COMMERCIAL SERIES TREADMILL
O W N E R ' S M A N U A L
06' Treadmill's OM.indd 1
2006/11/22 9:31:08 AM

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MX-T4x and is the answer not in the manual?

Questions and answers

Related Manuals for Matrix MX-T4x

Summary of Contents for Matrix MX-T4x

  • Page 1 COMMERCIAL SERIES TREADMILL O W N E R ’ S M A N U A L 06' Treadmill's OM.indd 1 2006/11/22 9:31:08 AM...
  • Page 2 06' Treadmill's OM.indd 2 2006/11/22 9:31:09 AM...

  • Page 3: Table Of Contents

    Using CSAFE ........................... CHAPTER 6: MX-T3x TREADMILL SPECIFICATIONS, PARTS & ASSEMBLY GUIDES 6.1 Model Specifications ........................ 6.2 Fasteners and Assembly Tools ....................6.3 Assembly Steps ........................CHAPTER 7: MX-T4x / MX-T5x TREADMILL SPECIFICATIONS, PARTS & ASSEMBLY GUIDES 7.1 Model Specifications ........................ 7.2 Fasteners and Assembly Tools ....................7.3 Assembly Steps ........................06' Treadmill's OM.indd 3 2006/11/22 9:31:09 AM...
  • Page 4 06' Treadmill's OM.indd 4 2006/11/22 9:31:09 AM...

  • Page 5: Proper Usage

    This Treadmill is intended for commercial use. To ensure your safety and protect the equipment, read all instructions before operating the MATRIX ucts to instruct all individuals, whether they are the end user or supervising personnel, on proper usage of the equipment. treadmill. When using an electrical product, basic precautions should always be followed It is recommended that all users of Matrix Fitness Systems exercise equip- ment be informed of the following information prior to its use. including the following: DANGER: To reduce the risk of electric shock: Always unplug this equipment 1.2 PROPER USAGE from the electrical outlet immediately after using and before cleaning.

  • Page 6: Electrical Requirements

    One of the most common wear and tear items on a treadmill is the Deck and into an appropriate outlet that is properly installed and grounded in accor- Belt combination. If these two items are not properly maintained they can dance with all local codes and ordinances. If the user does not follow these cause damage to other components. This product has been provided with the grounding Instructions, the user could void the Matrix limited warranty. most advanced maintenance free lubricating system on the market. DANGER: Improper connection of the equipment-grounding conductor can WARNING: Do not run the treadmill while cleaning the belt and deck. This result in a risk of electric shock. Check with a qualified electrician or service- can cause serious injury and can damage the machine.

  • Page 7: Adjusting The Belt

    Manually center the belt by pushing the belt from side to side. Tighten the bolts the same amount as when the user loosened them, approximately one full turn. Inspect the belt for damage. STEP 3 While the treadmill is running at 3 mph / 4.8 kph, observe the belt position. If it is moving to the right, tighten the right bolt by turning it clockwise ¼ turn, and loosen the left bolt ¼ turn. If it is moving to the left, tighten the left bolt by turning it clockwise ¼ turn and loosen the right ¼ turn. Repeat Step 3.2 MX-T4x / MX-T5x TREADMILL 3 until the belt remains centered for several minutes. STEP 4 Check the tension of the belt. The belt should be very snug. When a person walks or runs on the belt, it should not hesitate or slip. If this occurs, tighten the belt by turning both bolts clockwise ¼ turn. Repeat if necessary. 2.5 MAINTENANCE LAMP (MX-T3 There is a maintenance lamp on the console to remind the owner to do the scheduled maintenance. When the treadmill's accumulated distance reaches 5000 miles / 8000 kilometers, the maintenance lamp will light meaning maintenance is needed. The following is the maintenance lamp key:...

  • Page 8: Manual Operation

    CHAPTER 4: mX-t3 verlay escription rograming ngineering 4.1 MX-T3x CONSOLE DESCRIPTION 4.2 MANUAL OPERATION The MATRIX treadmill is inspected before it is packaged. It is shipped in MATRIX design makes using the programs as easy as one touch of a button. four pieces: the base, the upright console supports, the handlebar and qUICK START the console. Carefully unpack the unit and dispose of the box material. Press the “QUICK START” key and the LED will show “3”, “2”, “1”, “GO!”. The treadmill will start running from the lowest incline and 0.5 mph / 0.8 kph, CAUTION This unit weights 350 lbs / 159 kg. To avoid injury to the user with the default time counting down from 20 minutes. and the unit, be sure to have proper assistance to remove and move the unit. MANUAL MODE allows you to enter desired time, level and weight. 1) Choose the “MANUAL” program using the program qUICK-KEYS, then press SELECT.

