- Page 1 CI921 Integrated Tumble Dryer Manual for Installation, Use and Maintenance Customer Care Department • The Group Ltd. • Harby Road • Langar • Nottinghamshire • NG13 9HY T : 01949 862 012 F : 01949 862 003 E : service@cda.eu W : www.cda.eu...
- Page 2 Appliance information: Please enter the details on the appliance rating plate below for reference, to assist CDA Customer Care in the event of a fault with your appliance and to register your appliance for guarantee purposes. Appliance Model...
- Page 3 CE Declarations of Conformity: This appliance has been designed, constructed and marketed in compliance with safety requirements of EEC Directive 2006/95/EEC (Low voltage) and requirements of EMC Directive 2004/108/EEC. This product is manufactured to comply with the radio interference requirements of the Council directive 82/336/EEC, 2004/108/EC. IMPORTANT INFORMATION FOR CORRECT DISPOSAL OF THE PRODUCT IN ACCORDANCE WITH EC DIRECTIVE 2002/96/EC.
-
Page 4: User Information
User Information The room must be adequately ventilated to avoid the backflow of gases into the room from appliances burning gas or any other fuels. This includes open fires. It is important to clean the lint filter after each drying cycle. Items that have been soiled with substances such as cooking oil, acetone, alcohol, petrol, kerosene, spot removers, turpentine, waxes and wax removers should be washed in hot water with an extra... - Page 5 Do not Dry wool or wool mixture articles unless the article is labeled as suitable. This should avoid shrinkage. Do not Items such as foam rubber (latex foam), shower caps, waterproof textiles, rubber backed articles and clothes or pillows fitted with foam rubber pads should not be dried in the tumble dryer.
- Page 6 Use And Controls fig. 1 1. Programme selector: Choose the final dryness of the load by selecting the desired dryness setting (see the programme chart). The dryer will stop automatically when the chosen dryness is achieved. 2. Heat settings: High – For fabrics insensitive to higher temperatures, such as cotton.
-
Page 7: Programme Chart
Programme Chart Programmes 1-7 can be operated on either full heat or half heat setting and include a 12 minute cool-down period at the end of the cycle, followed by the automatic anti-crease cycle. Programme 8 operates without the heater (regardless of the heat switch setting), circulating air through the dryer at the ambient temperature. - Page 8 To run a programme • Sort out the clothes into groups of similar fabrics and colours. Check the care label inside the garment. We suggest that a fabric conditioner be used to reduce static electricity. Delicate articles e.g. tights should be placed inside a pillowcase. It is better to dry small and large articles together.
- Page 9 • The drum will begin to turn, and will stop when the clothes are dry. The drum will rotate clockwise and anticlockwise during the programme alternately to reduce creasing. • There is an automatic 12 minute cool down period at the end of the cycle, during which the heater is switched off, to minimise creasing and prevent damage to the clothing.
- Page 10 Use And Controls Should the clothes dry before the cycle has finished the thermostat will automatically switch off the heater to prevent over drying and save energy although the drum will still rotate. When drying large items such as sheets, we suggest you stop the dryer to redistribute the load.
-
Page 11: Care And Maintenance
Care And Maintenance Cleaning The Filter The filter is found, by opening the door (fig.2.) and must always be in position when drying items in the appliance. To allow the dryer to operate efficiently fig. 2 the filter should be cleaned after each drying cycle. -
Page 12: Troubleshooting
- Check that you have not set the timer within a cool down period. If your appliance does not work, check the following points before contacting CDA Customer Care • Check that there is power to the appliance. - Page 13 Installation/venting This appliance is fully compatible with any 600mm deep kitchen units and 695 mm complies with stringent EEC regulations. 125 mm Your dryer is supplied with a vent hose fig. 3 which will extend to approximately 2.4 m. We strongly recommend that this is vented through the wall with the attachment provided.
-
Page 14: Fitting The Décor Door
80mm 600mm fig. 4 PLEASE NOTE: The air vent at the front of the appliance must never be covered or blocked in any way as this will impair the functioning of the appliance and could cause it to overheat. Fitting the décor door The hinges can be fastened through predrilled holes on either the left or right hand side with the door stops... -
Page 15: Reversing The Door
Reversing The Door The door on the dryer can be positioned either with the left or right hand hinging, as shown in fig.6. Please note: power tools must not be used when reversing the door. How to reverse the door Open the door Undo screw A, remove switch strike B and replace screw A. -
Page 16: Electrical Information
Electrical information Warning! This appliance must be earthed. The mains lead of this appliance has been fitted with a BS 1363A 13 amp fused plug. To change a fuse in this type of plug, follow the steps below: 1. Remove the fuse cover and fuse. 2. -
Page 17: Technical Information
Do not shorten the supply cable, the appliance may require removing for servicing. N.B. Ensure that the plug socket is situated in an easily accessible place. If the power supply cord is damaged, it must replaced by a CDA authorised agent. Technical information: Overall dimensions : 86.5 - 89 cm x 59.5 cm x 53 cm (height x width x depth) - Page 20 Please contact our Customer Care Department, or for Service on the details below. Customer Care Department • The Group Ltd. • Harby Road • Langar • Nottinghamshire • NG13 9HY T : 01949 862 012 F : 01949 862 003 E : service@cda.eu W : www.cda.eu...
