Moffat Washing machine Instructions For Use Manual page 9

Leveling the appliance
Water inlet connection
•
Put the appliance in horizontal position by turning
the adjustable legs.
The legs are adjustable up to +/- 0,39 inch (1 cm).
The fl oor must be a hard surface with a
maximum slope of 1⁄2˝ per foot (1,27 cm per 30
cm). To make sure the washer does not vibrate
or move, you may have to reinforce the fl oor.
•
If you have a tumble dryer of the same
dimensions, you can place it on top of the
washing machine.
To ensure correct operation of the appliance,
water pressure inlet must be between 7 psi to
116 psi (0,05 MPa and 0,8 MPa).
Minimum water pressure can be established by
measuring the quantity of poured out water.
0,8 gal (3 litres) of water must be poured out
from completely opened tap in 15 seconds.
•
Insert the gasket with screen into the water inlet
hose thread. Screw the hose thread to the water
faucet
•
In case of hot and cold water connection, connect
one hose to cold and other to hot water faucet as
marked at the rear of the appliance (letters C and
H) (C - cold; H - hot)
9
