ST900 Direct Vent Gas Fireplace
Conversion Kit Manual
Propane for North America
Important:
The appliance shall be converted in accordance with;
• Local codes or, in the absence of local codes, with the National Fuel
Gas Code, ANSI Z223.1/NFPA 54, or the Natural Gas and Propane
Installation Code, CSA B149.1
• A manufactured home (USA only) or mobile home OEM installation
must conform with the Manufactured Home Construction and Safety
Standard, Title 24 CFR, Part 3280, or, when such a standard is not
applicable, the Standard for Manufactured Home Installations
ANSI/NCSBCS A225.1, or Standard for Gas Equipped Recreational
Vehicles and Mobile Housing, CSA Z240.4
• Any other relevant statutory regulations.
• Must be installed by a qualified installer, service agency or gas supplier
• Converting this appliance for use with other gasses must be done by a
qualified installer, service agency, or gas supplier
Ce manual est disponsible en Français sur demande. www.escea.net
Manufactured By: Escea International Limited, 375b Green Valley Road, Griffen, GA 30224, USA. Ph: 866 615 3096 | info@escea.ne
630101_2_Manual_Propane_Conversion_US.doc
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Escea ST900
Summary of Contents for Escea ST900
- Page 1 • Converting this appliance for use with other gasses must be done by a qualified installer, service agency, or gas supplier Ce manual est disponsible en Français sur demande. www.escea.net Manufactured By: Escea International Limited, 375b Green Valley Road, Griffen, GA 30224, USA. Ph: 866 615 3096 | info@escea.ne 630101_2_Manual_Propane_Conversion_US.doc...
- Page 2 1. Main Burner Jet (1.2mm orifice) 2. Pilot Burner Jet (N . 46 Jet) 3. Dataplate Label with Propane information 4. This instruction manual detailing the steps required to complete the gas conversion for this Escea ST900 Direct Vent Gas Fireplace. 630101_2_Manual_Propane_Conversion_US.doc...
- Page 3 Removing the Fascia The ST900 fascia attaches to the fireplace by four hooks. To remove the fascia, simply lift it upwards 5/8”-3/4”, and pull towards you. Care should always be taken when handling the fascia.
- Page 4 Removing the Fuel Bed Media Remove all pieces of the fuel bed media from the firebox and place them in a container carefully to avoid damage. Converting the Appliance First you need to remove the burner by removing the screw holding it in place on the left hand side of the firebox (Fig.
- Page 5 Now, put the gas data (Propane sticker shown) ST900 Edition sticker supplied in the conversion kit in onto the dataplate of the ST900 in the position shown. Note: This will need to be completed on the English language as well as the French language dataplates. (English...
- Page 6 Replacing the Fuel Bed Media The fuel bed media must now be placed back in the firebox in the correct manner to ensure that the appliance will operate in a safe and proper way. Replacing the Driftwood and Pebbles Set Scatter one layer of the supplied white coals evenly across the base of the firebox, ensuring there are no coals or media inside the pilot flame surround guard.
- Page 7 Re-fitting the Glass Assembly The glass assembly must be re-fitted to the appliance before the gas conversion process can proceed. Follow the instructions in ‘4.0 Removing the Glass Assembly’ in reverse to refit the glass assembly to the fireplace. Do not operate the appliance if the glass has been broken, damaged, or the glass is not properly positioned/hooked onto the appliance.
- Page 8 Notes: 630101_2_Manual_Propane_Conversion_US.doc...
