Appendix B

Appendix B Specifications

Data Parameters
Modulation Format
Certification/Compliance
Receiver Sensibility
User Data Throughput
Format 10/100 BaseT
Network Protocols
Configuration and Management
Upstream/Downstream Throughput
Physical Interfaces
Ethernet Speed (via RJ45 shielded)
Ethernet Packet
POWER PARAMETERS
Power Method
Voltage input limits into PoE J-Box
Voltage input limits into Radio
Standard Power Supply (included)
PoE Cat-5 Max Cable length
Current Draw/Power
Environmental
Radio Enclosure
Temperature Range
NEMA Rating
Radio Dimensions
Radio Weight
User Interfaces
Trango Broadband Wireless — ATLAS5010
Orthogonal Frequency Division Multiplexing
FCC Part 15.247, 15.407: ETSI/EN301 489-1 (7.2) (pending)
–73 dBm (54 Mbits) to –92 dBm (6 Mbits)
45 Mbps
10/100 BaseT
All IEEE 802.3 / 802.3u compliant protocols
Telnet, SNMP, TFTP, HTTP
Dynamic, automatically adjusts to suit demand
10/100 BaseT, Auto-sensing
Up to 3600 byte long packets (supports VLAN/VPN pass through)
Power-over-Ethernet (PoE). DC Voltage injected at PoE J-Box
12 VDC - 24 VDC, 24 VDC Nominal
10.5 VDC - 24 VDC
120 VAC to 24 VDC
100 meters on 24 AWG STP Cat-5 Cable
750 mA max. (12 W), using 24V standard adapter
All-weather, powder coated, aluminum case/back with UV stabilized ABS radome
-40° to 60° C (-40° to 140° F)
NEMA 4
14.5 in. x 14.5 in. x 3.75 in.
7 Lbs. (INT)
RJ45 (shielded)
Specifications
page 23
