Installation and connection

Package removal
Removal of transport
brackets
8
In removing the wrapping be careful not to
damage the appliance with a sharp object.
•
Our appliances are packed in environmentally
friendly materials which may be recycled,
deposited or decomposed without any threat to
the environment.
•
To this end all wrappings are marked accordingly.
•
Move the pipes.
•
Loosen screws A at the rear of the machine
(Fig. 1).
•
Remove the brackets B (Fig. 1) and slide them
into the groove on the blocking rod (Fig. 2) - the
right one should be turned around.
•
Use the brackets to rotate blocking rods for 90°
and pull them out.
•
Close the openings with attached plastic pegs.
Save transport brackets for eventual later use.
Be sure to remove the transport brackets
prior to use, otherwise the appliance may
be permanently damaged. In such cases
the warranty conditions are void.
Fig. 1
Fig. 2
Fig. 2
