- Page 1 Manual for Installation, Use and Maintenance Passionate about style Customer Care Department • The Group Ltd. • Harby Road • Langar • Nottinghamshire • NG13 9HY T : 01949 862 012 F : 01949 862 003 E : service@cda.eu W : www.cda.eu...
- Page 2 Contents Page 1 Important information Page 2 User information Page 3 How to use Page 4 Filter Maintenance Page 5 Installation Page 6 Technical Data Page 7 Technical information...
- Page 3 Appliance information: Please enter the details on the appliance rating plate below for reference, to assist CDA Customer Care in the event of a fault with your appliance and to register your appliance for guarantee purposes. Appliance Model...
- Page 4 User Information The room must be adequately ventilated to avoid the backflow of gases into the room from appliances burning gas or any other fuels. This includes open fires. It is important to clean the lint filter after each drying cycle. Items that have been soiled with substances such as cooking oil, acetone, alcohol, petrol, kerosene, spot removers, turpentine, waxes and wax removers should be washed in hot water with an extra amount of detergent before being dried in the tumble dryer.
- Page 5 Use And Controls TIME SETTING A. The timer - Turn the timer knob clockwise until the required programme around the timer knob is selected. B. Heat setting - Select gentle or intensive heat the control panel C. Start - Press the start button after selecting the required drying time. •...
- Page 6 Use And Controls Should the clothes become dry before the cycle has finished the thermostat will automatically switch off the heater and prevent over drying and save energy although the drum will still rotate. When drying large items such as sheets, we suggest you stop the dryer to redistribute the load. To stop the machine during the middle of a programme, open the door: the drum will stop rotating automatically and reset when you close the door.
-
Page 7: Care And Maintenance
- Check that the vent hose is not blocked (sometimes a strong wind may cause a back pressure). - Check that you have not set the timer within a cool down period. If your appliance does not work, check the following points before contacting CDA Customer Care •... - Page 8 Installation/Venting This appliance is fully compatible with any 600mm deep kitchen units and complies with stringent EEC regulations. Your dryer is supplied with a vent hose which will extend to approximately 2.4 m. We strongly recommend that this is vented through the wall with the attachment provided.
-
Page 9: Reversing The Door
Reversing The Door The door on the dryer can be positioned either with the left or right hand hinging, as shown in fig.6. Please note: power tools must not be used when reversing the door. How to reverse the door Open the door Undo screw A, remove switch strike B and replace screw A. -
Page 10: Electrical Information
Electrical information Warning! This appliance must be earthed. The mains lead of this appliance has been fitted with a BS 1363A 13 amp fused plug. To change a fuse in this type of plug, follow the steps below: 1. Remove the fuse cover and fuse. 2. -
Page 11: Technical Information
Technical information: Overall dimensions : 85cm x 59.5cm x 58cm (height x width x depth) Maximum dry weights: Cotton or linen 6.0kg. Maximum dry weights: Synthetics 2.0kg. Fuse rating: 13 A For electrical ratings see plate on rear of machine. - Page 12 Passionate about style Customer Care Department • The Group Ltd. • Harby Road • Langar • Nottinghamshire • NG13 9HY T : 01949 862 012 F : 01949 862 003 E : service@cda.eu W : www.cda.eu...
