  • Page 1 USERS MANUAL P16RTL HEARTWAY MEDICAL PRODUCTS CO., LTD. Part no:70030125...
  • Page 2 COMPONENTS Your power wheelchair is shipped partially disassembled for protection during shipping. After unpacking, please check whether you have received the following main components as our standard specification (See Fig.1). 1. Main frame with motor 7. Footrest (Left) 2. Backrest 8.Controller 3.

  • Page 3: Safety Instruction

    9. When driving up curbs, always check the height of the curb to ensure that it does not exceed 1-1/2”(40mm) height. Transfers, Reaching and Bending ansferring on and off the P16RTL requires a good sense of balance. To elimi- nate the possibility of injury. We recommend performing the following tasks before attempting a transfer: →...

  • Page 4: Use While Under The Influence Of Medication Or Alcohol

    11. When reaching, bending or leaning while seated on your power chair, make sure that you maintain a stable center of gravity to keep the power chair from tipping. General Always use a seat belt, and keep feet on the footplate at all time. 12.
  • Page 5 3.If unintended movement or brake release occurs, turn the powered wheelchair off as soon as it is safe. 4.Be aware that adding accessories or components, or modifying the powered wheel- chair, may make it more susceptible to interference from radio wave sources.(Note: It is difficult to evaluate the effect on the overall immunity of the powered wheel- chair).

  • Page 6: Environmental Conditions

    ENVIRONMENTAL CONDITIONS Environmental conditions may affect the safety and performance of your power wheelchair. Water and extreme temperatures are the main elements that can cause damage and affect performance. A) Rain, Sleet and Snow If exposed to water, your power wheelchair is susceptible to damage to electronic or mechanical components.
  • Page 7 ASSEMBLY INSTRUCTION 1. Installing the Saddle set and Seat Connection point (Fig 2) Slide the saddle set (#4) into the Connection points(both sides) in the main frame (#1)(See Fig 2), put down the saddle set and connect the front connection point and make sure that tighten the tension knob in the front connection point.(See Fig 3).
  • Page 8 Allen Key Wrench (Fig 5) (Fig 6) 2. Installing the skirt guard and Armrest 2-1 Install the skirt guards (#10,#11) Place the skirt guard bracket on the seat frame and go through the 2 *M8 bolts into the holes of the seat frame.(See Fig 7), Use the Allen key and wrench to tighten the bolts and nuts(See Fig 8).

  • Page 9: Installing The Backrest

    2-2 Install the Armrest Lift up the armrest bottom tube, take off the E- plastic clip and slide the armrest up tube into the bottom tube (See Fig 11). Then insert the E-plastic clip into the correct location. (See Fig 12) E-plastic clip (Fig 11)
  • Page 10 (Fig 15) (Fig 16) 4. Installing the Headrest Loosen the lever of saddle set, put the headset (#5) into the clamp then fasten the lever. (See Fig17) Saddle Lever (Fig 17 ) 5.Installing the Footrest Insert the footrest (with left-#7 and Right-#6 each) into footrest frame with side direction (See Fig 18) then turn 90 degree to correct direction and make sure the pin jumps into the correct position.

  • Page 11: Installing The Lights

    Assemble the controller (#8) on right armrest bracket with 2 screws.(See Fig 20). There are 1 main plug and 3 extended plugs for P16RTL. Please plug in the main frame (#1) plugs and connect the other 2 (or 3) plugs color by color (See Fig 22),.You have to plug in the main frame for other cables (connect for color by color) and make sure tightly.
  • Page 12 Plug-in color by color (Fig 22) Wrench Allen key (Fig 23) Note: Installing the Batteries (y ou can omit this step if your scooter already assembled the batteries) Take out the cover from the base frame slightly. Put the batteries to the battery loops and connect the cable (2 ends) with the battery positive and negative poles in batteries.

