AMX Mio R-3 Quick Start Manual

Overview
The Mio R-3 remote (FG148-03) provides custom control features, contained in
an elegant handheld rechargeable device. The Mio R-3 communicates with a
NetLinx master via a wireless ZigBee® network. The Mio R-3 is pre-loaded with
firmware that allows joining to ZigBee Pro 2007 networks, but may be upgraded
with firmware allowing access to older ZigBee 2004 networks.
You need VisualArchitect and KeypadBuilder to properly program this device.
The application and documentation are available from www.amx.com.
1
1
3
2 4
5 6 7
8 9
4 5
10 11
1 - Power
12
2 - Record
6
3 - Pause
13 8 10 14 9 15
4 - Stop
5 - Rewind
16 17
2 3
7
18 6 - Play
15
7 - Fast Forward
19 20 21
13
11
8 - Skip Back
16
22
9 - Skip Forward
14
12
23 24
10 - Menu
11 - Info
12 - Move Up
13 - Move Left
25 26
26
28
Numeral Keypad
FIG. 1
The MIO R-3 Device
Touch And Tilt Sensor
The MIO R-3 wakes up upon touching either the chrome side rails or pressing a
button. When the remote times out while holding it, you can reawaken the device
by tilting it. Errant jostling such as a bumped table will not wake the device
unless you are holding it.

Specifications

The MIO R-3 device specifications are as follows:
MIO R-3 (FG148-03) Specifications
Dimensions 9.50 x 2.00 x .74 (241.3 mm x 50.8 mm x 18.80 mm)
(HWD)
Weight • .45 lbs (20 g) without batteries
• .55 lbs (25 g) with batteries
Battery Rechargeable Lithium-Ion
Transmission • Zigbee RF wireless network
Frequencies • IR 38 Khz
• IR 455 Khz
Transmission • ZigBee: 100 feet (30.48m)
Range • IR 38 Khz: 100 feet (30.48m)
• IR 455 Khz: 50 feet (15.24m)
Top Components • LED - blue backlit buttons indicate device is awake
• Display (OLED) - 128 x 32 pixels, active area is 29.42mm x
7.98mm
• Pushbuttons - the power button is red backlit; the rest are blue
backlit buttons. 45 buttons; 9 custom buttons (3 macro and 6
device).
MIO R-3 (FG148-03) Specifications (Cont.)
Rear Component • Programming Port - 2.5 mm stereo female conductor jack
Supported
Languages
Power
Certifications
Transmission Mode
Current Menu
Battery Meter
Custom Macro
Buttons
Operating
Environment
Custom Mode
Options
Included Items
Other AMX
Equipment
14 - Select
15 - Move Right
16 - Guide
17 - Exit
18 - Move Down
Installing Your Custom Buttons
19 - Volume Up
1.
20 - Last Selected
21 - Channel Up
2.
22 - Mute
23 - Volume Down
24 - Channel Down
3.
25 - Input
26 - Enter
FIG. 2
4.
5.
6.
7.
8.
9.
10. Place the battery door back on the device, and slide the door upwards to
Inserting the Lithium-Ion Battery into The MIO R-3
To install your Lithium-Ion battery into the MIO R-3 remote:
1.
Quick Start Guide
MIO R-3
Mio Modero
• Battery Door
• Rechargeable Battery Connection
• English • Korean
• French • Simplified Chinese
• German • Portuguese
• Greek • Russian
• Italian • Spanish
• Japanese • Other languages supported by Glyphs
• FCC ID: CWU-NXR-MO
• IC: 5078A-NXRMO
• CE
• IEC-60950
• Japan Approval
• Designed for ZigBee
• Operating Temperature: 0° to 40° C (32° to 104° F)
• Storage Temperature: -20° to 70° C (-4° to 158° F)
• Relative Humidity: 5% to 85%
• MIO-RBP Rechargeable Lithium-ion Battery (FG147-10)
• DB-9 extension cable (FG10-727)
• Programming Cable - a 3 wire, 2.5 mm stereo jack (FG10-817)
• Custom engraving (FG147-01)
• MIO-RCC Kit (FG147-03K)
• MIO-RCC Charging Base (FG147-02)
• NXR-ZGW (FG5791-01)
• NXR-ZRP-PRO (FG5791-03)
Flip and turn the MIO R-3 device so that the buttons are facing away from
you and the device is upside down.
Holding the device in both hands, place your thumbs on the battery door
and push up to slide the battery door free. The battery door will slide in the
direction of the bottom end of the device.
Unscrew the 6 screw points indicated in FIG. 2.
Programming Jack
Internal MIO R-3 Components
Turn the unit over so the buttons are facing you.
Lift the top assembly away from the PCB.
If necessary, push out the standard buttons from the front of the top assem-
bly.
Drop on your custom button pad and verify the alignment with the guide
posts on the PCB.
Place the top assembly back down on the PCB and return the unit over,
exposing the 6 screw points.
Tighten the 6 screw points.
lock it in place.
Flip and turn the device so that the buttons are facing away from you and
the device is upside down.
Remote
®
6 Screw Points
