NOTICE: SAVE THESE INSTRUCTIONS
model(s):
TLC 2000 Coal/Wood Stove
PlEASE rEAd ThIS ENTIrE mANuAl bEFOrE YOu INSTAll ANd uSE YOur NEw rOOm hEATEr. FAIlurE TO
FOllOw INSTruCTIONS mAY rESulT IN PrOPErTY dAmAgE, bOdIlY INjurY, Or EvEN dEATh.
FOr uSE IN ThE u.S. ANd CANAdA. dO NOT INSTAll IN A mObIlE hOmE.
IF ThIS STOvE IS NOT PrOPErlY INSTAllEd, A hOuSE FIrE mAY rESulT. FOr YOur SAFETY, FOllOw
INSTAllATION dIrECTIONS.
CONTACT lOCAl buIldINg Or FIrE OFFICIAlS AbOuT rESTrICTIONS ANd INSTAllATION INSPECTION
rEQuIrEmENTS IN YOur ArEA.
CONTACT YOur lOCAl AuThOrITY (SuCh AS muNICIPAl buIldINg dEPArTmENT, FIrE dEPArTmENT, FIrE
PrEvENTION burEAu, ETC.) TO dETErmINE ThE NEEd FOr A PErmIT.
CETTE guIdE d'uTIlISATION EST dISPONIblE EN FrANCAIS. ChEz vOTrE CONCESSIONNAIrE dE hArmAN.
Installation & Operating manual

SAFETY NOTICE

SAvE ThESE INSTruCTIONS.
!
hOT SurFACES!
Glass and other surfaces are hot during
operation and cool down.
hot glass will cause burns.
• Do not touch glass until it is cooled
• NEVER allow children to touch glass
• Keep children away
• CAREFULLY SUPERVISE children in same room as
stove.
• Alert children and adults to hazards of high temperatures.
high temperatures may ignite clothing or other
flammable materials.
• Keep clothing, furniture, draperies and other flammable
materials away.
NOTE
To obtain a French translation of this manual, please
contact your dealer or visit www.harmanstoves.com
Pour obtenir une traduction française de ce manuel, s'il
vous plaît contacter votre revendeur ou visitez www.
harmanstoves.com
WARNING
3-90-08691R18_12/13

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Harman TLC 2000 and is the answer not in the manual?

Questions and answers

Related Manuals for Harman Harman TLC 2000

Summary of Contents for Harman Harman TLC 2000

  • Page 1: Safety Notice

    Installation & Operating manual NOTICE: SAVE THESE INSTRUCTIONS WARNING hOT SurFACES! Glass and other surfaces are hot during operation and cool down. hot glass will cause burns. model(s): • Do not touch glass until it is cooled TLC 2000 Coal/Wood Stove • NEVER allow children to touch glass • Keep children away • CAREFULLY SUPERVISE children in same room as stove. • Alert children and adults to hazards of high temperatures. high temperatures may ignite clothing or other flammable materials.
  • Page 3 3-90-08691R18_12/13...

  • Page 4: Table Of Contents

    Introduction Table of Contents Specifications ......6 Operation ......8 building a Fire .
  • Page 5 Carbon monoxide (CO) Awareness Carbon monoxide, referred to as CO, is a colorless, odorless CO detectors are very sensitive and may sound an alarm gas that is produced during combustion of coal and other for fumes other than CO or CO from sources other than the fuels. CO fumes are toxic and can be fatal. stove such as car or lawn mower exhaust. The TLC 2000 is a natural draft system which relies on If the alarm sounds a properly designed chimney to remove CO and other 1. Increase ventilation by opening windows or doors.

  • Page 6: Specifications

    Specifications Weight ........ 462 lbs Flue Size .
  • Page 7 unit Overview Clean-out Cover Top Load Door Top Load Opening Glass Door Top Load Door Arm Wood Air Grates (2) Control Side Shield Coal Bars (3) Coal Air Control Removable Shaker Handle Front Load Door Handle Ash Door Ash Door Latch 3-90-08691R18_12/13...

