- Page 1 USERS MANUAL HW1P HW1J HEARTWAY MEDICAL PRODUCTS CO., LTD. Part no: 70030169...
-
Page 2: Table Of Contents
TABLE OF CONTENTS INTRODUCTION & SAFETY…...............….…………………….……3 SPECIFICATIONS………………………………………………...…………………………….……….4 HEAD REST, ARM REST & PUSH HANDLE ADJUSTM………………………………………..…..6 ELEVATING REST ADJUSTMEN….………………………...………………………………………7 ATTENDANT & MANUAL BRAKE SYSTEM…………………..….………………………………8 MANUAL & POWER RECLINING & TILTING FUNCION..….……………………………………9 BATTERY CHARGING GUIDE……………………………………………………………………….10 SPARE PARTS DRAWINGS………………………………………………………………………….13 MAINTENANCE……………………………………………………………………………………….15... -
Page 3: Introduction & Safety
1. INTRODUCTION & SAFETY Welcome to Heartway Medical Products Co., Ltd. We truly appreciate your new purchase order on our model HW1/HW1P/HW1J. We are confident that this design features will provide you with the conveniences you expect during your daily activities. Once you understand how to safely operate this product for the first time, its safety and performance will give you years of trouble free operation and service. -
Page 4: Specifications
2. SPECIFICATIONS MODEL HW1 & HW1P 135kgs(300lbs) WEIGHT CAPACITY 8" x 2" FRONT CASTOR 24" DRIVE WHEEL LENGTH 45" (1150mm) WEIGHT(NW) 36.6KG(18") WEIGHT(NW)-HW1P 58KG(18") 26"(660mm)/27.5" (700 mm) /31.5"(800mm) WIDE HEIGHT 50" ~ 55.8" (1220~ 1420mm) SEAT WIDTH 16"/18"/22" SEAT HEIGHT 21"... - Page 5 MODEL HW1J 100 kgs (220lbs) WEIGHT CAPACITY 7" X 1.75" (178 mm X 45mm) FRONT CASTOR 20" (510mm) DRIVE WHEEL LENGTH 35.0" (890mm) WEIGHT(NW) 26 kg (57lbs) 23.0" (585mm) WIDTH HEIGHT 35" ~ 41" (890mm ~ 1040mm) SEAT WIDTH 14" (356mm) SEAT HEIGHT 18"...
-
Page 6: Head Rest, Arm Rest & Push Handle Adjustm
3. HEAD REST, ARM REST & PUSH HANDLE ADJUSTMENT Headrest Angle Adjustment Armrest Height Adjustment Headrest Height Adjustment Push Handle Adjustment... -
Page 7: Elevating Rest Adjustmen
4. ELEVATING LEG REST ADJUSTMENT Swing Away Function Elevating Function... -
Page 8: Attendant & Manual Brake System
5. ATTENDANT & MANUAL BRAKE SYSTEM Attendant Brake System Manual Brake System... -
Page 9: Manual & Power Reclining & Tilting Funcion
6. Manual & Power Reclining & Tilting Functions Manual Tilting(-5°~25° ) Press the LH-brake and force the handle downwards to adjust the angle. Manual Reclining (90°~120°)– Press the RH-brake and force the handle downwards to adjust the angle. Power Tilting– Press the button (2) to Button (1) Button (2) - Page 10 7. SEALED LEAD ACID BATTERIES USER’S GUILD 7.1 - Battery Specification: 7.2 - Battery Power Depletion Chart: Storage Temperature/Time/Capacity Table...
-
Page 11: Battery Charging Guide
7.3 - Battery Charging Guide: Remove the connector covers from a battery box to insert DC IN socket indicated at the left side of LAK B box, and then plug in power cord. The CPU in the control will automatically detect the battery capacity. If the power capacity is insufficient, it will automatically charge. -
Page 12: Charging The Batteries
7.5 Charging the batteries: The batteries of the power Tilting and Reclining functions have to be charged on a regular basis. Together with the control unit the batteries are place at a separate box beneath the seat. If the batteries are stored, pay heed to a dry and cool environment, to decelerate the natural discharge process during storage. -
Page 13: Spare Parts Drawings
8. SPARE PARTS DRAWINGS... -
Page 15: Maintenance
9 .MAINTENANCE Maintenance is an important part of wheelchair ownership. There are two types of maintenance: preventive (routine) and corrective. Preventive maintenance enables you to help extend the life of your wheelchair by catching potential problems before it becomes necessary to correct them. Corrective maintenance is what you must do when your wheelchair needs immediate repair.
