- Page 1 USERS MANUAL CEO P25 HEARTWAY MEDICAL PRODUCTS CO., LTD. Version: 2011- September Part Number: 70030215 www.heartway.com.tw...
-
Page 2: Table Of Contents
Main Components………………………………………….………...……………........… 錯 誤 尚 未 定 義 書 籤 。 Safety Instruction…………………………………………………….…………….…………………………………4 Environmental Condition ……………………..….…….………………..……………….…………………..7 Technical Specifications……………………….……………………...…………...…………………….……….8 Assembly Instruction……………………………………………………...………………………………..………9 Adjustments for Seating Comfort…………………………………………………..…………………..…..12 Operation…………………………………………………………………………………………………………..…15 Battery & Charger……………………………………………………..……..……………………………….……22 Maintenance & Repair………………………………………………….………..………………………………25 Care and Maintenance………….…….………..……….……..………………………..………………………30 Circuit Diagram &BOM DRAWING………………………………………......……………32 Warranty Declaration………………………………………………………………………………………………34 www.heartway.com.tw... -
Page 3: Main Components
(See Figure.1). 1. Main frame with motor 5. Left Armrest 2. Headrest 6. Footrest( Left&Right) 3. Seat Cushion /Backrest 7. Controller 4. Right Armrest 8. Drive Wheel (See Figure.1) www.heartway.com.tw... -
Page 4: Safety Instruction
Turn both caster wheels towards the transfer direction to improve power chair stability during transfer. When reaching, bending or leaning while seated on your power chair, make sure that you maintain a stable center of gravity to keep the power chair from tipping. www.heartway.com.tw... - Page 5 3. If unintended movement or brake release occurs, turn the powered wheelchair off as soon as it is safe. 4. Be aware that adding accessories or components, or modifying the powered wheel-chair, may make it more susceptible to interference from radio wave sources.(Note: It is difficult to evaluate the effect on www.heartway.com.tw...
- Page 6 20 V/m, which provides a reasonable degree of protection against more common sources of EMI. The higher the immunity level, the greater the protection. Your powered wheelchair has an immunity level of 20 V/m which should protect against common sources of EMI. www.heartway.com.tw...
-
Page 7: Environmental Condition
At extreme low temperatures, the batteries may freeze, and your power wheelchair may not be able to operate. In extreme high temperatures, it may operate at slower speeds due to a safety feature of the controller that prevents damage to the motors and other electrical components. www.heartway.com.tw... -
Page 8: Technical Specifications
WEIGHT: W/O BATTERY 75Kgs ( 165lbs) TURNING RADIUS 840mm (33") SUSPENSION Full LENGTH 830mm (32.7") WIDE 650 mm (25.6") HEIGHT 1060mm (41.7") SEAT WIDTH 508mm(20") SEAT HEIGHT 520mm(20.5") SEAT DEPTH 415mm(16.3") BACK HEIGHT 560mm(22") WHEEL BASE 500mm(19.7") FOOTRESTS 400mm(15.7")~500mm(19.7") www.heartway.com.tw... -
Page 9: Assembly Instruction
It may be necessary to install the seat either prior to initial operation or after transporting your power chair to the customers. Install The Skirt Guard Insert the skirt guard support tube into the bracket in the correct direction. Tighten the adjusted knob www.heartway.com.tw... - Page 10 Put the backrest into the saddle set. Make sure the tube fit into the bracket properly. After than, , please tighten the set-screw tightly with the Allen Key. Installing the Headrest Loosen the lever, Put the headset into the clamp and then fasten the lever. www.heartway.com.tw...
- Page 11 Installing the Footrest Insert the footrest into footrest frame from side direction then turn around 90 degree to correct direction Make sure the lever trip into the correct position www.heartway.com.tw...
-
Page 12: Adjustments For Seating Comfort
Tighten the knob to secure the armrest Seat Depth Adjustment Use Allen keys to loosen setscrews on both left & right hand-sides Slide the seat-rest in or out for desired depth Tighten the screws with the Allen Key www.heartway.com.tw... - Page 13 Loosen the adjusting screws with Allen key (No # 6 ) Move the backrest to your comfortable angle. You can adjust it to different angles at your desired position. Set the backrest at the desired angle and then tighten the screws www.heartway.com.tw...
- Page 14 Loosen the setscrew on the controller underneath bracket in order to extend the position of controller (Figure 1) Slide the controller into or out of the armrest to the desired position (Figure 2) Tighten the setscrew to secure the controller position Figure 1 Figure 2 www.heartway.com.tw...
