Reversing The Door Swing - GE SBSD227F Use And Care Manual

Reversing the door swing

IMPORTANT NOTES:
Read the instructions all the way through before starting.
Handle parts carefully to avoid scratching paint.
Set screws down by their related parts to avoid using them
in the wrong places.
Provide a non-scratching work surface for the doors.
Normal completion time to reverse the door swing is
30–60 minutes.
IMPORTANT: Once you begin, do not move the cabinet
until door-swing reversal is completed.
These instructions are for changing the hinges from the
right side to the left side—if you ever want to switch them
back to the right side, follow these same instructions and
reverse all references to the left and right.
TOOLS YOU WILL NEED
Cresent Wrench
(Adjustable)
Robertson-Head
Screwdriver
DOOR PARTS
Hinge Cover
Hinge Assembly
Large Tapping
Screw (#10) - 6
30
Putty Knife or Thin-
Blade Screwdriver
Plastic Cover
Washer - 2
Nut (#8) - 2
Tapping
Machine
Screw (#8) - 2
Screw (#8) - 6
BEFORE YOU START
1
Unplug the dryer from its electrical outlet.
REMOVE DOOR ASSEMBLY
2
Open the door to approximately 90 degrees. Remove the
4 screws starting from the bottom to the top. Make sure
the door is supported while removing the screws.
Loosen the top screw as shown. Unhook the door by
lifting and pulling as shown by the arrows.
Remove
the 4
screws.