  • Page 9: Heart Rate Control

    4.4 HEART RATE CONTROL 4.5 FIT TEST Follow these easy Steps to enter into the Heart Rate Program. FIT TEST allows you to measure your fitness based on a program designed specifically for your Matrix Treadmill. The test takes 5 minutes and is TARGET HR: based on your heart rate. User should keep hands on contact heart rate graps. 1) Choose the “TARGET HR” using the program qUICK-KEYS, then press SELECT. 2) Choose the “TARGET HART RATE” using the SPEED -/+, then press SELECT. Follow these easy steps to enter in the Fit Test Program. 3) Choose your HR CONTROL MODE using the SPEED or INCLINE KEYS: - If SPEED -/+ is pressed the console will display “Speed HR Control,...

  • Page 10: Engineering Mode

    CHAPTER 4: mX-t3 verlay escription rograming ngineering MEN’S OUTPUT TABLE FOR TEST #1 AND #2 4.6 ENGINEERING MODE Engineering screens allow the viewing and editing of variables that would EXCELLENT GOOD AVERAGE FAIR POOR be necessary for a club operator/manager to customize. Unless otherwise noted, engineering screens consist of the initial screen, the editing or action screen, and the saving screen. The initial screen displays the vari- 15-19 56 ~ 61 52 ~57 48 ~ 51 42 -...

  • Page 11: Manager Screen Descriptions / Details

    CHAPTER 4: mX-t3 verlay escription rograming ngineering 4.7 MANAGER SCREEN DESCRIPTIONS / DETAILS 4.8 USING CSAFE Matrix is the leader in entertainment availability. Below is a list of the MX-T3x functions for each engineering screen. Exceptions will be noted in the description for each engineering screens: UNIT 1 LOW SPEED LEARN MODE (EDIT) This variable controls the low limit for the speed of the treadmill. CSAFE MIDDLE SPEED LEARN MODE (EDIT) This variable controls the middle limit for the speed of the treadmill. UNIT 2 HIGH SPEED LEARN MODE (EDIT) This variable controls the high limit for the speed of the treadmill.
  • Page 12 EMERGENCY STOP: To stop all function running. 5.2 MANUAL OPERATION MATRIX design makes using the programs as easy as one touch of a button. qUICK START Start pedaling and press qUICK START to begin workout. MANUAL MODE allows you to enter desired time, level and weight. Select MANUAL program button on left of panel. STEP 1 Press SELECT or wait 5 seconds. Selecting START will start program. STEP 2 Select TIME by using the UP or DOWN arrow keys. Press SELECT or wait 5 seconds. Select START will start program. Select LEvEL by using UP or DOWN arrow keys. You can change the level at any STEP 3 time during workout. Press SELECT or Wait 5 seconds. Select START will start program. STEP 4 Select WEIGHT by using the UP or DOWN arrow keys. Press START or SELECT to begin workout. MX-T4x Display, TIME, Starting 3, Starting 2, Starting 1 06' Treadmill's OM.indd 12 2006/11/22 9:31:29 AM...
  • Page 13 CHAPTER 5: MX-T4 / mX-t5 verlay escription rograming ngineering 5.4 HEART RATE CONTROL 5.3 OPERATING LEvEL BASED PROGRAMS Your MATRIX treadmill offers versatile programs to keep the usere motivated. The follow- For your convenience, MATRIX T5x Treadmills come standard with digital ing instructions will guide you through simple steps to select INTERvALS, ROLLING, and contact heat rate sensors and are POLAR telemetry compatible. The MX-T4x is only available with telemetry. RANDOM programs. Locate the metal sensors on the handrail of the MX-T5x. Notice there are two STEP 1 Select the PROGRAM button on left of panel. separate pieces of metal on each grip. You must be making contact on both Press SELECT or wait 5 seconds. pieces of each grip to get an accurate heart rate reading. You can grab these- Selecting START will start program.
  • Page 14 32 ~ 36 23 ~ 31 17 ~ 22 17 - 5.5 FIT TEST FIT TEST allows you to measure your fitness based on a program designed specifically for your Matrix Treadmill. The test takes 5 minutes and is based on your heart rate. User should keep hands on contact heart rate WOMEN’S OUTPUT TABLE FOR TEST #1 AND #2 graps. EXCELLENT GOOD...
  • Page 15 CHAPTER 5: MX-T4 / mX-t5 verlay escription rograming ngineering 5.7 MANAGER SCREENS EXCEPTIONS/DETAILS 5.6 ENGINEERING MODE Below is a list of functions for each Manager Setting. Exceptions will be noted in Manager screens allow the viewing and editing of variables that would be the description for each manager setting: necessary for a club operator/manager to customize. Unless otherwise noted manager screens consist of the initial screen, the editing or action screen and P0 MAXIMUM TIME (EDIT) the saving screen. The initial screen displays the variable type and in most This variable controls the program maximum time.
  • Page 16 1.6 / 1 3.2 / 2 kph / mph Below is a layout of the (backside) console access panel on the Maximum Speed 3.2 / 2 20 / 12 20 / 12 kph / mph MX-T4x / MX-T5x . Default Channel Default Volume Speed Mode Out of Order Machine Type Unit IR On/Off Unit...

