Heartway Medical Products P4ASR User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
USERS
MANUAL
P4ASR
HEARTWAY MEDICAL PRODUCTS CO., LTD.
Part no:70030126
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the P4ASR and is the answer not in the manual?

Questions and answers

Related Manuals for Heartway Medical Products P4ASR

Summary of Contents for Heartway Medical Products P4ASR

  • Page 1 USERS MANUAL P4ASR HEARTWAY MEDICAL PRODUCTS CO., LTD. Part no:70030126...
  • Page 2 COMPONENTS Your power wheelchair is shipped partially disassembled for protection during shipping. After unpacking, please check whether you have received the following main components as our standard specification (See Fig.1). 1. Main frame with motor 7. Footrest (Left) 2. Backrest 8.Controller 3.

  • Page 3: Safety Instruction

    9. When driving up curbs, always check the height of the curb to ensure that it does not exceed 1-1/2”(40mm) height. Transfers, Reaching and Bending 10. Transferring on and off the P4ASR requires a good sense of balance. To eliminate the possibility of injury, we recommend performing the following tasks before attempting a transfer: →...

  • Page 4: Use While Under The Influence Of Medication Or Alcohol

    11. When reaching, bending or leaning while seated on your power chair, make sure that you maintain a stable center of gravity to keep the power chair from tipping. General 12. Always use a seat belt, and keep feet on the footplate at all times. 13.
  • Page 5 which is interfering electromagnetic energy emitted from sources such as radio stations, TV stations, amateur radio (HAN) transmitter, two-way radios and cellular phones. The interference (from radio wave sources) can cause the powered wheelchair to release its brakes, move by itself or move in unintended directions. It can also permanently damage the powered wheelchair’s control system.

  • Page 6: Environmental Conditions

    ENVIRONMENTAL CONDITIONS Environmental conditions may affect the safety and performance of your power wheelchair. Water and extreme temperatures are the main elements that can cause damage and affect performance. A) Rain, Sleet and Snow If exposed to water, your power wheelchair is susceptible to damage to electronic or mechanical components.
  • Page 7 ASSEMBLY INSTRUCTION 1. Installing the Saddle set and Seat Connection point (Fig 2) Slide the saddle set (#3,4) into the Connection points(both sides) in the main frame (#1)(See Fig 2), put down the saddle set and connect the front connection point and make sure that tighten the tension knob in the front connection point.(See Fig 3).Tight up the tension knob on the front of both sides.(See Fig 4).
  • Page 8 Allen Key Wrench (Fig 5) (Fig 6) 2. Installing the skirt guard and Armrest 2-1 Install the skirt guards (#10,#11) Place the skirt guard bracket on the seat frame and go through the 2 *M8 bolts into the holes of the seat frame.(See Fig 7), Use the Allen key and wrench to tighten the bolts and nuts(See Fig 8).

  • Page 9: Installing The Backrest

    2-2 Install the Armrest Lift up the armrest bottom tube, take off the E- plastic clip and slide the armrest up tube into the bottom tube (See Fig 11). Then insert the E-plastic clip into the correct location. (See Fig 12) E-plastic clip (Fig 11)
  • Page 10 (Fig 15) (Fig 16) 4. Installing the Headrest Loosen the lever of saddle set, put the headset (#5) into the clamp then fasten the lever. (See Fig17) Saddle Lever (Fig 17 ) 5.Installing the Footrest Insert the footrest (with left-#7 and Right-#6 each) into footrest frame with side direction (See Fig 18) then turn 90 degree to correct direction and make sure the pin jumps into the correct position.
  • Page 11 (Fig 18 ) (Fig 19) 6.Installing Controller and Connect Cables Assemble the controller (#8) on right armrest bracket with 2 screws.(See Fig 20). There is 1 main plug (4 pins) in the other end on the controller. Please plug in the main frame (#1) plugs, then make sure tightly connection.(See Fig 21 ).

