Summary of Contents for Heartway Medical Products HP6RT
- Page 1 USERS MANUAL HP6RT HEARTWAY MEDICAL PRODUCTS CO., LTD. Part no:70030061...
- Page 2 COMPONENTS Your power wheelchair is shipped partially disassembled for protection during shipping. After unpacking, please check whether you have received the following main components as our standard specification (See Fig.1). 1. Main frame with motor 7. Footrest (Left) 2. Backrest 8.Controller 3.
-
Page 3: Safety Instruction
9. When driving up curbs, always check the height of the curb to ensure that it does not exceed 1-1/2”(40mm) height. Transfers, Reaching and Bending ansferring on and off the HP6RT requires a good sense of balance. To elimi- nate the possibility of injury. We recommend performing the following tasks before attempting a transfer: →... -
Page 4: Use While Under The Influence Of Medication Or Alcohol
The United States Food and drug Administration (FDA) suggests that the following statement be incorporated to the user’s manual for all power wheelchairs like the HP6RT. 2.Be aware of nearby transmitters such as radio or TV stations and try to avoid... - Page 5 3.If unintended movement or brake release occurs, turn the powered wheelchair off as soon as it is safe. 4.Be aware that adding accessories or components, or modifying the powered wheel- chair, may make it more susceptible to interference from radio wave sources.(Note: It is difficult to evaluate the effect on the overall immunity of the powered wheel- chair).
-
Page 6: Environmental Conditions
ENVIRONMENTAL CONDITIONS Environmental conditions may affect the safety and performance of your power wheelchair. Water and extreme temperatures are the main elements that can cause damage and affect performance. A) Rain, Sleet and Snow If exposed to water, your power wheelchair is susceptible to damage to electronic or mechanical components. - Page 7 ASSEMBLY INSTRUCTION 1.Installing the Saddle set and Seat Connection point (Fig 2) Slide the saddle set (#4) into the Connection points (both sides) in the main frame (#1)(See Fig 2), put down the saddle set and connect the front connection point and make sure that tighten the tension knob in the front connection point.(See Fig 3).
- Page 8 Allen Key Wrench (Fig 5) (Fig 6) 2. Installing the skirt guard and Armrest 2-1 Install the skirt guards (#10,#11) Place the skirt guard bracket on the seat frame and go through the 2 *M8 bolts into the holes of the seat frame.(See Fig 7), Use the Allen key and wrench to tighten the bolts and nuts(See Fig 8).
-
Page 9: Installing The Backrest
2-2 Install the Armrest Lift up the armrest bottom tube, take off the E- plastic clip and slide the armrest up tube into the bottom tube (See Fig 11). Then insert the E-plastic clip into the correct location. (See Fig 12) E-plastic clip (Fig 11) - Page 10 (Fig 15) (Fig 16) 4. Installing the Headrest Loosen the lever of saddle set, put the headset (#5) into the clamp then fasten the lever. (See Fig17) Saddle Lever (Fig 17 ) 5.Installing the Footrest Insert the footrest (with left-#7 and Right-#6 each) into footrest frame with side direction (See Fig 18) then turn 90 degree to correct direction (See Fig 19) and make sure the pin jumps into the correct position.
- Page 11 (Fig 18 ) (Fig 19) (Fig 20) 6.Installing Controller and Connect Cables Assemble the controller (#8) on right armrest bracket with 2 screws.(See Fig 21). There are 1 main plug and 2 extended plugs. Please connect the 9 pins with the main frame (#1) plug and connect the other 2 plugs color by color (See Fig 22).You have to plug in the main frame for other cables (connect for color by color) and make sure they are tightly connected.(See Fig 23)
-
Page 12: Adjustments For Seating Confort
ADJUSTMENTS FOR SEATING CONFORT To maximize seating comfort, your power wheelchair lets you adjust: →Armrest height and angle →Seat depth and width →Headrest angle →Backrest angle and width →Controller position A. Armrest Height and Angle Adjustment A-1:To adjust the Height: wrench (Fig 24) (Fig 25) - Page 13 B. Seat Depth and Width Adjustment B-1:To adjust the Depth (Fig 28) → use Allen keys to loosen the 4 bolts in footrest frame (Fig 28) → slide the footrest frame in or out for desired depth → tighten the bolts with Allen key B-2:To adjust the Width Bolts (Fig 29) →...
