System Operation
Equalizer & Audio Dynamics

Adjusting the Keypad's Sound

EQ button to enter equalizer
• Press the
adjustment mode. Press EQ again to exit.
• Equalizer adjustment mode automatically
exits after 30 seconds of keypad inactivity.
• The source indicators will light up, then one
will flash to indicate that the keypad is in
equalizer adjustment mode.
• Use the SOURCE button to cycle
through the five adjustment modes.

Bass Adjust

• When source indicator
keypad is in bass adjust mode.
• The center volume indicator will light,
showing a "flat" adjustment for the bass, no
bass increase or decrease.
VOL ▲ and VOL ▼ buttons to
• Use the
adjust the bass level. Lit indicators above
the center show more bass. Lit indicators
below the center show less bass.

Treble Adjust

• When source indicator
keypad is in treble adjust mode.
• The center volume indicator will light,
showing a "flat" adjustment for the treble,
no treble increase or decrease.
VOL ▲ and VOL ▼ buttons to
• Use the
adjust the treble level. Lit indicators above
the center show more treble. Lit indicators
below the center show less treble.

Balance Adjust

• When source indicator
keypad is in balance adjust mode.
• The center volume indicator will light,
showing a "center" adjustment for the
balance, no extra left or right.
VOL ▲ and VOL ▼ buttons to
• Use the
adjust the balance. Lit indicators above
the center show more right balance. Lit
indicators below the center show more left
balance.
8
1 is flashing, the
2 is flashing, the
3 is flashing, the

Loudness On/Off

• When source indicator
keypad is in loudness setting mode.
• When the loudness setting is on, extra
bass is added to improve the sound when
listening at low volume levels.
VOL ▲ button to turn this option
• Use the
on (the top volume indicator lights).
VOL ▼ button to turn this option off
• Use the
(the bottom volume indicator lights).

Limiter/Compressor On/Off

• When source indicator
keypad is in limiter/compressor mode.
• Loudness adds extra bass. Limiter/
compressor automatically limits volume.
VOL ▲ button to turn this option
• Use the
on (the top volume indicator lights).
VOL ▼ button to turn this option off
• Use the
(the bottom volume indicator lights).
PRESS VOL UP OR VOL DOWN
TO ADJUST THE LEVEL
CENTER LIGHT
INDICATES A FLAT SETTING
PRESS VOL UP OR VOL DOWN
TO ADJUST THE BALANCE
LIGHTS ABOVE CENTER = MORE RIGHT
LIGHTS BELOW CENTER = MORE LEFT
CENTER LIGHT
INDICATES A CENTER BALANCE SETTING
PRESS VOL UP TO TURN LOUDNESS ON
PRESS VOL DOWN TO TURN LOUDNESS OFF
TOP LIGHT = LOUDNESS ON
BOTTOM LIGHT - LOUDNESS OFF
4 is flashing, the
L is flashing, the
BASS & TREBLE ADJUST
LIGHTS ABOVE CENTER = MORE
LIGHTS BELOW CENTER = LESS
BALANCE ADJUST
LOUDNESS SETTING