  • Page 8: Operation

    POSE A rISk TO PErSONAl hEAlTh ANd SAFETY. cast iron grates linked together to operate simultaneously when the external shaker handle is moved. The purpose of the grate system is to support the coal bed while air flows up through the grates to the burning coal. The grates are also used to remove ashes from the bottom of the coal bed while the fire is burning. This is accomplished by shaking the shaker lever back and forth with short choppy strokes. This causes the ashes to fall through the grates into the ash pan. It is the special design of the Harman Grates that allows longer intervals between refueling and shaking the grates. rEmOvAl Or mOdIFICATION OF ThIS grATE SYSTEm mAY CAuSE A dANgErOuS SITuATION. harman TlC 2000 grate System 3-90-08691R18_12/13...

  • Page 9: Building A Fire

    building & maintaining a Fire CAUTION wOOd wOOd ThE OPErATION rANgE OF ThE AIr CONTrOlS mAY NOT bE AlTErEd FOr ANY rEASON. CAUTION AlwAYS wEAr FIrE-rESISTANT glOvES TO OPErATE ThE STOvE. ThE AIr CONTrOl IS hOT whIlE IN OPErATION. COAl building and maintaining a wood Fire Never use gasoline, gasoline-type lantern fuel, kerosene, charcoal lighter fluid, or similar liquids to start or...
  • Page 10 building & maintaining a Fire reloading Once you have prepared and maintained a thick charcoal Remove Cleanout bed, you should be able to reload the stove, allow some Plate To Burn As A Fireplace Stove burning at the maximum air setting, and reset the air control in a few minutes. Select hardwoods if possible, as they are heavier and contain more heating capacity (BTU’s) per load than do softwoods. Wood should be split and stored under cover for “seasoning” a year is recommended. Your stove is not an incinerator, do not burn garbage, painted or treated wood, plastic, or other debris. Keep the area around the stove free from clutter. Keep all combustibles, including fuel, beyond the code-required clearance distance (48" or 1215 mm in the U.S., 1525 mm or 60" in Canada). Never store fuel in front of the stove where...
  • Page 11 building & maintaining a Fire building and maintaining a Coal Fire; Build a wood fire as described but instead of adding larger wood, limit the size to about 2" in diameter. Add enough 2" wood that the firebox floor is covered with burning wood. After the wood is burning well for about five minutes, put the wood air controls in the down position and slide the coal air control to the right. This makes the primary air flow up through the grates as is required for coal burning. Next add a layer of coal on top of the wood. Continue burning until the layer of coal is turning red and igniting. It is possible to speed this process by opening the ash door, but never for more than five minutes at a time. Operation with the ash door open for more than five minutes will overfire the stove and may cause damage to the stove. Never leave the stove unattended with the ash door open. After the layer of coal is burning, a second layer may be added. After the second layer is burning, more layers may be added. Do not add coal above the firebricks or grate bars. The stove is hot while in operation.
  • Page 12 building & maintaining a Fire disposal of Ashes. The TLC 2000 was designed to provide access to the ash pan without the need for opening the main door. Wearing heavy protective gloves, open the ash door and remove the ash pan by pulling it forward by the handle. Close the ash door before taking the ashes outside for safe disposal. A good time to empty the ash pan is before loading. This ensures that the ashes will be cold and safer to handle than directly after shaking the ashes down or tending the fire. Ashes should be placed in a steel container with a tight fitting lid and moved outdoors immediately. The closed container of ashes should be placed on a noncombustible floor or on the ground, well away from all combustible materials, pending final disposal.

  • Page 13: Maintenance

    maintenance Like all fine equipment, your TLC 2000 requires some glass - replacement routine maintenance and inspection. Follow the guidelines The glass in this unit is a ceramic glass. 5mm X 444mm X in this section to guarantee safe, efficient operation. 311 mm. available from your Harman dealer. The Stove If the stove’s glass is cracked or broken, you must replace it before operating your stove. Remove pieces carefully. Surface Replace glass only with Harman supplied replacement glass The stove’s exterior surface should be dusted periodically panels; do not use substitutes. with a soft cloth. For more thorough cleaning, wait until To replace the glass panel, you will need to remove the door.

  • Page 14: Maintenance

    maintenance glass - Cleaning Sometimes it will be necessary to clean accumulated ash from the glass surface; allowing this ash to remain on the Top Load glass for long periods can result in “etching” due to the acidity Door Gasket of the ash. The creosote which accumulates on the glass should burn off during your hot fires. Never clean the glass while it is hot, and do not use abrasive substances. Wash the surface with cool water, and rinse Door Gasket thoroughly. You may wish to use a non-abrasive cleaner specifically designed for use on stove glass. In any case, dry thoroughly before relighting your stove.

