INSTALLING THE STACK BRACKET KIT

1. Remove the Dryer
Leveling Legs
A. Carefully lay the dryer on its side.
B. Use an open-end wrench or pliers to
Back out and remove all
4 leveling legs
2. Install Rubber Pads
to Dryer Base
Locate the 4 rubber pads in the parts
package. Remove the adhesive backing
and firmly place over on the bracket
where you removed the leveling legs.
3. Install Bracket
to Dryer
A. Align the holes in the left bracket with
B. Repeat the above step with the right
C. Set the dryer upright.
Use the packing material so you
don't scratch the finish on the dryer.
remove the dryer leveling legs.
the holes in the bottom left corner of
the dryer. Use a Phillips screwdriver
to install the 2 #12 x 1" tapping
screws.
bracket on the bottom right corner of
the dryer.
www.GEAppliances.ca
NOTE: Make sure to set the dryer on
a piece of packing material so the
brackets that are attached to the
bottom of the dryer do not damage the
floor.