  • Page 17: Model Specifications

    CHAPTER 6: MX-T3 reaDmill pecifications arts ssembly uiDes 6.1 MX-T3 MODEL SPECIFICATIONS SPECIFICATIONS Foot Print inches = 85” x 34” x 55” cm = 216 x 87 x 140 Weight 350 lbs / 159 kg Max User Weight 400 lbs = 182 kg Belt Type Habasit Frame Construction...
  • Page 18 CHAPTER 6: MX-T3 reaDmill pecifications arts ssembly uiDes 6.2 MX-T3 MODEL REqUIRED FASTENERS & ASSEMBLEY TOOLS PART # SKETCH DESCRIPTION NOTES 8mm ALLEN WRENCH 10mm ALLEN WRENCH #2 PHILLIPS SCREW DRIVER [ 4.5 x 50 ] FLAT WASHER 10 x 20 x 2.0t SOCKET HEAD CAP SCREW M10 x 25L SOCKET HEAD CAP SCREW M8 x 15L BUTTON HEAD MACHINE SCREW M5 x 12L...
  • Page 19 CHAPTER 6: MX-T3 reaDmill pecifications arts ssembly uiDes 6.3 MX-T3 MODEL ASSEMBLY STEPS ATTENTION • After installation is completed, the treadmill will need to be calibrated by using the AUTO-CHECK function. If this is not done, the treadmill's speed and incline values may be incorrect and damage the treadmill. Do not stand on the belt when performing the AUTO-CHECK function. ASSEMBLY INSTRUCTIONS • Please make sure that the power plug is not plugged into the wall outlet while completing the following procedure. To ensure correct assembly of the treadmill, carefully read and follow these steps: STEP 2 STEP 1 Remove the motor cover. Pull out the console cable and route it through Connect the console cables from the console set to the motor control the Right console mast. Place the right console mast and then the left board cables. Secure the console set with 2 screws (Z52) on each side.
  • Page 20 CHAPTER 6: MX-T3 reaDmill pecifications arts ssembly uiDes 6.4 MX-T3 MODEL ASSEMBLY STEPS STEP 3 STEP 4 FINAL ASSEMBLY OPTIONAL ENTERTAINMENT ACCESSORY SHOWN FINAL ASSEMBLY AUTO CHECK • Press and hold both incline “UP” and speed “DOWN“ buttons simultaneously for 3 seconds .Then the “ENGINEERING MODE” is shown onto the console. • Press the incline “UP” button to find the “AUTO CHECK” screen. • Press the incline “START” button and then, the treadmill will run the auto check function automatically. This will take around 3 minutes to run. • After auto check is complete “AUTO CHECK OK” will show on the console. Then, press EMERGENCY STOP key twice to back to initial starting screen. 06' Treadmill's OM.indd 20 2006/11/22 9:31:46 AM...

  • Page 21: Model Specifications

    CHAPTER 7: MX-T4 / MX-T5 reaDmill pecifications arts ssembly uiDes 7.1 MX-T4 MX-T5 MODEL SPECIFICATIONS SPECIFICATIONS Product Name T4x / T5x HEART RATE T4x / T5x Foot Print inches = 85” x 35” x 62” cm = 215.9 x 88.7 x 157.5 Telemetry Contact Heart Rate T4x-No / T5x-Yes...
  • Page 22 CHapter 7: MX-t4 / MX-t5 readmill pecificationS artS SSembly uideS 7.2 MX-t4 MX-t5 Model required fasteners & asseMbley tools PART # SKETCH DESCRIPTION NOTES 4mm ALLEN WRENCH 5mm ALLEN WRENCH ALLEN WRENCH [ #8 x 168 ] ALLEN WRENCH [ #5 x 172 ] #2 PHILLIPS SCREW DRIVER [ 4.5 x 50 ] FLAT HEAD MACHINE SCREW (M8 x 20L) FLAT HEAD MACHINE SCREW (M8 x 25L)
  • Page 23 CHAPTER 7: MX-T4 / MX-T5 reaDmill pecifications arts ssembly uiDes 7.3 MX-T4 MX-T5 MODEL ASSEMBLY STEPS STEP 1 STEP 2 Z50 C11 06' Treadmill's OM.indd 23 2006/11/22 9:31:51 AM...
  • Page 24 CHAPTER 7: MX-T4 / MX-T5 reaDmill pecifications arts ssembly uiDes 7.3 MX-T4 MX-T5 MODEL ASSEMBLY STEPS FINAL ASSEMBLY STEP 3 OPTIONAL ENTERTAINMENT ACCESSORY SHOWN 06' Treadmill's OM.indd 24 2006/11/22 9:31:55 AM...
  • Page 25 06' Treadmill's OM.indd 25 2006/11/22 9:31:55 AM...
  • Page 26 06' Treadmill's OM.indd 26 2006/11/22 9:31:55 AM...
  • Page 27 MATr ix Fi T n es s sysT e Ms c or p. IN TER N ATIO N AL V ER SI ON reV. 02 06' Treadmill's OM.indd 27 2006/11/22 9:47:25 AM...