  • Page 15: Installation

    Installation dO NOT INSTAll IN A SlEEPINg rOOm Assembly blower (Optional) Bolt the blower to the bottom rear of the stove with four 1/4-20 bolts. Tighten the bolts, but do not overtighten. The blower speed can be adjusted using the knob that is built-in to the power cord. When first starting a fire, keep the blower off. After a good bed of coals is established, you can run the blower at any speed desired. Blower Variable The power cord for the blower must be connected to a Speed knob grounded outlet, and must be routed away from the appliance.
  • Page 16 Installation Floor Protection Parallel versus Corner Installations In all installations, the area under and around the stove A parallel installation is one in which the back and sides of must be protected from falling ash and live coals. The floor the stove are parallel to the walls behind and to the side of protector must be of noncombustible material, and positioned the stove. A corner installation is one in which the back of the as shown in the accompanying illustration. stove is positioned diagonally across a corner of the room. Each installation requires its own set of clearances. The guidelines for floor protection are: 1. Completely under the stove and any horizontal runs of For parallel installations the required clearance distances connector. The floor protection must extend a minimum of from the stove are: 18" (457mm) to the side wall and 16"...

  • Page 17: Chimney System

    Chimney System The Chimney System When installed and operated according to this manual, the TLC 2000 will produce enough hot gases to keep the chimney Soot and Creosote - Formation and Need for removal warm so that adequate draft is maintained throughout the When wood is burned slowly, it produces tar and other organic burn cycle. vapors, which combine with expelled moisture to form soot or creosote. The soot and creosote vapors condense in Chimney Connectors the relatively cool chimney flue of a slow burning fire. As In general, following these guidelines will ensure compliance a result, soot or creosote residue accumulates on the flue with all national and provincial codes; prior to beginning your...
  • Page 18 Chimney System Non-combustible cover, one side only. If two covers are Closest Combustible Material Hole with minimum used, each must be mounted clearance of 18” Minimum 2” (50mm) on non-combustible spacers Clearance to Brick (450mm) Between at least 7/8” (21mm) away connector and wall.

  • Page 19: Chimney System

    Chimney System dO NOT CONNECT ThIS uNIT TO A ChImNEY FluE Chimney liner SErvINg ANOThEr APPlIANCE. inner edges Existing masonry Chimneys If you plan on using a pre-existing masonry chimney, have Mechanical fasteners it thoroughly inspected and cleaned. Any faults which make (minimum 3) but not at the bottom of the connector the chimney unsafe and unusable must be repaired prior to use. These can include improper height, structural defects, blockages, inadequate clearance to combustibles, unsealed openings into other rooms of the house, signs of creosote or smoke leakage, a loose or absent clean-out door, or absence of a liner.

  • Page 20: Service Parts List

    TlC-2000 Service Parts Top load Coal/wood Stove beginning manufacturing date: N/A 1-90-08690-1 (black w/door) Ending manufacturing date: Active retired units 1-70-08690-4 (metallic blue) Ending manufacturing date jan 2010 1-70-08690-1 (black) Ending manufacturing date: june 2011 1-70-08690-5 (honey glo) Ending manufacturing date june 2009 1-70-08690-2 (Charcoal) Ending manufacturing date: june 2011 1-70-08690-10 (mojave red) Ending manufacturing date jan 2010 1-70-08690-3 (goldenfi re) Ending manufacturing date: june 2011...
  • Page 21 Service Parts beginning manufacturing date: N/A Ending manufacturing date: Active IMPORTANT: THIS IS DATED INFORMATION . Parts must be ordered from a dealer or Stocked hearth and home Technologies does not sell directly to consumers distributor. . Provide model number and serial number when requesting service parts from your dealer or distributor. at depot ITEm...
  • Page 22 Service Parts beginning manufacturing date: N/A Ending manufacturing date: Active IMPORTANT: THIS IS DATED INFORMATION . Parts must be ordered from a dealer or Stocked hearth and home Technologies does not sell directly to consumers distributor. . Provide model number and serial number when requesting service parts from your dealer or distributor. at depot ITEm...