  • Page 12: Adjustments For Seating Confort

    ADJUSTMENTS FOR SEATING CONFORT To maximize seating comfort, your power wheelchair lets you adjust: →Armrest height and angle →Seat depth and width →Headrest angle →Backrest angle and width →Controller position A. Armrest Height and Angle Adjustment A-1:To adjust the Height: wrench (Fig 23) (Fig 24)
  • Page 13 B. Seat Depth and Width Adjustment B-1:To adjust the Depth (Fig 27) → use Allen keys to loosen the 4 bolts in footrest frame (Fig 27) → slide the footrest frame in or out for desired depth → tighten the bolts with Allen key B-2:To adjust the Width Bolts (Fig 28) →...
  • Page 14 C. Headrest Angle Adjustment → loosen the headrest lever (back the headrest) → turn the headrest to your desired angle (See Fig 29) → tighten the headrest lever Headrest Lever (Fig 29) D. Backrest Angle and Width Adjustment D-1:To adjust the Angle →...

  • Page 15: Controller Position Adjustment

    → slide in or out for backrest plastic parts (left and right) separately to your desired width(See Fig 32) → tighten the bolts and nuts D-2-2:To adjust the backrest tube → loosen the bolts with Allen key (No #5) → slide in or out for the tube (left and right) separately to your desired width (See Fig 33) →...

  • Page 16: Operation

    For outdoor operation of this vehicle we recommend that you select a speed that is comfortable for you to control it safely. The following steps are required to operate your vehicle safely with the controller-can use for P4ASR (See Fig 36) Battery ON/OFF...

  • Page 17: Controller Display

    3.Joystick The joystick controls the direction and speed of your vehicle, pointing the joystick away from the neutral position (center) will move the vehicle in the direction where the joystick is pointing. The farther away (forward/backward) the joystick is from the neutral position, the faster the vehicle will go. The farther away to the right/ left the joystick is pointing, the sharper the turn of the vehicle will be.

  • Page 18: Free-Wheeling

    Note: When the batteries begin to approach a discharged state, the first red LED will begin to flash slowly, reminding you that the batteries need to be charged immediately. C. Free-Wheeling: Because the motors are designed to engage the electromagnetic brakes when the vehicle is not in use or when the power is OFF.

  • Page 19: Main Circuit Breaker

    F. Main Circuit Breaker: Please see Fig 38 to check the circuit breaker location in P4ASR. Breaker (Fig 38) The main circuit breaker monitors the electric current drawn from the battery. It is a safety feature built in your power wheelchair for your extra safety.

  • Page 20: Batteries And Charger

    BATTERIES & CHARGER BATTERY We recommend that you use deep-cycle batteries that are sealed and maintenance free for your power wheelchair. Both sealed lead-acid (SLA) and gel cell are deep-cycle batteries and are similar in performance. Deep-cycle batteries are specifically designed to provide power, drain down, and then accept a relatively quick recharge.
  • Page 21 →Disconnect the charger power cord from the wall outlet when the batteries are fully charged. (See Fig 39) Important! Do not use for voltage input unless specified. Make sure your present voltage input (110V or 220V) and adjust manually. (See Fig 40) plug-in controller plug-in wall outlet (Fig 40) (Fig 39)

  • Page 22: Maintenance And Repair

    MAINTENANCE & REPAIR Your power wheelchair is designed for minimal maintenance. However, like any motorized vehicle it requires routine maintenance. To keep your P4ASR for years of trouble-free operation, we recommend you the following maintenance checks as scheduled. DAILY CHECKS 1.
  • Page 23 Warning! Failure to maintain the brushes could void the power wheelchair warranty. o inspect or replace the motor brushes: 1.Unscrew the motor brush caps. (See Fig 41) 2.Remove the brushes. 3.Inspect the brushes for wear. (See Fig 42) 4.Replace the brushes if necessary. Motor Brush caps New Motor Brush Worn Motor Brush...
  • Page 24 If you get one of these error codes, contact your local dealer. DIAGNOSIS AND SOLUTION FLASHING LIGHTS The battery needs charging or there is a bad connection to the battery. Check the connections to the battery. If the connect- ions are good, try charging the battery. The left motor has a bad connection.
