wall or wood stud wall. Improper installation may cause property damage and/or personal injury,so the installation must be done by two qualified contractors.
- Page 3 TV mounting hardware a--M4x12 bolt b--M5x12 bolt c--M6x12 bolt d--M8x16 bolt e--M8x20 bolt 4pcs 4pcs 4pcs 4pcs 4pcs f--M4x30 bolt g--M5x30 bolt h--M8x30 bolt i--M6x35 bolt j--M8x40 bolt 4pcs 4pcs 4pcs 4pcs 4pcs k--5mm l--M4/M5 m--M8/M6 n--M4/M5 o--M6/M8 spacer 4pcs spacer 4pcs spacer 4pcs washer 4pcs...
- Page 4 ： Step 2 Pls remove the plaster board on the surface of concrete wall when assembling mount on the concrete wall. Hold Wall plate ( A ) against wall at desired position on concrete wall, then using a pencil mark 4 hole locations. Then drill holes according pencil marks using 3/8"...
- Page 5 Step 3 Attach TV Bracket (B) to the back of TV, choose corresponding bolt,washer and spacer to fix the holes of TV rear. (Figure 4) If the back of TV is not flat, or the bolts used to assemble TV are too long, or there is interfere between TV bracket and cable inlets, we highly recommend you to use spacers.
- Page 6 Step 5 Adjust the angle by loosening the two adjustable handles on the side to allow the TV to tilt forward to 15 degrees or back to 5 degrees (Figure 6). Once the desired tilt angle is achieved, tighten the handle to secure the television in the new position.
- Page 7 lIMIted WARRANty Helios® – Limited Warranty – Valid in the United States and Canada This 60 month limited warranty is provided by Metra Electronics Corporation for the Metra product identified by the purchaser’s registration as indicated below, and there are no other warranties, expressed or implied, except as required by law, including warranties of merchantability and fitness for a specific purpose, that are provided for herein, however all such implied warranties, if any, are limited to the duration of this specific limited product warranty.
- Page 8 ©2018 Metra Electronics Corporation, 460 Walker Street, Holly Hill, FL 32117-2699 Specifications are subject to change without notice. All trademarks are the property of their respective owners. 1-866-839-9187 • www.MetraHomeTheater.com...