  • Page 13: Adjustments For Seating Confort

    ADJUSTMENTS FOR SEATING CONFORT To maximize seating comfort, your power wheelchair lets you adjust: →Armrest height and angle →Seat depth and width →Headrest angle →Backrest angle and width →Controller position A. Armrest Height and Angle Adjustment A-1:To adjust the Height: wrench (Fig 25) (Fig 26)
  • Page 14 B. Seat Depth and Width Adjustment B-1:To adjust the Depth (Fig 29) → use Allen keys to loosen the 4 bolts in footrest frame (Fig 29) → slide the footrest frame in or out for desired depth → tighten the bolts with Allen key B-2:To adjust the Width Bolts (Fig 30) →...
  • Page 15 C. Headrest Angle Adjustment → loosen the headrest lever (back the headrest) → turn the headrest to your desired angle (See Fig 31) → tighten the headrest lever Headrest Lever (Fig 31) D. Backrest Angle and Width Adjustment D-1:To adjust the Angle →...

  • Page 16: Controller Position Adjustment

    → slide in or out for backrest plastic parts (left and right) separately to your desired width(See Fig 34) → tighten the bolts and nuts D-2-2:To adjust the backrest tube → loosen the bolts with Allen key (No #5) → slide in or out for the tube (left and right) separately to your desired width (See Fig 35) →...

  • Page 17: Operation

    For outdoor operation of this vehicle we recommend that you select a speed that is comfortable for you to control it safely. he following steps are required to operate your vehicle safely with the P16RTL controller (See Fig 38)

  • Page 18: Controller Display

    ally and automatically for your safety. 3.Joystick The joystick controls the direction, speed and tilt degree of your vehicle, pointing the joystick away from the neutral position,(center), will move the vehicle in the direction where the joystick is pointing. The farther away (forward/backward) the joystick is from the neutral position, the faster the vehicle will go.

  • Page 19: Free-Wheeling

    left. →Red, yellow and green LEDs indicate that the batteries are fully charged →Red and yellow LEDs indicate that you should charge the batteries if possible. →Red LEDs indicate that you should charge the batteries as soon possible, because low battery voltage may cause your power wheelchair to become inoperative.

  • Page 20: Thermal Protection

    E. Main Circuit Breaker: Please see Fig 40 to check the circuit breaker location in P16RTL. Breaker (Fig 40) The main circuit breaker monitors the electric current drawn from the battery. It is a safety feature built in your power wheelchair for your extra safety.

  • Page 21: Batteries And Charger

    BATTERIES & CHARGER BATTERY We recommend that you use deep-cycle batteries that are sealed and maintenance free for your power wheelchair. Both sealed lead-acid (SLA) and gel cell are deep-cycle batteries and are similar in performance. Deep-cycle batteries are specifically designed to provide power, drain down, and then accept a relatively quick recharge.
  • Page 22 fully charged. (See Fig 41) Important! Do not use for voltage input unless specified. Make sure your present voltage input (110V or 220V) and adjust manually. (See Fig 42) Plug-in Controller Plug-in Wall Outlet (Fig 42) (Fig 41) Note: →Always charge your batteries in well ventilated areas. →The charger is intended for indoor use only.

  • Page 23: Maintenance And Repair

    MAINTENANCE & REPAIR Your power wheelchair is designed for minimal maintenance. However, like any motorized vehicle it requires routine maintenance. To keep your P16RTL for years of trouble-free operation, we recommend you follow the maintenance checks as scheduled. DAILY CHECKS 1.
  • Page 24 Warning! Failure to maintain the brushes could void the power wheelchair warranty. To inspect or replace the motor brushes: 1.Unscrew the motor brush caps. (See Fig 43) 2.Remove the brushes. 3.Inspect the brushes for wear (See Fig 44) 4.Replace the brushes if necessary. New Motor Brush Worn Motor Brush Motor Brush caps...
  • Page 25 If you get one of these error codes, contract your local dealer. DIAGNOSIS AND SOLUTION FLASHING LIGHTS The battery needs charging or there is a bad connection to the battery. Check the connections to the battery. If the connect- ions are good, try charging the battery. The left motor has a bad connection.