- Page 14 C. Headrest Angle Adjustment → loosen the headrest lever (back the headrest) → turn the headrest to your desired angle (See Fig 30) → tighten the headrest lever Headrest Lever (Fig 30) D. Backrest Angle and Width Adjustment D-1:To adjust the Angle →...
-
Page 15: Controller Position Adjustment
→ tighten the bolts and nuts D-2-2:To adjust the backrest tube → loosen the bolts with Allen key (No #5) → slide in or out for the tube (left and right) separately to your desired width (See Fig 34) → tighten the bolts and nuts. (Fig 33 ) (Fig 34) Allen Key... -
Page 16: Operation
For outdoor operation of this vehicle we recommend that you select a speed that is comfortable for you to control it safely. he following steps are required to operate your vehicle safely with the HP6RT controller (See Fig 37) -
Page 17: Controller Display
3.Joystick The joystick controls the direction, speed and tilt degree of your vehicle, pointing the joystick away from the neutral position,(center), will move the vehicle in the direction where the joystick is pointing. The farther away (forward/backward) the joystick is from the neutral position, the faster the vehicle will go. The farther away to the right/ left the joystick is pointing, the sharper the turn of the vehicle will be. -
Page 18: Free-Wheeling
possible. →Red LEDs indicate that you should charge the batteries as soon possible, because low battery voltage may cause your power wheelchair to become inoperative. Note: When the batteries begin to approach a discharged state, the first red LED will begin to flash slowly, reminding you that the batteries need to be charged immediately. -
Page 19: Batteries And Charger
rollback. A built-in circuit monitors the temperature of the controller and motors, the controller reduces the motor voltage and speed of the power wheelchair. The reduction of the speed allows the electrical components to cool down. Although your power wheelchair will resume its normal speed when the temperature returns to a safe level, we recommend that you turn the power off and wait for 5 minutes before restarting to allow the components to cool down if you find that you have lost speed suddenly. -
Page 20: Charging Instructions
We recommend that you use deep-cycle batteries that are sealed and maintenance free for your power wheelchair. Both sealed lead-acid (SLA) and gel cell are deep-cycle batteries and are similar in performance. Deep-cycle batteries are specifically designed to provide power, drain down, and then accept a relatively quick recharge. -
Page 21: Maintenance And Repair
input (110V or 220V) and adjust manually. (See Fig 41) Plug-in Controller Plug-in Wall Outlet (Fig 41) (Fig 40) Note: →Always charge your batteries in well ventilated areas. →The charger is intended for indoor use only. Protect from moisture. →For maximum performance , it is recommended that you replace both batteries at the same time if the batteries are weak. -
Page 22: Daily Checks
To keep your HP6RT for years of trouble-free operation, we recommend you follow the maintenance checks as scheduled. DAILY CHECKS 1. With the controller turned OFF, perform a joystick check. Make sure it is not bent or damaged and that it returns to center when you release it. - Page 23 1.Unscrew the motor brush caps. (See Fig 42) 2.Remove the brushes. 3.Inspect the brushes for wear (See Fig 43) 4.Replace the brushes if necessary. New Motor Brush Worn Motor Brush Motor Brush caps (Fig 42) (Fig 43) 1. Inspect the state of the battery terminals every six months. Make sure that they are not corroded and the connections are tight.
- Page 24 FLASHING LIGHTS DIAGNOSIS AND SOLUTION The battery needs charging or there is a bad connection to the battery. Check the connections to the battery. If the connect- ions are good, try charging the battery. The left motor has a bad connection. Check the left motor connection.
