Keypad Features

The keypads control the system's
power and all its functions. The system
can be controlled by any keypad in the
installation.
The keypads have soft blue lighting
that stays on for about 20 seconds after
any key is pressed. As a power-saving
feature, after 20 seconds the keypad
lighting will slowly dim
SOURCE INDICATORS
INDICATORS LIGHT TO SHOW THE SELECTED
AUDIO SOURCE FOR THE KEYPAD
INDICATORS BLINK IN EQUALIZER ADJUST
AND PARTY MODES
VOLUME LIGHTS
DISPLAYS THE KEYPAD'S VOLUME SETTING
ALSO USED TO DISPLAY EQUALIZER SETTINGS
4
PRESS TO ADJUST EQ SETTINGS
USE SOURCE BUTTON TO CYCLE THROUGH OPTIONS
USE VOL BUTTONS TO ADJUST LEVELS
BASS ADJUST - SOURCE 1 LIGHT FLASHING
TREBLE ADJUST - SOURCE 2 LIGHT FLASHING
LEFT/RIGHT BALANCE ADJUST - SOURCE 3 LIGHT FLASHING
LOUDNESS (BASS BOOST) ON/OFF - SOURCE 4 LIGHT FLASHING
LIMITER/COMPRESSOR ON/OFF - LOCAL SOURCE LIGHT FLASHING
PRESS TO MUTE THE KEYPAD'S SPEAKERS
TO UN-MUTE THE SPEAKERS, PRESS MUTE AGAIN
PRESSING VOL OR SOURCE BUTTONS WILL ALSO UN-MUTE
THE KEYPAD'S SPEAKERS
PRESS AND HOLD FOR 3 SECONDS TO DISABLE OR ENABLE
WHOLE-HOUSE MODE FOR THIS KEYPAD
POWER BUTTON
PRESS TO TURN KEYPAD POWER ON OR OFF
PRESS FOR 3 SECONDS TO TURN POWER OFF
ON ALL KEYPADS
The system
components can be operated by
pointing the appropriate IR remote
control at the keypad.
INFRARED SENSOR
DETECTS INFRARED SIGNALS FROM
REMOTE CONTROLS
INFRARED SIGNALS ARE PASSED ON TO
THE SOURCE COMPONENTS
SOURCE BUTTON
PRESS TO SELECT ONE THE FOUR HUB SOURCES
OR THE LOCAL (L) KEYPAD INPUT SOURCE
PRESS AND HOLD FOR 3 SECONDS TO
TURN WHOLE-HOUSE MODE ON OR OFF
VOLUME BUTTON
PRESS UP ARROW TO INCREASE VOLUME
PRESS DOWN ARROW TO DECREASE VOLUME
ALSO USED FOR ADJUSTMENTS IN EQ MODE
EQ BUTTON (EQUALIZER)
MUTE BUTTON
and audio source
