- Page 1 Condenser Dryer Manual for Installation, Use and Maintenance Customer Care Department • The Group Ltd. • Harby Road • Langar • Nottinghamshire • NG13 9HY T : 01949 862 012 F : 01949 862 003 E : service@cda.eu W : www.cda.eu...
- Page 2 Appliance information: Please enter the details on the appliance rating plate below for reference, to assist CDA Customer Care in the event of a fault with your appliance and to register your appliance for guarantee purposes. Appliance Model...
- Page 3 CE Declarations of Conformity: This appliance has been designed, constructed and marketed in compliance with safety requirements of EEC Directive 2006/95/EEC (Low voltage) and requirements of EMC Directive 2004/108/EEC. This product is manufactured to comply with the radio interference requirements of the Council directive 82/336/EEC, 2004/108/EC. IMPORTANT INFORMATION FOR CORRECT DISPOSAL OF THE PRODUCT IN ACCORDANCE WITH EC DIRECTIVE 2002/96/EC.
-
Page 4: User Information
User Information The room must be adequately ventilated to avoid the backflow of gases into the room from appliances burning gas or any other fuels. This includes open fires. It is important to clean the lint filter after each drying cycle. Items that have been soiled with substances such as cooking oil, acetone, alcohol, petrol, kerosene, spot removers, turpentine, waxes and wax removers should be washed in hot water with an extra... - Page 5 Do not Dry wool or wool mixture articles unless the article is labeled as suitable. This should avoid shrinkage. Do not Items such as foam rubber (latex foam), shower caps, waterproof textiles, rubber backed articles and clothes or pillows fitted with foam rubber pads should not be dried in the tumble dryer.
-
Page 6: Before First Use
Open the dryer door and push the filter into its operating position. Remove any dust by wiping the drum and door with a damp cloth. Any initial smell of burning will be caused by dust on the heater and will quickly disappear. Use And Controls CI560 CI560 heat heat start... - Page 7 C Display The display shows the progamme number or drying time when programme 9 is selected D Plus button The plus button increases the programme number or programme time E Start button The start button starts the programme F Activate button The activate button should be pressed to power on the dryer.
-
Page 8: Programme Chart
Programme Chart Programmes 1-7 and 9 can be operated on either full heat or half heat setting and include a 12 minute cool-down period at the end of the cycle. Programme 8 operates without the heater (regardless of the heat switch setting), circulating air through the dryer at the ambient temperature. - Page 9 Delay start The dryer is equipped with a variable delay start timer of up to 9 hours’ duration at hourly intervals. To set the delay timer, first select the programme, heat setting and required duration (if applicable) and then press the delay timer button. This will switch the timer on for one hour, which will show on the delay start display.
- Page 10 To run a programme • S ort the clothes into groups of similar fabrics and colours. Check the care label inside the garment. We suggest that a fabric conditioner be used to reduce static electricity. Delicate articles e.g. tights should be placed inside a pillowcase. It is better to dry small and large articles together.
- Page 11 • S elect anti-crease function if required. If you have selected the anti- crease function, the drum will continue to turn periodically for up to 8 hours or until the dryer is stopped by opening the dryer door or by disconnecting the dryer from the mains.
-
Page 12: Cleaning The Condenser
Emptying the water bottle When the dryer is configured to drain to the internal water bottle, it must be emptied periodically. The warning light on the control panel will illuminate when the bottle is full. • T o empty the water bottle •... - Page 13 • F irmly pull the condenser using the handle to remove it from the dryer. • R inse between the plates under a tap or with running water to remove any lint or fluff. fig. 2 • C arefully shake any excess water from the condenser.
-
Page 14: Care And Maintenance
Care And Maintenance Cleaning The Filter The filter is found by opening the door (fig.3.) and must always be in position when drying items in the appliance. To allow the dryer to operate efficiently fig. 3 the filter should be cleaned after each drying cycle. -
Page 15: Troubleshooting
- Check that the bottle full warning light is off. If it is on then the bottle may be full or incorrectly fitted. If your appliance does not work, check the following points before contacting CDA Customer Care • C heck that there is power to the appliance. -
Page 16: Installation
Installation 600mm 50mm This appliance is fully compatible with any 600mm deep kitchen units and complies with stringent EEC regulations. 600mm The illustration shows the minimum space required by the dryer and the position of the waste-pipe within this space and behind the dryer. If a trap is 615mm fig. - Page 17 80mm 600mm fig. 5 PLEASE NOTE: The air vent at the front of the appliance must never be covered or blocked in any way as this will impair the functioning of the appliance and could cause it to overheat.
-
Page 18: Drainage Options
Drainage options This condenser dryer is fitted with an internal drain pump, which gives you the option of being able to drain condensed water to the water bottle, or to the household waste pipe. Connecting your dryer to the household fig. -
Page 19: How To Reverse The Door
How to reverse the door Open the door. Turn the red switch strike 90⁰ anticlockwise and then remove it. Remove the four screws on the opposite side from the door hinge. Holding the door in position to prevent damage, remove the four hinge screws Turn the door 180⁰... -
Page 20: Electrical Information
Electrical information Warning! This appliance must be earthed. The mains lead of this appliance has been fitted with a BS 1363A 13 amp fused plug. To change a fuse in this type of plug, follow the steps below: 1. Remove the fuse cover and fuse. 2. -
Page 21: Technical Information
Do not shorten the supply cable, the appliance may require removing for servicing. N.B. Ensure that the plug socket is situated in an easily accessible place. If the power supply cord is damaged, it must replaced by a CDA authorised agent. Technical information: Overall dimensions : 86.5 - 89 cm x 59.5 cm x 53 cm (height x width x depth) - Page 24 Please contact our Customer Care Department, or for Service on the details below. Customer Care Department • The Group Ltd. • Harby Road • Langar • Nottinghamshire • NG13 9HY T : 01949 862 012 F : 01949 862 003 E : service@cda.eu W : www.cda.eu...
