HDMITM Extender over 5-Wire
(RGBHV or 5 x RCA) up to 330ft
with Bi-directional IR
AT-HD-RG100SR
User Manual
Toll free: 1-877-536-3976
www.atlona.com
Local: 1-408-962-0515

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AT-HD-RG100SR and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Atlona AT-HD-RG100SR

  • Page 1 HDMITM Extender over 5-Wire (RGBHV or 5 x RCA) up to 330ft with Bi-directional IR AT-HD-RG100SR User Manual Toll free: 1-877-536-3976 www.atlona.com Local: 1-408-962-0515...
  • Page 2: Table Of Contents

    6. IR Pass-through 6.1. IR Extenders 6.2. IR Sockets 6.3. Definition of IR Earphone Jack 6.4. Supported IR Data Format 7. HDMI Pin Definition 8. Coaxial Cable 9. Safety Information 10. Warranty 11. Atlona Product Registration Toll free: 1-877-536-3976 www.atlona.com Local: 1-408-962-0515...
  • Page 3: Introduction

    Bi-Directional IR also gives advantage to user to control display via Control System by sending commands (such as on/off, input change, etc...) from Control System to Display. The AT-HD-RG100SR comes with one transmitting module and one receiving module. Both transmitter mod- ules are based on the HDMI 1.3C and HDCP 2.0 and therefore are compatible with:...
  • Page 4: Specification

    Interlocking power supply & wall-mount case with screws Power supply +5V 2A DC Power consumption 3 Watts [max] Operation temperature 0~40 C [32~104 Storage temperature -20~60 C [-4~140 Relative humidity 20~90% RH [no condensation] Toll free: 1-877-536-3976 www.atlona.com Local: 1-408-962-0515...
  • Page 5: Panel Descriptions

    3. HDMITM IN: connect to a HDMITM source device with a HDMITM male-male cable here 4. +5V DC: connect to 5V DC power supply unit 1.2. Rear Panel 2. Receiving Module 2.1. Front Panel Toll free: 1-877-536-3976 www.atlona.com Local: 1-408-962-0515...
  • Page 6: Rear Panel

    Incorrect placement of IR Blaster and Receiver may result in the failure of the IR extenders. Please check carefully before plugging in the IR extender to the respective IR sockets. Warranty will not cover the damage. Toll free: 1-877-536-3976 www.atlona.com Local: 1-408-962-0515...
  • Page 7: Definition Of Ir Earphone Jack

    GRUNDIG CODE SONY 12 BIT CODE SONY 15 BIT CODE SONY 20 BIT CODE RCA CODE RCM CODE MATSUSHITA CODE MITSUBISHI CODE ZENITH CODE JVC CODE M50560-001P MN6125H MN6125L MN6014_C5D7 MN6014_C6D6 MC14457P LC7464(AHEA) GEMINI_CM Toll free: 1-877-536-3976 www.atlona.com Local: 1-408-962-0515...
  • Page 8: Hdmi Tm Pin Definition

    0.346 2.02 0.799 0.243 0.799 2.83 1.440 0.439 1.440 4.05 2.840 1500 0.855 2.840 5.60 3.360 2000 1.020 3.360 6.23 2500 1.170 3.840 1000 6.59 1200 7.50 1450 8.10 1800 8.95 2200 9.98 3.840 Toll free: 1-877-536-3976 www.atlona.com Local: 1-408-962-0515...
  • Page 9: Safety Information

    It may also cause damage to your AT-HD- RG100SR. Opening the product will void the warranty. Do not attempt to service the unit. Disconnect the product and contact your authorized Atlona reseller or con- tact Atlona directly.
  • Page 10: Warranty

    To the maximum extent permitted by applicable law, in no event shall Atlona Technologies or its suppliers be liable for any damages arising out of the use of or inability to use this product, even if Atlona Technologies has been advised of the possibility of such damages. Such damages include but are not limited to: special, inciden- tal, consequential, or indirect damages for personal injury, loss of business profits, business interruption, loss of business information, or any other pecuniary loss.
  • Page 11: Atlona Product Registration

    ATLONA PRODUCT REGISTRATION Thank you for purchasing this Atlona product. - We hope you enjoy it and will take an extra few moments to register your new purchase. Registration creates an ownership record if your product is lost or stolen and helps ensure you’ll receive notification of performance issues and firmware updates.