  • Page 23: Warranty

    hearth & home Technologies lImITEd lIFETImE wArrANTY Hearth & Home Technologies, on behalf of its hearth brands (”HHT”), extends the following warranty for HHT gas, wood, pellet, coal and electric hearth appliances that are purchased from an HHT authorized dealer. wArrANTY COvErAgE: HHT warrants to the original owner of the HHT appliance at the site of installation, and to any transferee taking ownership of the appliance at the site of installation within two years following the date of original purchase, that the HHT appliance will be free from defects in materials and workmanship at the time of manufacture. After installation, if covered compo- nents manufactured by HHT are found to be defective in materials or workmanship during the applicable warranty period, HHT will, at its option, repair or replace the covered components. HHT, at its own discretion, may fully discharge all of its obligations under such warranties by replacing the product itself or refunding the verified purchase price of the product itself. The maximum amount recoverable under this warranty is limited to the purchase price of the product. This warranty is subject to conditions, exclusions and limitations as described below. wArrANTY PErIOd: Warranty coverage begins on the date of original purchase. In the case of new home construction, warranty coverage begins on the date of first occupancy of the dwelling or six months after the sale of the product by an independent, authorized HHT dealer/ distributor, whichever occurs earlier. The warranty shall commence no later than 24 months following the date of product shipment from HHT, regardless of the installation or occupancy date. The warranty period for parts and labor for covered components is produced in the following table. The term “Limited Lifetime” in the table below is defined as: 20 years from the beginning date of warranty coverage for gas appliances, and 10 years from the beginning date of warranty coverage for wood, pellet, and coal appliances. These time periods reflect the minimum expected useful lives of the designated components under normal operating conditions. Warranty Period HHT Manufactured Appliances and Venting Components Covered Parts Labor Wood Pellet Coal Electric Venting Wood All parts and material except as covered by Conditions, 1 Year...

  • Page 24: Warranty

    wArrANTY CONdITIONS: • This warranty only covers HHT appliances that are purchased through an HHT authorized dealer or distributor. A list of HHT authorized dealers is available on the HHT branded websites. • This warranty is only valid while the HHT appliance remains at the site of original installation. • This warranty is only valid in the country in which the HHT authorized dealer or distributor that sold the appliance resides. • Contact your installing dealer for warranty service. If the installing dealer is unable to provide necessary parts, contact the nearest HHT authorized dealer or supplier. Additional service fees may apply if you are seeking warranty service from a dealer other than the dealer from whom you originally purchased the product. • Check with your dealer in advance for any costs to you when arranging a warranty call. Travel and shipping charges for parts are not covered by this warranty. wArrANTY ExCluSIONS: This warranty does not cover the following: • Changes in surface finishes as a result of normal use. As a heating appliance, some changes in color of interior and exterior surface finishes may occur. This is not a flaw and is not covered under warranty. • Damage to printed, plated, or enameled surfaces caused by fingerprints, accidents, misuse, scratches, melted items, or other external sources and residues left on the plated surfaces from the use of abrasive cleaners or polishes. • Repair or replacement of parts that are subject to normal wear and tear during the warranty period. These parts include: paint, wood, pellet and coal gaskets, firebricks, grates, flame guides, batteries and the discoloration of glass. • Minor expansion, contraction, or movement of certain parts causing noise. These conditions are normal and com- plaints related to this noise are not covered by this warranty. • Damages resulting from: (1) failure to install, operate, or maintain the appliance in accordance with the installation instructions, operating instructions, and listing agent identification label furnished with the appliance; (2) failure to install the appliance in accordance with local building codes; (3) shipping or improper handling; (4) improper opera- tion, abuse, misuse, continued operation with damaged, corroded or failed components, accident, or improperly/ incorrectly performed repairs; (5) environmental conditions, inadequate ventilation, negative pressure, or drafting caused by tightly sealed constructions, insufficient make-up air supply, or handling devices such as exhaust fans or forced air furnaces or other such causes; (6) use of fuels other than those specified in the operating instructions; (7) installation or use of components not supplied with the appliance or any other components not expressly authorized and approved by HHT; (8) modification of the appliance not expressly authorized and approved by HHT in writing;...

  • Page 25: Service & Maintenance Log

    Service & maintenance log Date Of Service Performed By Description Of Service 3-90-08691R18_12/13...
  • Page 26 At Harman, we build each product to a standard, not a price. (Signature of Boxer) Your premium quality hearth product designed and assembled by the experienced and skilled members at Harman in Halifax, PA, USA. Proudly Printed On 100% Recycled Paper...
