- Page 1 USERS MANUAL HEARTWAY MEDICAL PRODUCTS CO., LTD. Part no:70030100...
- Page 2 COMPONENTS Your power wheelchair is shipped partially dissembled to protect it during shipping. After unpacking, please check whether you have received the following main components as our standard specification (See Fig.1). 1. Main frame with motor 5. Footrest( right ) 2.
-
Page 3: Safety Instruction
9. When driving up curbs, always check the height of the curb to ensure that it does not exceed 1-1/2”(40mm) height. Transfers, Reaching and Bending ansferring on and off the P13 requires a good sense of balance. To elimi- nate the possibility of injury, We recommends performing the following tasks before attempting a transfer: →... -
Page 4: Use While Under The Influence Of Medication Or Alcohol
11. When reaching, bending or leaning while seated on your power chair, make sure that you maintain a stable center of gravity to keep the power chair from tipping. General Always use a seat belt, and keep feet on the footplate at all the time. 12. - Page 5 soon as it is safe. 4.Be aware that adding accessories or components, or modifying the powered wheel- chair, may make it more susceptible to interference from radio wave sources.(Note: It is difficult to evaluate the effect on the overall immunity of the powered wheel- chair).
-
Page 6: Environmental Conditions
ENVIRONMENTAL CONDITIONS Environmental conditions may affect the safety and performance of your power wheelchair. Water and extreme temperatures are the main elements that can cause damage and affect performance. A) Rain, Sleet and Snow If exposed to water, your power wheelchair is susceptible to damage to electronic or mechanical components. -
Page 7: Assembly Instruction
ASSEMBLY INSTRUCTION 1. Installing the Seat (#3) Connection (Fig 2) Slide the seat (#3) into the Connection points(both sides) in the Main frame (#1)(See Fig 2), put down the saddle set and connect the front connection point. (See Fig 3) and make sure that tighten the tension knob in the front connection point. - Page 8 Allen Key Wrench (Fig 5) (Fig 6) 2. Installing the Armrest Lift up the armrest bottom tube, take off the E- plastic clip (See Fig 7) and slide the armrest up tube into the bottom tube (See Fig 8). Then insert the E-plastic clip into the correct location.
-
Page 9: Pin Location
3. Installing the Backrest Put the backrest (#2) into the saddle set. Make sure the round tube fit into the U bracket and the pin locate in correct position (See Fig 10). Pin location U Bracket (Fig 10) nsert the spring pin into the hole (in U bracket) and let the spring to attach the other end. - Page 10 Saddle set lever (Fig 13 ) 5.Installing the Footrest Insert the footrest ( with Right-#5 and left-#6 each) into footrest frame with side direction (See Fig 14) then turn around 90 degree to correct direction (See Fig 15) and make sure the pin jumping into the correct position. (See Fig 16) (Fig 14) (Fig 15) (Fig 16)
- Page 11 6.Installing Controller and Connect Cables Assemble the controller (#7) on right armrest bracket with 2 screws.(See Fig 17). There is 1 main plug (4 pins) in the other end on the controller. Please plug in the main frame (#1) plugs, then make sure tightly connection.(See Fig 18 ). 4 pins plug Controller (Fig 17)
-
Page 12: Adjustments For Seating Confort
ADJUSTMENTS FOR SEATING CONFORT To maximize seating comfort, your power wheelchair lets you adjust: →Armrest height and angle →Seat depth and width →Headrest angle →Backrest angle and width →Controller position A. Armrest Height and Width Adjustment 1:To adjust the Height: wrench (Fig 22) (Fig 23) - Page 13 B. Seat Depth and Width Adjustment B-1:To adjust the Depth 4 bolts (Fig 26) → use Allen keys to loosen footrest frame 4 bolts (Fig 26) → slide the footrest frame in or out for desired depth → tighten the bolts with Allen key B-2:To adjust the Width Bolts (Fig 27)
- Page 14 C. Headrest Angle Adjustment → loosen the headrest lever (back of the headrest) → turn the headrest to your desired angle (See Fig 28) → tighten the headrest lever Headrest lever (Fig 28) D. Backrest Angle and Width Adjustment D-1:To adjust the Angle →...
-
Page 15: Controller Position Adjustment
→ slide in or out for backrest plastic parts (left and right) separately to your desired width(See Fig 31) → tighten the bolts and nuts D-2-2:To adjust the backrest tube → loosen the bolts with Allen key (No #5) → slide in or out for the tube ( both left and right) separately to your desired width (See Fig 32) →... -
Page 16: Operation
For outdoor operation of this vehicle we recommend that you select a speed that is comfortable for you to control it safely. The following steps are required to operate your vehicle safely with the controller-can use for P13 (See Fig 34) Battery ON/OFF... -
Page 17: Controller Display
settings while the speed will slow down if you press the speed-decreasing button. The controller sets the reverse speed, acceleration and deceleration proportion- ally and automatically for your safety. 3.Joystick The joystick controls the direction and speed of your vehicle, pointing the joystick away from the neutral position (center) will move the vehicle in the direction where the joystick is pointing. -
Page 18: Free-Wheeling
→Red LEDs indicate that you should charge the batteries as soon possible, because low battery voltage may cause your power wheelchair to become inoperative. Note: When the batteries begin to approach a discharged state, the first red LED will begin to flash slowly, reminding you that the batteries need to be charged immediately. - Page 19 E. Thermal Protection: Your power wheelchair controller is equipped with a safety system called thermal rollback. A built-in circuit monitors the temperature of the controller and motors, the controller reduces the motor voltage and speed of the power wheelchair. The reduction of the speed allows the electrical components to cool down.
-
Page 20: Batteries And Charger
BATTERIES & CHARGER BATTERY We recommend that you use deep-cycle batteries that are sealed and maintenance free for your power wheelchair. Both sealed lead-acid (SLA) and gel cell are deep-cycle batteries and are similar in performance. Deep-cycle batteries are specifically designed to provide power, drain down, and then accept a relatively quick recharge. - Page 21 fully charged. (See Fig 37) Important! Do not use for voltage input except the specified. Make sure your present voltage input (110V or 220V) and adjust manually. (See Fig 38) plug-in controller plug-in wall outlet- (Fig 37) (Fig 38) Note: →Always charge your batteries in well ventilated areas.
-
Page 22: Maintenance And Repair
MAINTENANCE & REPAIR Your power wheelchair is designed for minimal maintenance. However, like any motorized vehicle it requires routine maintenance. To keep your HP7R for years of trouble-free operation, we recommend you follow the following maintenance checks as scheduled. DAILY CHECKS 1. - Page 23 Warning! Failure to maintain the brushes could void the power wheelchair warranty. To inspect or replace the motor brushes: 1.Unscrew the motor brush caps. (See Fig 39) 2.Remove the brushes. 3.Inspect the brushes for wear. (See Fig 40) 4.Replace the brushes if necessary. New Motor Brush Worn Motor Brush Motor Brush caps...
- Page 24 If you get one of these error codes, contract your local dealer. DIAGNOSIS AND SOLUTION FLASHING LIGHTS The battery needs charging or there is a bad connection to the battery. Check the connections to the battery. If the connect- ions are good, try charging the battery. The left motor has a bad connection.