-
Page 15: Operation
For outdoor operation of this vehicle we recommend that you select a speed that is comfortable for you to control it safely. The following steps are required to operate your vehicle safely with the P25 controller www.heartway.com.tw... - Page 16 Press “Power” button to turn on P25 power wheelchair Press the mode button and move the joystick right/ left to select Lifting Function Move the joystick up to lift the seat and down to descend the seat www.heartway.com.tw...
- Page 17 How to perform Power-Legrest Tilting Function on P25 Press “Power” button to turn on P25 power wheelchair Press the Mode button. Move the joystick right/ left to select Power-Legrest Tilting Function Move the joystick up to tilt the legrest www.heartway.com.tw...
- Page 18 The available modes are dependent on programming and the range of auxiliary output devices connected to the control system. 6. Profile Button The Profile button allows the user to navigate through the available Profiles for the control www.heartway.com.tw...
- Page 19 This button activates and de-activates the wheelchair’s right indicator. Depress the button to turn the indicator on and depress the button again to turn it off. When activated the right indicator LED will flash in sync with the wheelchair’s indicator. www.heartway.com.tw...
- Page 20 B. Main Circuit Breaker: The main circuit breakers reset button located near the seat of the back side on the main www.heartway.com.tw...
- Page 21 If the circuit breaker trips, wait for approximately one minute and then depress the button to reset it. Then turn on the controller power, and continue normal operation. If the main circuit breaker continues to trip repeatedly, contact your authorized dealer. www.heartway.com.tw...
-
Page 22: Battery & Charger
Green Flash : Power On Orange Flash : Pre Charge Orange : Charging Green&Orange Flash : Charged Green : Full Charge Red Flash：Defect Important! Make sure voltage input is correctly selected for your local regulation (110V or 220V) www.heartway.com.tw... - Page 23 (2)Plug in the power cord. LED indicates green flash when AC power on. (3)Connect the battery charger to the battery. (4)Start charging ; please refer to 4. LED INDICATION 4. LED INDICATION (1)Green Flash：Power on (2)Orange：Charging (3)Orange Flash：Pre charge (4)Green&Orange Flash：Charged 80%。 (5)Green：Full charged(Floating charge)。 (6)Red Flash：Defect www.heartway.com.tw...
- Page 24 (1) Before using the battery charger, read all instructions and cautionary markings. (2) Use the battery charger in a well-ventilated area (3) To avoid the risk of injury, charge only lead-acid or gel cell type rechargeable batteries. (4) Please turn off the power after charging www.heartway.com.tw...
-
Page 25: Maintenance & Repair
Slowly push the joystick forward until you hear the electric brakes clicks. Immediately release the joystick. You must be able to hear each electrical brake operating within a few seconds of joystick movement. Repeat this test three times, pushing the joystick backward, then left, and then right. www.heartway.com.tw... - Page 26 Always perform a general inspection of the tightness of all nuts and bolts. Note: If you experience any technical problems, it is recommended that you check with your local dealer before attempting to troubleshoot on your own. If you get one of these error codes, contact your local dealer. www.heartway.com.tw...
- Page 27 Troubleshooting www.heartway.com.tw...
- Page 28 www.heartway.com.tw...
- Page 29 Frayed harnesses Cracked or broken connectors Uneven wear on any of tires Jerky motion Pulling to one side Bent or broken wheel assemblies Does not power up Powers up, but does not move www.heartway.com.tw...
-
Page 30: Care And Maintenance
When changing a tire, remove only the center lug nut and washer then remove the wheel. If any further disassembly is required, deflate the tire completely or it may explode. www.heartway.com.tw... - Page 31 These testers are available at automotive parts stores. Disconnect both batteries before load testing and follow the directions that come with the load tester. If either one of the batteries fails the load test, replace both of them. If your power chair still does not power up, contact your authorized dealer. www.heartway.com.tw...
-
Page 32: Circuit Diagram &Bom Drawing
CIRCUIT DIAGRAM www.heartway.com.tw... - Page 33 BOM DRAWINGS www.heartway.com.tw...
-
Page 34: Warranty Declaration
WARRANTY DECLARATION Quality/ Warranty Declaration Products are to be fit for purpose and of excellent quality and performance. For valid warranty claims Heartway will, at their discretion, replace/ repair/ refund items mutually agreed to be defective. Heartway’s Warranty as Following: ...
