- Page 1 USERS MANUAL P15&P15S HEARTWAY MEDICAL PRODUCTS CO., LTD. Part no:70030114...
- Page 2 COMPONENTS Your power wheelchair is shipped partially dissembled to protect it during shipping. After unpacking, please check whether you have received the following main components as our standard specification (See Fig.1). 1. Main frame with motor 4. Controller 2. Saddle set 5.Charger 3.
-
Page 3: Safety Instruction
1-1/2”(40mm) height. Transfers, Reaching and Bending ansferring on and off the P15 requires a good sense of balance. To elimi-nate the possibility of injury, We recommends performing the following tasks before attempting a transfer: → Position chair so that the distance between your power chair and the object to which you are transferring is close enough for a safe transfer. -
Page 4: Use While Under The Influence Of Medication Or Alcohol
General Always use a seat belt, and keep feet on the footplate at all the time. 12. For safety reasons, make sure that your weight does not exceed the recommended weight limit of the wheelchair. Consult your dealer for the specified weight limits for your particular model. 13. - Page 5 sources) can cause the powered wheelchair to release its brakes, move by itself or move in unintended directions. It can also permanently damage the powered wheelchair’s control system. The inten- sity of the EM energy can be measured in volts per meter(V/m).Each powered wheelchair can resist EMI up to a certain intensity.
-
Page 6: Environmental Conditions
ENVIRONMENTAL CONDITIONS Environmental conditions may affect the safety and performance of your power wheelchair. Water and extreme temperatures are the main elements that can cause damage and affect performance. A) Rain, Sleet and Snow If exposed to water, your power wheelchair is susceptible to damage to electronic or mechanical components. - Page 7 ASSEMBLY INSTRUCTION 1. Installing the Saddle set (#4) and Seat (#3) Unfold the saddle (See Fig 2) and slide the saddle set (#4) into the connection points (both sides) in the Main frame (#1)(See Fig 3), put down the saddle set and connect the front connection point. The pin will lock automatically in the front connection point.
- Page 8 (Fig 5) (Fig 6) 4 pins Connector (Fig 7) (Fig 8) Installing the Battery box Lift the battery box, aim at the battery male connector and the female connector on the main frame (See Fig 8). Make sure the tension knob locate on the horizontal position.(See Fig 9) And put the rear hole of the battery box into the tension knob.
-
Page 9: Adjustments For Seating Confort
ADJUSTMENTS FOR SEATING CONFORT To maximize seating comfort, your power wheelchair lets you adjust: →Anti-tipper height D. Anti-Tipper Height Adjustment → Take away the C-Clip → slide the anti-tipper tube to your desired height → Insert the C-Clip into the tube.(See Fig 11,12, 13 ) (Fig 11) (Fig 12) (Fig 13) -
Page 10: Operation
For indoor environments we recommend that you select the slowest speed setting. For outdoor operation of this vehicle we recommend that you select a speed that is comfortable for you to control it safely. he following steps are required to operate your vehicle safely with the P15 controller (See Fig 14) Battery ON/OFF... -
Page 11: Controller Display
be. To operate the vehicle gently push the joystick in the direction you want to go. Returning the joystick to its neutral position,(center), will reduce the speed and stop the vehicle by automatically applying the electro- magnetic brakes. Notes: →After pressing the controller ON/OFF switch, allow two seconds to elapse before engaging the joystick. -
Page 12: Thermal Protection
Breaker (Fig 15) (Fig 16) D. Electromagnetic Brakes: Your power wheelchair comes with an Electromagnetic Brakes., i.e. an automatic magnetic disc safety brake which is also known as Fail-Safe brake. The Electromagnetic Brakes are automatic and work when the power wheelchairs is ON but in a steady state (i.e. -
Page 13: Batteries And Charger
BATTERIES & CHARGER BATTERY We recommend that you use deep-cycle batteries that are sealed and maintenance free for your power wheelchair. Both sealed lead-acid (SLA) and gel cell are deep-cycle batteries and are similar in performance. Deep-cycle batteries are specifically designed to provide power, drain down, and then accept a relatively quick recharge. - Page 14 plug-in controller plug-in wall outlet- (Fig 17) (Fig 18) Note: →Always charge your batteries in well ventilated areas. →The charger is intended for indoor use only. Protect from moisture. →For maximum performance , it is recommended that you replace both batteries at the same time if the batteries are weak.
-
Page 15: Maintenance And Repair
MAINTENANCE & REPAIR Your power wheelchair is designed for minimal maintenance. However, like any motorized vehicle it requires routine maintenance. To keep your HP7R for years of trouble-free operation, we recommend you follow the following maintenance checks as scheduled. DAILY CHECKS 1. -
Page 16: Periodical Checks
New Motor Brush Worn Motor Brush Motor Brush caps (Fig 41) (Fig 42) 1. Inspect the state of the battery terminals every six months. Make sure that they are not corroded and the connections are tight. Periodically apply a thin film of petroleum jelly on the surface of terminals to guard against corrosion. -
Page 17: Diagnosis And Solution
DIAGNOSIS AND SOLUTION FLASHING LIGHTS The battery needs charging or there is a bad connection to the battery. Check the connections to the battery. If the connect- ions are good, try charging the battery. The left motor has a bad connection. Check the left motor connection.
